Summary of Contents for Clevo N855HC

  • Page 1 N855HC...
  • Page 3 Preface Notebook Computer N855HC Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the N855HC se- ries notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 7 Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.
  • Page 9 Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 Top ....................A-3 Bottom ................... A-4 Overview ..................1-1 Main Board ................... A-5 Specifications ..................1-2 HDD ....................A-6 External Locator - Top View with LCD Panel Open ......1-4 LCD ....................A-7 External Locator - Front & Right Side Views .........1-5 Schematic Diagrams.........
  • Page 12 Preface PCH 4/9 ..................B-26 LED Board ..................B-58 PCH 5/9 ..................B-27 Power Sequence ................B-59 Updating the FLASH ROM BIOS..C-1 PCH 6/9 ..................B-28 PCH 7/9 ..................B-29 Download the BIOS ................C-1 PCH 8/9 ..................B-30 Unzip the downloaded files to a bootable CD/DVD or PCH 9/9 ..................

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the N855HC series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about dri- vers (e.g.

  • Page 14: Specifications

    Introduction Specifications Processor Options Video Adapter Intel® Kabylake H Processort Intel® Integrated GPU and NVIDIA® Discrete GPU (2.70GHz) Supports Microsoft Hybrid Graphics 8MB Smart Cache, 14nm, DDR4-2400MHz, TDP 45W  Intel Integrated GPU (2.40GHz) Latest Specification Information Intel® UMA Graphics 8MB Smart Cache, 14nm, DDR4-2400MHz , TDP 45W Dynamic Frequency The specifications listed here are correct at the...
  • Page 15 Introduction Keyboard Communication Full-size “WinKey” keyboard (with numeric keypad) Built-In Gigabit Ethernet LAN 1.0M HD PC Camera Module (Factory Option) Full-size “WinKey” Illuminated White-LED (Factory Option) 2.0M FHD PC Camera Module Keyboard (with numeric keypad) (Factory Option) M.2 3G or 4G Module Pointing Device WLAN/ Bluetooth M.2 Modules: (Factory Option) Intel®...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. PC Camera 2. *PC Camera LED *When the PC camera is in use, the LED will be illuminated. 3. Built-In Array Microphone 4. LCD 5. Power Button 6.

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Indicator FRONT VIEW Figure 3 Right Side View 1. Headphone-Out RIGHT SIDE VIEW Jack 2. Microphone-In Jack 3. USB 2.0 Port 4. USB 3.0 (USB 3.1 Gen 1) Type A Port 5.

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. DC-In Jack 2. RJ-45 LAN Jack 3. External Display LEFT SIDE VIEW Port 4. HDMI-Out Port 5. USB 3.0 (USB 3.1 Gen 1) Type C Port (Factory Option) USB 3.1 Gen 2 Type C Port...

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Vent 3. Speakers  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use. External Locator - Bottom View 1 - 7...

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. KBC-ITE IT8587 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. GPU 2. CPU 3. Memory Slots DDR4 SO-DIMM 4. Mini-Card Connector (WLAN Module) 5. PCH 6. CMOS Battery 7. M.2-Card Connector (SSD Module) Mainboard Overview - Bottom (Key Parts) 1 - 9...

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. DC-In Jack 2. RJ-45 LAN Jack 3. External Display Port 4. HDMI-Out Port 5. USB Port 3.0/3.1 (Type C) Connector 6. USB Port 3.0/3.1 (Type A) Connector 7. Multi-in-1 Card Reader 8.

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. CCD Connector 2. Fan Connector 3. HDD Connector 4. Speaker Connector 5. LCD Connector Mainboard Overview - Bottom (Connectors) 1 - 11...
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the N855HC series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the 3G Module: 1. Remove the battery page 2 - 5 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn the computer off, and turn it over. 2. Slide the latch in the direction of the arrow (Figure 1a). a. Slide the latch in the 3. Slide the latch in the direction of the arrow. direction of the arrow.

  • Page 30: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 2 Keyboard Removal 1. Turn off the computer, turn it over. 2. Remove screws from the bottom of the computer. a. Remove the screws from 3. Open it up with the LCD on a flat surface before pressing at point to release the keyboard module (use the spe- the bottom of the compu- cial eject stick...

  • Page 31: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive Figure 3 The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm HDD Assembly or 7mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as Removal outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 32 Disassembly screws from the HDD assembly (Figure 4b). Figure 4 6. Slightly lift and pull the hard disk assembly in the direction of arrow (Figure 4c HDD Assembly 7. Lift the hard disk assembly out of the bay (Figure 4d Removal (cont’d.) 8.

  • Page 33: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 5 RAM Module The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDR3L up to 1600 MHz. The main memory can be expanded up to 16GB. The total memory size is automatically de- tected by the POST routine once you turn on your computer.

  • Page 34: Removing The M.2 Ssd Module

    Disassembly Removing the M.2 SSD Module Figure 6 M.2 SSD Module M.2 SSD Module Removal Procedure Removal 1. Turn off the computer, turn it over, remove the battery (page 2 - 2. The M.2 SSD module will be visible at point on the mainboard (Figure 6a).

  • Page 35: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 7 Wireless LAN 1. Turn off the computer, turn it over, remove the battery (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 7a).

  • Page 36: Wireless Lan, Combo, 3G & Lte Module Cables

    Disassembly Wireless LAN, Combo, 3G & LTE Module Cables Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, 3G and LTE modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for iden- tification as outlined in the table below.

  • Page 37: Removing The 3G Module

    Disassembly Removing the 3G Module Figure 8 3G Module Removal Procedure 3G Module Removal 1. Turn off the computer, remove the battery (page 2 - a. Locate the module. 2. Locate the module, it is visible at point Figure 8a b.

