- Page 1 Titan 912 /914 EB Greenhouse Assembly Instructions Model Titan 912 EB Model Titan 914 EB Hunkin Garden Products Ltd sales@hunkin.co.nz www.hunkin.co.nz Ph 0800 14 48 65...
- Page 2 We endeavour to supply a quality product, however should you encounter a problem please contact Hunkin Garden Products Ltd either by email sales@hunkin.co.nz or by free phone 0800 14 48 65. To help identify the problem please refer to the assembly instructions and the list of components.
- Page 3 Caution Peel back approximately 2 inches (50mm) of film from both sides before installing. Remove all film immediately after the construction is completed. Mark the sheets with a permanent felt tip pen to indicate the correct side to the sun. The UV-protected side of the sheet has printing on the film and must face towards the sun.
- Page 4 Base The base is powder coated green. This protects the base from ground salts and makes it far more durable when in ground contact. The bolt heads slide into the base channels. Leave the concreting of the middle pegs until later. Some need to line up with the greenhouse frame and it is much easier to align and concrete them later.
- Page 5 Front gable (view from inside looking out) Package No.1 2664 1282 1535 1571 1571 1995 1634 1623 M6x10 Preload two bolts into each 661 before assembly. Used to fasten 712 and 723.
- Page 6 Rear gable (view from inside looking out) Package No.2 2664 1535 1571 1571 2009 2009 2375 2662 1985 1968 M6x10 M6 M6x15 Preload 663, 665 and 664 with two bolts. These are used to fasten 2 x 781 horizontal brac- a1/a2 a3/a2 a1/a2...
- Page 7 Side wall Package No.3 3496 4190 1535 3496 4190 2055 2055 400 M6x10 M6 Titan 912 Titan 914 Preload an extra bolt into 666 before assembly. Used for eave braces later.
- Page 8 Roof Package No.4 All 681 profiles should be preload- ed with 4 bolts ie: all 681 profiles should have 4 free bolts once the eave and ridge have been at- tached. When fitting 713, the full 3496 4190 1571 3485 4179 2084 400 M6x10 M6 length brace, leave one bolt free in Titan 912...
- Page 9 Vent Build the vent around polycarbonate sheet b7. b7 is inserted into the Package No.6 rebated vent frame. No glue required 678 M6x10 M6 M4x8 M4 Φ4.2x9.5 Vent No. a1/a2 Notes on vent assembly No silicone is used on the vent poly- carbonate.
- Page 10 DOOR Tip: Grease the self-tapping screws before you screw them in Package No.5 No silicone glue is required on the doors. Size 2530 1967 1967 1847 P4 has slots. When attaching p4 leave it flush with 591 & 593 until you have put the door on the top run- ner 572.
- Page 11 Door Package No.5 (Tip: Grease the self-tapping screws before you screw them in) a1/a2 a1/a2 Section View Slide the door rollers into the top rail 572. To get past the frame uprights 661 gently pull the bottom of the door out so it clears them.
- Page 12 Mounting the frame on the base The frame, once completed and prior to glazing with polycarbonate, can now be lifted onto the base. Only do this if the con- crete has set. With a helper on each corner the greenhouse can be easily lifted into place.
- Page 13 If you are in a high wind area you might like to consider Polycarbonate sheets using ADOS MS high performance adhesive sealant in- stead of the sealer supplied. Avail. Mitre 10, Bunnings etc. s-585,f-3 Before you start to mount the pol- ycarbonate make sure the frame is square.
- Page 14 Polycarbonate sheet PVC locking strip Step6 Step1 Step4 Step3 Step2 Step5 Step6 Step1 Step4 Step3 Step2 Step5 PVC locking strip Note: PVC locking strips are pushed into place from the top and the bottom in a diagonal direction, bit by bit, so the PVC locking strips are fitted evenly. If you fully insert the PVC locking strips from one side only, the polycarbonate panel may move sideways making it very difficult to insert the PVC locking strip to the other side.
- Page 15 Installing the polycarbonate sheets (see page 16 for more info) PVC capping bars (U shaped) are put Titan 912 Titan 914 over the ends of the sheet (top and bot- 677x1553/1991 tom) to stop moisture and bugs from getting into the twin wall portions of the 609x2002/2399 polycarbonate.
- Page 16 Installing the polycarbonate sheet Inserting PVC locking strips. W clips and PVC locking strips are supplied with the greenhouse. PVC locking strips are far superior to W clips in the wind so we recommend you use them. W clips have just been left in the kits to be used in case you are short shipped PVC locking strips.
