Govaplast Play Picknick Table Mini User Manual

Only for use with parasol posts
diameter 45 to 48 mm
(By using smaller parasols, there
will be the risk of finger entrapment)
!
NO parasol use
during heavy wind ...
According to EN1176, this picnic table
is not considered as being a play equipment.
Therefore, a TÜV-certificate is not required.
100% recycled material
83 kg
Govaerts Recycling NV | Kolmenstraat 1324 | B-3570 Alken | info@govaplast.com | www.govaplast.com
Latest version can always be found at www.govaplay.com
+/- 73 kg
62
135
Material
· Solid posts and planks made of recycled plastic (PE), coloured throughout.
· Stainless steel screws and lock bolts
Mounting
The Picnic table GP16 is delivered fully assembled. Anchorage is possible.
Description
The picnic table consists of 2 A-shaped legs made of 4 x 12 cm beams on which the table
top and the two seats are mounted. The seat consists of two 4 x 12 x 120 cm boards. The
table top consists of five 4 x 12 x 120 cm boards. Between the A-shaped table legs, a 4 x 12
cm beam is mounted. A hole of 50 mm for a parasol post is provided in the middle of the
table (suited for parasol posts with diameter of 45 to 48 mm).
Anchorage
The picnic table GP 16 is freestanding or to be anchored on a hard surface. The table GP16b
has extended legs which are to be anchored in a loose ground (grass, ...) using sand-cement
mixture or concrete.
User manual GP16
"Picknick tablel Mini"
( version 2015-01)
120
56
1