  • Page 38: Removing The Cpu Heat Sink

    Disassembly Removing the CPU Heat Sink Figure 9 Heat Sink Removal Heat Sink Removal Procedure 1. Turn off the computer, turn it over, remove the battery (page 2 - 5) and the bottom cover (page 2 - a. Remove the screws. &...

  • Page 39: Removing The Ccd

    Disassembly Removing the CCD Figure 10 CCD Removal 1. Turn off the computer, turn it over to remove the battery (page 2 - 2. Lay the computer down on a flat surface with the top case up forming a 90 degree angle. Carefully remove the a.
  • Page 40 Disassembly 5. Disconnect the cable (Figure 11c). Figure 11 6. Remove the CCD module (Figure 11d). CCD Removal 7. Reverse the process to install a new CCD module. (cont’d) c. Disconnect the cable. d. Remove the CCD mod- ule.  11.

  • Page 41: Part Lists

    Appendix A:Part Lists This appendix breaks down the N855HC series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 42: Part List Illustration Location

    Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part Location page A - 3 Bottom page A - 4 page A - 5 Main Board page A - 6 page A - 7 A - 2...

  • Page 43: Top

    Figure A - 1 Top A - 3...

  • Page 44: Bottom

    Bottom Figure A - 2 Bottom A - 4 Bottom...

  • Page 45: Main Board

    Main Board Figure A - 3 Main Board Main Board A - 5...

  • Page 46: Hdd

    Figure A - 4 A - 6 HDD...

  • Page 47: Lcd

    Figure A - 5 LCD A - 7...
  • Page 48 A - 8...

  • Page 49: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the N855HC notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1...

  • Page 50: System Block Diagram

    Schematic Diagrams System Block Diagram N850HC/HN System Block Diagram (Kabylake) VDD3,VDD5 SHEET 43 nVIDIA GPU NVDIDA NVVDD Nvidia 2 VIA:3"~8" N16P-GT(950M)RAM SIZE 2GB (128Mbx4x32)DDR5 Kabylake-H PCIE*8 4 VIA:3"~9" N16S-GTR(940M)RAM SIZE 2GB (256Mbx4x32)DDR5 SHEET 50 KBY-H 42 45W N850HC--N16P-GT N850HN--N16S-GTR 5V,3V,5VS,3VS 2 vias <10"...

  • Page 51: Processor 1/6

    Schematic Diagrams Processor 1/6 SKYLAKE _HA LO U29C BGA1440 PEG_TX_0 C633 0.22u_10V_X5R_04 PEG_RX0 PEG_TX#_0 PEG_TX0 10 PEG_RXP[0] PEG_TXP[0] C632 0.22u_10V_X5R_04 PEG_RX#0 PEG_RXN[0] PEG_TXN[0] PEG_TX#0 10 PEG_TX_1 C630 0.22u_10V_X5R_04 6-36-00180-250(BOT) PEG_RX1 PEG_TX#_1 PEG_TX1 10 PEG_RXP[1] PEG_TXP[1] C631 0.22u_10V_X5R_04 PEG_RX#1 PEG_RXN[1] PEG_TXN[1] PEG_TX#1 10 CPU HOLD PEG_TX_2...
  • Page 52 Schematic Diagrams Processor 2/6 U29A SKYLAKE _HA LO U29B SKYLAKE _HA LO M_A_DQ[63:0] M_B_DQ[63:0] BGA1440 BGA1440 M_A_DQ0 M_B_DQ0 BT11 M_A_DQ1 DDR0_DQ[0] DDR0_CKP[0] M_A_CLK_DDR0 M_B_DQ1 DDR1_DQ[0]/DDR0_DQ[16] DDR1_CKP[0] M_B_CLK_DDR0 BR11 M_A_DQ2 DDR0_DQ[1] DDR0_CKN[0] M_A_CLK_DDR#0 M_B_DQ2 DDR1_DQ[1]/DDR0_DQ[17] DDR1_CKN[0] M_B_CLK_DDR#0 M_A_DQ3 DDR0_DQ[2] DDR0_CKN[1] M_A_CLK_DDR#1 M_B_DQ3 DDR1_DQ[2]/DDR0_DQ[18] DDR1_CKN[1]...

  • Page 53: Processor 3/6

    Schematic Diagrams Processor 3/6 NEAR CPU 1.0V_VCCST CFG[0]: Stall reset sequence after PLL lock until de-asserted: — 1 = (Default) Normal Operation; SKYLAKE _HA LO U29E No stall. — 0 = Stall. BGA1440 BN25 CFG0 PCH_CPU_BCLK_R_DP CFG[1]: Reserved configuration lane. BCLKP CFG[0] BN27...
  • Page 54 Schematic Diagrams Processor 4/6 PLACE CAPS AT BOARD EDGE CPU_TOP_VCCCORE VCCEDRAM VCORE VCORE SKYLAKE _HA LO VCORE U29G SKYLAKE _HA LO U29J BGA1440 BGA1440 AA13 C250 Gary_nonstuff AA31 BJ17 VCCOPC AA32 BJ19 VCCOPC C588 C266 C262 AA33 BJ20 PLACE CAP BACKSIDE VCCOPC AA34 BK17...

