MODEL Q-10
Q-10N, Q-10VCR
ONE PIECE BODY, SWITCH
TUBE, COVER AND CABLE
18/2 SJT
UL APPROVED
CABLE, 0.33" O.D.
SONIC WELDED IN PLACE
ONE PIECE DRAG
STRIP INCLUDING
MAGNET HOUSING
AND MOUNTING SCREW
OPTIONAL DRAG
STRIP LENGTH
INSTALLATION INSTRUCTION SHEET
1" NPT
STANDARD PLASTIC
OR METAL TEE
PARTS LIST
FLUID FLOW SWITCH
ULTRA RELIABLE SINCE 1956
HARWIL CORPORATION
541 KINETIC DRIVE, OXNARD, CA 93030
TEL: (805) 988-6800 FAX: (805) 988-6804
EMAIL: HARWIL@HARWIL.COM
1 ⁄ "
A / F
⁄ "
ENCAPSULATED
REED SWITCH
ENCAPSULATED
MAGNET
TURBULENT
2D
FLOW REDUCTION
5D
MOUNT IN
THREE POSITIONS
¾"
1 ⁄ "
