- Page 1 KS-700 Media Station Quick Installation Guide ENGLISH AREC Inc.© All Rights Reserved 2013. l www.arec.com All information contained in this document is Proprietary...
- Page 2 (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation Hereby, AREC Inc., declares that this Media Station is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
- Page 3 KS-700 Quick Installation Guide CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. – the ventilation should not be impeded by covering the ventilation openings with items, such as newspapers,table-cloths, curtains, etc.: –...
-
Page 4: Speci Cations
KS-700 Quick Installation Guide Introduction Featuring a compact and stand-alone design, AREC KS-700 Media Station consists of diverse features and functionality, including multi-signals capturing, recording synchronously, codec, streaming online, multi-channel split screen, live broadcasting, and web-based video switcher, providing complete lecture capture solution. -
Page 5: Product Appearance
KS-700 Quick Installation Guide Product Appearance Front Back Name Brief introduction Remote Control receiver Remote Control receiving area Led light Bluetooth/Record/Power Function key Record/Play/Pause/Stop/Menu/Channel/Preview Layout Select key: Up/Down/Left/Right /Back/OK Power Power on/ off devices USB port Export document by driving USB flash drive into USB port... -
Page 6: Remote Controller
KS-700 Quick Installation Guide Remote Controller Name Brief introduction Power Power on/ off devices Resolution Adjust the output resolution A/B/C/D A：Export the storage device B/C/D：User De ne Prev Index Jump to previous index play Info Display the channel information Next Index... - Page 7 KS-700 Quick Installation Guide Connection AREC CI-200 Network Camera AREC TP-100 projector AREC Auto-Tracking System AM-500 Wireless Speaker Microphone Power Video output VGA / HDMI Audio output Wireless audio receiver Digital I/O Audio input Video input VGA / HDMI eSATA...
- Page 8 KS-700 Quick Installation Guide Connection Name Brief introduction Power Power connection Video input Video input for VGA or HDMI cables. For example: Connected to notebook or document cam. Video output Video output for VGA or HDMI cables. For example: Connected to projector or TV.
- Page 9 KS-700 Quick Installation Guide KS-700 Quick Installation Guide Product setup roduct setup Initial installation Initial installation Step1: Log in Step1: Log in System System Administration, both Administration, both User User Password Password are defaulted as are defaulted as admin. admin.
- Page 10 KS-700 Quick Installation Guide Step4:CH3 and CH4 set network camera input. Go to Discovery page then click Refresh to nd out network camera and Auto-Tracking Mount connection automatically. User may also click Add, then type IP or MAC to connect network camera and Auto-Tracking Mount.
- Page 11 KS-700 Quick Installation Guide Step6: Back to Sensor Setting, go to Video Setting. Click CH3 and CH4 image. Click to connect network camera input. Step7: After setting is nished. Please click Apply. Install successfully, preview screen will appear four divided scene.
- Page 12 KS-700 Quick Installation Guide Step8: Going to Local Storage Setting, then set your storage device. It is recommended to connect brand new hard drive. At initial setup, please format rst. Suggest selecting Enable Local Storage Cycling Record. After setting is nished, please click Apply.
- Page 13 KS-700 Quick Installation Guide Battery Safety Messages Please store the battery at cool and dry places. Please do not randomly discard used batteries; please collect the batteries and drop them at speci c recycling locations. If the product is not used for long periods of time, please remove the batteries from the product.
- Page 14 AREC Inc.© All Rights Reserved 2013. l www.arec.com All information contained in this document is Proprietary Made in Taiwan Version：2013-11 Part Number : 40-70001-A51...