  • Page 55: Processor 5/6

    Schematic Diagrams Processor 5/6 PLACE CAP BACKSIDE VCCVDDQ_CLK 1.0V_VCCST 1.0V_VCCST VCCSA VDDQ C296 C214 C213 SKYLAKE _HA LO U29I 11.1A 2.8A BGA1440 VCCSA VDDQ SKYLAKE _HA LO AE12 place to angle U29K VCCSA VDDQ VCCSA VDDQ BGA1440 VCCSA VDDQ TP_SKL_D1 TP_SKL_BM33 T104 BM33...
  • Page 56 Schematic Diagrams Processor 6/6 VCCGT VCCGT VCCGT SKY LAKE_H ALO SKY LAKE_H ALO U29F U29L U29M SKY LAKE_H ALO VCCGTU BGA1440 BGA1440 SKY LAKE_H ALO BGA1440 AK30 U29N SKY LAKE_H ALO AK29 U29H AJ29 BGA1440 BG34 AV29 AJ30 VCCGT VCCGT VCCGT VCCGT BGA1440...

  • Page 57: Ddr4 Cha So-Dimm

    Schematic Diagrams DDR4 CHA SO-DIMM Channel A SO-DIMM 0[RAM1] VTT_MEM RVS TYPE VDDQ J_DIMMA_2B H=5.2mm 2.5V J_DIMMA_2A M_A_DQ[63:0] VDD19 M_A_DQ1 VDD18 M_A_CLK_DDR0 CK0_T M_A_DQ0 VDD17 M_A_CLK_DDR#0 M_A_DQ3 CK0_C VDD16 VPP2 M_A_CLK_DDR1 CK1_T M_A_DQ2 VDD15 VPP1 M_A_CLK_DDR#1 CK1_C M_A_DQ4 VDD14 M_A_DQ5 VDD13 3.3VS M_A_CKE0...

  • Page 58: Ddr4 Chb So-Dimm

    Schematic Diagrams DDR4 CHB SO-DIMM VTT_MEM STD TYPE J_DIMMB_1B Channel B SO-DIMM 0[RAM2] VDDQ 2.5V H=5.2mm VDD19 VDD18 VDD17 J_DIMMB_1A VDD16 VPP2 PLACE THE CAP WITHIN 200 MILS FROM THE SODIMM M_B_DQ5 M_B_DQ[63:0] VDD15 VPP1 DDR4_DRAMRST# M_B_CLK_DDR0 CK0_T M_B_DQ1 VDD14 3.3VS 8,25 DDR4_DRAMRST#...

  • Page 59: Vga Pci-E Interface

    Schematic Diagrams VGA PCI-E Interface 3V3_AON N16x 2.0 U150A BGA_0908_P080_P085_P100_290X290 COMMON 10K_04 Gary_Change Value N14x 1.0 1/19 PCI_EXPRESS N16x 2.0 Gary_Change Value PEX_VDD 2SK3018S3 SNN_PEXWAKE PEX_CLKREQ# AJ11 N17P GB4C-128 PEX_WAKE PEG_CLKREQ# AG19 PEX_DVDD PEX_IOVDD R480 0_04 AJ12 PEX_DVDD AG21 GPU_PEX_RST# PEX_RST PEX_IOVDD AG22...

  • Page 60: Vga Frame Buffer Interface

    Schematic Diagrams VGA Frame Buffer Interface Term Description U150C BGA_0908_P080_P085_P100_290X290 FBB_CMD[31:0] The total trace length measured COMMON FBB_CMD[31:0] 14,15 from GPU ball to capacitor is Under GPU 3/19 FBB Frame Buffer Interface no more than 150 mil The total trace length measured FBB_D[31:0] U150D from GPU ball to capacitor is no...

  • Page 61: Vga Frame Buffer A

    Schematic Diagrams VGA Frame Buffer A U151B U151C INS1220714 INS1221418 BGA170 BGA170 COMMON 11,13 FBA_CMD[31:0] COMMON FBA_CMD12 Normal FBA_CMD15 FBA_SOE0 FBA_CMD5 MF_VSS/SOE* FBA_CLK0 FBVDDQ FBA_CMD0 add 1k to VSS FBA_CLK0# R455 FBA_D[31:0] FBA_CMD8 1K_04 U151D U151A FBA_CMD10 FBA_CMD11 A0_A10 INS1221112 INS1220380 A1_A9 BGA170...
  • Page 62 Schematic Diagrams VGA Frame Buffer A U152B U152C INS1224528 INS1224754 BGA170_MIRR BGA170_MIRR 1K_04 COMMON COMMON 11,12 FBA_CMD[31:0] FBVDDQ Mirrored FBA_CMD28 FBA_CLK1 FBA_CMD31 FBA_SOE3 FBA_CLK1# SOE*/MF_VDD FBA_CMD21 FBA_CMD16 add 1k to VDD FBA_D[63:32] FBVDDQ FBA_CMD24 U152D U152A INS1225672 INS1226066 FBA_CMD26 A0_A10 BGA170_MIRR BGA170_MIRR FBA_CMD27...

  • Page 63: Vga Frame Buffer B

    Schematic Diagrams VGA Frame Buffer B U158B U158C INS1233936 INS1234206 BGA170 BGA170 COMMON COMMON Normal 11,15 FBB_CMD[31:0] FBB_CMD12 FBB_CMD15 FBB_SOE0 MF_VSS/SOE* FBB_CMD5 FBVDDQ FBB_CLK0 add 1k to VSS FBB_CMD0 FBB_CLK0# R577 FBB_CMD8 1K_04 FBB_D[31:0] FBB_CMD10 U158D U158A A0_A10 FBB_CMD11 N16P-GT INS1233730 INS1235576 A1_A9...
  • Page 64 Schematic Diagrams VGA Frame Buffer B U154B U154C INS25562815 INS25563645 BGA170_MIRR BGA170_MIRR COMMON COMMON Mirrored R576 1K_04 11,14 FBB_CMD[31:0] FBVDDQ FBB_CMD28 FBB_CMD31 FBB_SOE3 SOE*/MF_VDD N16P-GT FBB_CLK1 FBB_CMD21 add 1k to VDD FBB_CLK1# FBB_CMD16 FBVDDQ FBB_D[63:32] FBB_CMD24 U154A U154D FBB_CMD26 INS25562313 A0_A10 BGA170_MIRR FBB_CMD27...

  • Page 65: Vga I/O

    Schematic Diagrams VGA I/O U150K U150L U150M BGA_0908_P080_P085_P100_290X290 BGA_0908_P080_P085_P100_290X290 U150N BGA_0908_P080_P085_P100_290X290 COMMON COMMON BGA_0908_P080_P085_P100_290X290 COMMON 7/19 IFPC 8/19 IFPD COMMON 9/19 IFPEF 4/19 DACA ALL PINS NC FOR GF117 ALL PINS NC FOR GF117 ALL PINS NC FOR GF117 GF108/GKx N17P GB4C-128 N17P...

  • Page 66: Vga Nvvdd Coupling

    Schematic Diagrams VGA NVVDD Coupling Gary_from RS1 to PJ74 NVVDD Gary_Change Value U150G U150I U150E U150H BGA_0908_P080_P085_P100_290X290 BGA_0908_P080_P085_P100_290X290 NVVDD BGA_0908_P080_P085_P100_290X290 BGA_0908_P080_P085_P100_290X290 COMMON COMMON COMMON COMMON C169 C234 C166 C158 Gary_D02 for common design(to X6S) 16/19 GND_1/2 14/19 NVVDD 10/19 XVDD 17/19 GND_2/2 AM25...

  • Page 67: Ps8625

    Schematic Diagrams PS8625 Sheet 18 of 58 PS8625 Gary_DEL PS8625 Title Title Title [18] PS8625(EDP TO LVDS) [18] PS8625(EDP TO LVDS) [18] PS8625(EDP TO LVDS) Size Size Size Document Document Document Number Number Number R e v R e v R e v 6-71-N8500-D02 6-71-N8500-D02...

  • Page 68: Panel, Inverter

    Schematic Diagrams Panel, Inverter PANEL POWER PANEL CONNECTOR SHORT VIN_LCD PJ16 OPEN_2A *MTS3572G6 Gary_DEL LVDS CON. C243 C282 D02A C242 3.3V R106 *0.22u_50V_Y5V_06 *220_06 R646 *150K_04 *10K_04 *100K_04 LVDD_EN#1 *MTDK5S6R *100K_04 Gary_D02 Change LCD PIN Define 3.3VS *MTDK5S6R Gary_NB_ENAVDD change "PANELEN"...

  • Page 69: Crt

    Schematic Diagrams 5VS_CRT 6-19-31001-003 J_CRT1 DS15146BAC067 RB751S-40H DAC_RED *0402_short FCM1005MF-600T01 FRED DAC_GREEN *0402_short FCM1005MF-600T01 FGRN 6-06-75140-068 R471 DAC_BLUE *0402_short FCM1005MF-600T01 FBLUE 2.2K_04 2.2K_04 C120 C119 C118 C117 C116 C115 VGA_SDA 6-13-36R01-28C VGA_HSYNC VGA_HS_R R452 36_1%_04 VGA_VSYNC VGA_VS_R 36_1%_04 POWER VGA_SCL C607 C627 3.3VS...

  • Page 70: Hdmi

    Schematic Diagrams HDMI Differential pair mismatch < 5 mil R4.4 CPU to Level Shift total trace length < 5.5” ,via count 2 ,referenc e t o ground . Level Shift to HDMI connector total trace length < 1” ,via count 2 ,referenc e t o ground .

  • Page 71: Pch 1/9

    Schematic Diagrams PCH 1/9 BOOT HALT JTAG ODT ENABLE:LOW DISABLE:LOW (INTERNAL WEAK PD) (INTERNAL WEAK PU) SP T-H_P CH U45A SPI_SI_R SPI_SO_R LAN_WUP# R550 *0_04 BD17 BB27 32,36,40 LAN_WAKEUP# GPP_A11/PME# GPP_B13/PLTRST# PLT_RST# 26 AG15 RSVD AG14 R520 R543 T134 RSVD GPP_G16/GSXCLK AF17 *4.7K_04...
  • Page 72 Schematic Diagrams PCH 2/9 SP T-H_P CH U45B DMI_MT_IR_0_DN DMI_RXN0 USB2N_1 USB_PN1 USB_PP1 1- USB3 Port 1 Charger DMI_MT_IR_0_DP DMI_RXP0 USB2P_1 USB_PN2 DMI_IT_MR_0_DN DMI_TXN0 USB2N_2 2- CCD DMI_IT_MR_0_DP USB_PP2 DMI_TXP0 USB2P_2 DMI_MT_IR_1_DN USB_PN3 DMI_RXN1 USB2N_3 AG10 3- BT DMI_MT_IR_1_DP DMI_RXP1 USB2P_3 USB_PP3 USB_PN4...

  • Page 73: Pch 3/9

    Schematic Diagrams PCH 3/9 BIOS RECOVERY ENABLE :LOW PCH_RSVD MFG_MODE 3.3VS 3.3VS 3.3VS SATAGP3 3.3VS SATAGP2 10K_8P4R_04 SATAGP1 SATAGP0 R233 R234 R605 SCI#_R R620 10K_04 Gary_DEL ODD_DA# *10K_04 *10K_04 *10K_04 SATA_LED# R604 10K_04 BIOS_REC PCH_RSVD MFG_MODE SWI#_R R618 10K_04 SP T-H_P CH 3.3VA U45C Gary D02 non-stuff for GPIO...
  • Page 74 Schematic Diagrams PCH 4/9 R621 1.5K_1%_04 R622 45.3K_1%_04 VDD3 SP T-H_P CH U45D ISH_GP_6_R RTC3.2V BB17 HDA_BITCLK HDA_BCLK GPP_A12/BMBUSY#/ISH_GP6/SX_EXIT_HOLDOFF# PM_CLKRUN# AW22 HDA_RST# HDA_RST# GPP_A8/CLKRUN# 6-06-00054-06F HDA_SDIN0 LAN_DISABLE_N HDA_SDI0 AR15 VCC_RTC HDA_SDI1 GPD11/LANPHYPC HDA_SDOUT PCH_SLP_WLAN# AV13 25,39 HDA_SDOUT HDA_SDO GPD9/SLP_WLAN# PCH_SLP_WLAN# HDA_SYNC HDA_SYNC DDR4_DRAMRST#...

  • Page 75: Pch 4/9

    Schematic Diagrams PCH 5/9 3.3VS R191 R192 U45E 100K_04 100K_04 SP T-H_P CH HDMI_CTRLCLK VGA_HPD GPP_I7/DDPC_CTRLCLK HDMI_CTRLDATA HDMI_CTRLCLK VGA OUT(B) VGA_HPD VGA_CLK HDMI_CTRLDATA GPP_I0/DDPB_HPD0 GPP_I8/DDPC_CTRLDATA HDMI OUT(C) DDPB_HPD GPP_I1/DDPC_HPD1 GPP_I5/DDPB_CTRLCLK VGA_DATA HDMI_HPD GPP_I2/DDPD_HPD2 GPP_I6/DDPB_CTRLDATA GPP_I3/DDPE_HPD3 GPP_I9/DDPD_CTRLCLK GPP_I10/DDPD_CTRLDATA GPP_F14 DGPU_PWR_EN H_SKTOCC_N GPP_F23 DGPU_RST#_PCH DGPU_PWR_EN...
  • Page 76 Schematic Diagrams PCH 6/9 C741 15p_50V_NPO_04 6-07-18034-1A0 R636 FSX3M_24MHZ 1M_1%_04 SPEC: 20PPM R637 *10mil_short C742 15p_50V_NPO_04 SP T-H_P CH U45G AR17 GPP_A16/CLKOUT_48 PCH_XDP_CLK_DN 24 MHz CLKOUT_ITPXDP PCH_XDP_CLK_DP 2015.9.11 CPU_24MHZ_R_DP CLKOUT_CPUNSSC_P CLKOUT_ITPXDP_P 100 MHz XTAL P OWE R O R CPU_24MHZ_R_DN CLKOUT_CPUNSSC R554 100 MHz...

  • Page 77: Pch 7/9

    Schematic Diagrams PCH 7/9 VDD1.0 VDD1.0 SP T-H_P CH U45H Gary_Change footprint VDD3 eSPI:1.8V AA23 2.899A R534 *20mil_04 LPC:3.3V 3.3VA VCCPRIM_1P0 AA26 VCCPRIM_1P0 AA28 AL22 0.0908A R177 *20mil_04 3.3VA VCCPRIM_1P0 VCCPRIM_1P0 AC23 Gary_Change footprint VCCPRIM_1P0 AC26 BA24 0.403A C324 R204 *20mil_04 3.3VA VCCPRIM_1P0...
  • Page 78 Schematic Diagrams PCH 8/9 U45I SP T-H_P CH SP T-H_P CH AC18 U45L AB11 AN10 M-MARK M-MARK M-MARK M-MARK BE14 AB14 BE18 AE29 AB31 BE23 AB32 BE28 AE42 AB38 BE32 AF18 BE37 AF20 BE40 AF21 AF23 AC20 AF25 AC21 AF26 AC25 AF28 AC29...

  • Page 79: Pch 9/9

    Schematic Diagrams PCH 9/9 NO REBOOT STARP ENABLE: HIGH (INTERNAL WEAK PD) SP T-H_P CH U45J 3.3VS DFX TEST MODE QUALIFIER FOR OTHER DFX STRAP WHEN SAMPLED LOW (WEAK INTERNAL PU) AR22 RSVD22 RSVD BD45 R209 RSVD BD44 Gary_DEL EDP_DET RSVD *4.7K_04 BE44...

  • Page 80: M.2 3G Card

    Schematic Diagrams M.2 3G Card 3G_EN 3G CARD 6-34-P750S-010(BOT) GPS_DISABLE# CURRENT2A ,DON'T DROP BELOW 3.135V 3G_PWR_EN Gary_D02 for common design 3G_3.3V 3G_3.3V 80 mils H6_5D3_7 J_3G1 C830 220u_6.3V_6.3*6.3*4.2 base on common design C813 0.1u_16V_Y5V_04 CONFIG_2 3.3V4 GND10 3.3V3 C814 0.1u_16V_Y5V_04 GND9 3.3V2 DETECT_SW...

  • Page 81: M.2 Wlan+Bt, Ssd

    Schematic Diagrams M.2 WLAN+BT, SSD J_WLAN1 WLAN+BT 40 mil WLAN_3.3V GND10 3.3V3 Reserved/REFCLKN1 3.3V2 C428 C462 C427 Reserved/REFCLKP1 UIM_Power_In/Gpio1/PEWake1# GND9 UIM_Power_Out/CLKREQ1# *22u_6.3V_X5R_08 *22u_6.3V_X5R_08 0.1u_16V_Y5V_04 Reserved/PERn1 UIM_SWP/PERST1# Reserved/PERp1 Reserved1 GND8 ALERT#(I) R305 10K_04 PJ33 *2mm 3.3V Reserved/PETn1 I2C CLK(O) WLAN_3.3V R304 10K_04 VDD3 WLAN_3.3V...

  • Page 82: Asm 1142 & 2142

    Schematic Diagrams ASM 1142 & 2142 PCIE_TXP1_ASM FSX3M 20.0000000M16FAO PCIE_TXN1_ASM PCIE_RXP1_ASM 0.22u_10V_X5R_04 C419 USB3.1 PCIE_RXN1_ASM 0.22u_10V_X5R_04 C420 USB3.1 Gary_DEL PCIE3~4(Reserved) USB3.1 VDDP_12P 12p_50V_NPO_04 C417 USB3.1 R298 0_04 USB3.1 ASM_1.2VS_1.05VS <0.5" , Diff : 95 ohm C749 4.7u_6.3V_X5R_06 USB3.1 USB3.1 ASM1142_REXT R654 12.1K_1%_04 PCIE_RXP2_ASM...

  • Page 83: Asm Power

    Schematic Diagrams ASM Power For ASM2142 Layout trace 2A after jumper PR155 *10_06 PC78 USB3.1_2142 PC66 USB3.1_2142 USB3.1_2142 PC70 *MP2315GJ-Z USB3.1_2142 *0.1u_10V_X7R_04 PC69 PR160 USB3.1_2142 USB3.1_2142 *0_04 ASM_1.05V *BCIHP0420TB-2R2M PR151 PJ36 USB3.1_2142 *1mm *0_04 PR150 PR161 PC68 PC71 PC79 USB3.1_2142 *47K_1%_04 USB3.1_2142 USB3.1_2142...

  • Page 84: Usb, Charger

    Schematic Diagrams USB, Charger USB3.1 USB3.0/3.1 PORT(PORT1) Add TYPE-C Function 6-02-75495-9C0 USB3.0 PORT(PORT3) 5V_MUX VDD5 USBVCC_CH ASM1543_VCONN_EN CC_RDY# 5V_MUX ASM_3.3V 80 mil ASM1543_PWR_EN MC_RDY# pin1 80 mil ASM1543_MODE_SEL HC_RDY# Gary_Reserved USB3.1 control signal VOUT C713 C709 HCB1608KF-121T30 C753 USB3.1 USB3.1 10u_6.3V_X5R_06 C415 C426...

  • Page 85: Card Reader / Lan Rtl8411B

    Schematic Diagrams Card Reader / LAN RTL8411B LAN (RTL8411B) Crystal HSX32 1 S(3. 2X 2. 5X 0. 6 5) 6 IN 1 SOCKET - MMC / RSMMC meet realtek Freq tolerance 50ppm - SD / mini SD / SDHC / SDXC J_CARD-REV1 RSET R340...

  • Page 86: Hdd, Click Tp, Audio, Hall Con

    Schematic Diagrams HDD, Click TP, Audio, Hall Con.. FOR SUPPORT OPTANE project, SATA HDD POWER GATEING HDD CONNECT1 (MASTER) SATA_5VS PJ75 *OPEN-3mm SATA_5VS U159 6-20-43790-122 Gary_for OPTANE control 2.5A 2.5A J_HDD1 Gen3 VOUT C835 C836 C837 C838 JHDD_SATA_TXP2 C812 0.01u_16V_X7R_04 VOUT JHDD_SATA_TXN2 SATA_TXP2...

  • Page 87: Led, Ccd, Tpm, Power Sw Con

    Schematic Diagrams LED, CCD, TPM, Power SW Con. NGFF B & M KEY TPM 2.0 (SLB9665TT) PCI E S S D L E D S A T A WLAN LED L E D WLAN ON PIN24 S S D L E D B I O S Windows 7 WLAN OFF...

  • Page 88: Audio Codec Alc269 Vc2

    Schematic Diagrams Audio Codec ALC269 VC2 PCB Footprint ALC26 9 VC2-QFN48-6 X 6M AUDIO CODEC ALC269 VC2 EMI Require Layout note: PVDD1_2 HCB1005KF-121T20 GND and AUDG space is *HCB1005KF-121T20 60mils ~ 100mils AUDG DVDD_IO For 3.3V HDA Link. R373 *20mil short-p C520 C519 Gary_DEL C898(base on common design)

  • Page 89: Kbc-Ite It8587

    Schematic Diagrams KBC-ITE IT8587 KBC_AVDD HCB1005KF-121T20 VDD3 VDD3 VDD3 VDD3 C536 C557 C556 C500 C502 10u_6.3V_X5R_06 0.1u_10V_X7R_04 0.1u_10V_X7R_04 0.1u_10V_X7R_04 GPIO9_THERM_ALERT_EC SMC_BAT R342 *10K_04 R412 0.1u_10V_X7R_04 R362 1.5K_04 N850 N870 SMD_BAT R383 1.5K_04 100K_04 C553 BAT_DET Used for 15" VBATT_BOOST# R348 10K_1%_04 KBC_WRESET# R347...

  • Page 90: 5V, 5Vs, 3.3V, 3.3Vs, 3.3Va

    Schematic Diagrams 5V, 5VS, 3.3V, 3.3VS, 3.3VA DD_ON# VDD3 VDD3 SUSB PR168 PR164 VIN1 10K_04 10K_04 C819 C832 C569 C831 DD_ON# SUSB DD_ON# 35,44 SUSB 21,34,37 C531 C530 C529 PC80 0.1u_50V_Y5V_06 0.1u_50V_Y5V_06 0.1u_50V_Y5V_06 2SK3018S3 PC82 2SK3018S3 35,40,43 DD_ON 19,23,25,34,35,40,42,44 SUSB# *0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 PR167...

  • Page 91: Vdd1.0, Vccio

    Schematic Diagrams VDD1.0, VCCIO For CV test VDD1.0 VDD1_EN TON_P1U1 R425 100K_04 PR172 820K_1%_06 VDD3 PJ50 *CV-1mm PC225 PC223 PC224 R427 *0_04 DD_ON_EN SHORT PR170 PC81 VREG5 0_06 0.1u_10V_X7R_04 PQ39 25,40,47 SLP_SUS# QM3004M3 EN_PSV PJ83 DH_PU1 PR346 0_06 V1.0A PL19 VDD1.0 SHORT VTT_SELECT...

  • Page 92: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5 VREF PR344 *10mil_short PC229 1u_10V_Y5V_06 PR343 PR345 EN_5V PC227 62K_1%_04 62K_1%_04 PC230 1000p_50V_X7R_04 1000p_50V_X7R_04 D01A PU16 2.5A VREG3 PC89 PC87 PC88 PC232 PC231 PC90 PC84 PC83 VDD3 PC228 1u_6.3V_X5R_04 LDO3 PQ38 PQ42 QM3004M3 PC236 QM3004M3 15 A 12 A VDD5 BOOT2...

  • Page 93: Ddr 1.2V/0.6Vs, 2.5V

    Schematic Diagrams DDR 1.2V/0.6VS, 2.5V DDR4 PD17 PQ36 1.2V/0.6VS MDU1516 PU15 ULTRASO-8 PC213 PC211 PC212 RB0540S2 G5616BRZ1U VDDQ_R VTT_MEM(0.6V) 1.2V PC216 PC217 0.1u_10V_X7R_04 VLDOIN VBST SHORT EMR4 10u_6.3V_X5R_06 VDDQ_R SHORT VTT_MEM DRVH PL16 2.2_1%_06 PJ71 BCIHP0730-1R0M PJ70 PC218 VTTGND VDDQ PR340 PCB Footprint = BCIHP0735A *15mil_short...

  • Page 94: Vcore, Vccgt Output Stage

    Schematic Diagrams VCore, VCCGT Output Stage VCORE & VCCGT OUTPUT STAGE PC141 PC140 PC159 PC146 PC142 PC29 PR266 PC154 2.2_06 0.1u_25V_X7R_06 VCORE_R change to VCORE VCORE 2Phase Gary_D02 for BUG solution Gary_D02 Change PC172 footprint INS19909547 MLP08 Gary_D02 PC157 non-stuff COMMON PL10 PR267...

  • Page 95: Vcc_Core, Vccgt

    Schematic Diagrams VCC_Core, VCCGT Intel SKYLAKE IMVP8 POWER CKT - 2+1 PHASE VCORE IMON GT IMON VREF_VCORE Gary_D02 for BUG solution VREF_VCORE PR12 PR221 0_04 0_04 H-line 42 PR220 33.2K_1%_04 PR11 56K_1%_04 10k ntc 100k_1%_04_NTC EWTF02-103F3I-N 1.0V_VCCST PC36 3.3VS 0_04 1.0V_VCCST 1u_6.3V_X5R_04 PR32...
  • Page 96 Schematic Diagrams 1.0DX_VCCSTG/VCCSFR_OC, 3.3VA NOTE: SHORT 1.0DX_VCCSTG PJ15 *1mm 1.0DX_VCCSTG Ton need <65us VCCSFR_OC VCCSFR_OC 1.0DX_VCCSTG M5938 TURON-ON TIME=60us VCCSFR_OC PJ73 SHORT VDD1.0 Gary_Reserved PJ73 VDDQ PJ31 VCCIO VOUT1_U140 VOUT2_U141 VOUT VOUT C249 C464 C468 C192 C191 *10u_6.3V_X5R_06 C441 *10u_6.3V_X5R_06 VDD3 R314 *10u_6.3V_X5R_06...

  • Page 97: Vccsa

    Schematic Diagrams VCCSA VCCSA For CV test PR82 820K_1%_06 PQ24 QM3004M3 PR74 100K_04 VDD3 PC26 PC176 PC177 Modify,3/20 Ken PJ12 *CV-1mm 0.1u_50V_Y5V_06 4.7u_25V_X5R_08 *4.7u_25V_X5R_08 PC30 PR81 10K_04 PJ10 *1mm PR75 0_06 VCCIO_EN EN_PSV 0.1u_10V_X7R_04 PJ11 0_06 SHORT 23,42 VCCIO_PWRGD SHORT BCIHP0730-1R0M VCCSA PR290...

  • Page 98: Ac_In, Charger

    Schematic Diagrams AC_In, Charger PC109 SMART CHARGER V_BAT PQ12 EMB20P03V PR198 VJACK 20K_04 PQ26 Gary_EMI TEST J_DC_JACK1 EML1 EMB20P03V HCB2012KF-800T80 JDC_AC PQ11 *EMB20P03V PRS1 BCIHP-0730 8R2M 0.01_1%_32 PC116 PC117 2DC3003-002211 PC133 PC94 PC93 PC105 PC108 PC92 PRS2 PR176 PC103 PC15 0.01_1%_32 2.2_04 Battery Voltage:...

  • Page 99: Nvvdd

    Schematic Diagrams NVVDD VGA_NVVDD 3V3_RUN 3V3_RUN PR550 PR556 PR548 *1K_04 PR549 *0_04 0_04 0_04 PJ77 *CV-1mm NVVDD_PSI GPU_PWR_VID PR526 PC258 *47p_50V_NPO_04 UP1462_VREF 3.3V PR67 *0_04 PJ78 *CV-1mm 1642_DGPU_ON dGPU_PWR_EN Sheet 50 of 58 *10K_04 PR527 *0_04 dGPU_PWR_EN 26,40,52 Gary_D02 for common design 3V3_MAIN_EN PC125 PR528...

  • Page 100: Fbvddq

    Schematic Diagrams FBVDDQ FBVDDQ PHASE 1 and 2 FBVDDQ FOR N16 VGA PR566 820K_1%_06 PJ81 *CV-1mm PR304 *0_04 PC275 PC272 PC269 PC274 Sheet 51 of 58 PEXVDD_PWRGD GC6 2.0 3.3V PJ82 PU18 PQ53 U160 *CV-1mm MDU1516 PR565 0_04 ULTRASO-8 FBVDDQ 50,52 NVVDD_PWRGD PR564...

  • Page 101: Pex_Vdd/3V3

    Schematic Diagrams PEX_VDD/3V3 PEX_VDD PC279 PC278 PR572 22u_6.3V_X5R_08 10_06 0.1u_10V_X7R_04 PU19 INS25324032 1.05V G5671RE1U DFN10 PR574 10K_04 G5671RE1U PEX_VDD 3.3V PGOOD PEXVDD_PWRGD Gary_D02 DEL PEX_VDD PJ point OpenV Reg PS3_1V05_EN PR573 15K_04 PL22 3V3_RUN BCIHP0420TB-2R2M PS6_VCC_PEXVDD PC281 PC284 PC283 PC277 3/15 PS6_SW_PEXVDD 0.22u_10V_X5R_04...

  • Page 102: Audio Board

    Schematic Diagrams Audio Board *0_04 *0_04 6-71-N8508-D03 USB PORT(PORT9) USB2.0 CON *0_04 *0_04 AC12 *22u_6.3V_X5R_08 AGND A_5V *0_04 *0_04 60 mil A_USBVCC2 0.1u_10V_X7R_04 A_USBVCC2 AGND 60 mil 60 mil AUDIO BOARD Connector VOUT AC10 22u_6.3V_X5R_08 AGND AC18 AC20 CLOSE TO CONNECTOR 10u_6.3V_X5R_06 AJ_USB2 AD37...

  • Page 103: Power Switch Board

    Schematic Diagrams Power Switch Board *0_04 *0_04 6-71-N850S-D03 *0_04 *0_04 POWER SW BOARD *0_04 *0_04 Sheet 54 of 58 Power Switch Board BH_3.3VS BH_3.3VS POWER POWER POWER BUTTON BUTTON BOTTOM 6-53-31500-B41 820_06 820_06 For N850 BSW1 Gary_change for ME T4BJB10BQR 6-13-82001-2AB 6-13-82001-2AB BJ_SW1...

  • Page 104: Hall Sensor Board

    Schematic Diagrams Hall Sensor Board HALL Sensor Board Sheet 55 of 58 H_VDD3 6-02-09249-LC0 OLD Value MH248-ALFA-ESO 6-02-00248-LC2 100K_04 Hall Sensor Board HRN1 HJ_HALL1 H_VDD3 H_LIDSW# H_LID_SW# H_GND H_LID_SW# *10mil_short AH9249NTR-G1 0_8P4R_04 FP226H-004S10M *100p_50V_NPO_04 N85RC_RN *V15AVLC0402 HRN2 H_LID_SW# H_GND H_GND H_GND H_GND H_GND...

  • Page 105: Click Board

    Schematic Diagrams Click Board *0_04 *0_04 6-71-N8502-D04A *0_04 *0_04 *0_04 *0_04 CTP_VCC N87RC_RN 6-20-94K30-108 FP225H-008S11M C_TP_CLK C_CTPBUTTON_L C_TP_DATA C_CTPBUTTON_R C_SMB_CLK C_SMB_DATA CJ_TP3 Sheet 56 of 58 C_GND Click Board CTP_VCC 0.1u_10V_X7R_04 *10u_6.3V_X5R_06 CJ_TP2 N87RC_RN C_GND C_GND C_TP_DATA C_TP_CLK C_SMB_DATA C_SMB_CLK FPC0502-6AW-S-HF 6-20-94K10-006 N87RC_RN...

  • Page 106: Led Board

    Schematic Diagrams LED Board *0_04 *0_04 6-71-N8704-D04 *0_04 *0_04 *0_04 *0_04 6-52-55001-021 GREEN YELLOW HDD LED WLAN LED L_LED_HDD# 220_04 L_3.3VS RY-SP190YG34-5M WLAN ON GREEN YELLOW Windows 7 L_AIRPLAN_LED# Airplane mode 220_04 WLAN OFF L_3.3VS RY-SP190YG34-5M Airplane ON 6-52-55001-021 Windows 8 Airplane OFF WLAN/BLUETOOTH GREEN/YELLOW...

  • Page 107: Power Sequence

    Schematic Diagrams Power Sequence W650RN POWER ON SEQUENCE VDD3 3.372v DD_ON 595.47us 3.367V 3.3V 1.398ms 5.19V VDD5 1.963ms 5.18V 30.459ms 3.348V SLP_SUS# 31.018ms 3.371V 3.3VA 31.333ms 1.054V VDD1.0 81.21963ms 3.368V RSMRST 182.725ms 3.369V PWR_BTN 178.754ms 3.372V SUSC# 33.405us 3.372V SUSB# 98.177 1.214V VDDQ...
  • Page 108 Schematic Diagrams B - 60...

  • Page 109: Updating The Flash Rom Bios

    Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS versions 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files...

  • Page 110: Use The Flash Tools To Update The Bios

    BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “EFI Shell”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by EFI Shell.
