Page 5: Welcome
Figure 1.1 IQ-MC8 Front Panel 1 Welcome The IQ-MC4 and IQ-MC8 modules connect CTs 4200 and CTs 8200 am- plifiers to the IQ Bus of an IQ Sys- ® , allowing the amplifier to be controlled and monitored via IQ. -
Page 6: Controls, Connectors & Indicators
2 Controls, Connectors & Indicators IQ BUS IQ Bus IQ Bus Output Input Connector Connector Figure 2.1 IQ-MC8 Controls, Connectors and Indicators Page 6 LISTEN BUS PRESET Reset/Preset Switch Input/Output and Listen Bus Preset Connector Indicator IQ-MC Modules IQ ADDRESS DATA Data Indicator... -
Page 7: Installation
3 Installation 3.1 Prepare the IQ-MC Module First, turn off and unplug the amplifier. Set the IQ address switch S1. By giving each IQ component a unique address, it can be individually con- trolled and monitored. Whenever the IQ System wants to send a command to just one IQ component, it first sends its address and then the command down the IQ Bus. -
Page 8: Install The Wiring
3.2 Install the Wiring Connect the IQ-MC module to the IQ system via the IQ Bus. The IQ compo- nents in a IQ Bus loop are wired sequentially. The loop begins and ends with the IQ interface. The output of one IQ component “loops” to the input of the next and so on as shown in Figure 3.2. - Page 9 IQ-MC Modules The following examples show how to connect the MC-IQ to other IQ components: Figure 3.3 RJ-45 Output to Barrier Block Input Figure 3.4 RJ-45 Output to Din Input Figure 3.5 RJ-45 Input to Barrier Block Output Page 9 Reference Manual...
-
Page 10: Adjust System Levels
Figure 3.6 RJ-45 Input to Din Output Figure 3.7 RJ-45 Output to RJ-45 Intput 3.3 Adjust System Levels Adjust attenuator levels both on the amplifier and on the IQ-MC module Page 10 IQ-MC Modules control panels within your IQ soft- ware for optimum system gain. -
Page 11: Operation
In addition, the IQ-MC Load Su- pervision feature has the ability to verify the status of the loads in real time. The IQ-MC module uses Crown’s IQ2 protocol. This makes it possible for a user to design custom graphic display modules to control and moni- tor the unit with IQ2-compatible IQ software. -
Page 12: Iq Bus "Drop Out" Relays
trolled via software or may be pro- grammed to switch when a fail con- dition is present on any channel.* The high-impedance (10 K ohm) AUX input can sense logic signals and can be programmed to activate system mute or report fault condi- tions when a logic high is present. -
Page 13: Amplifier Control And Monitoring
(See Section 4.3.14) * This is assumed to be 70V or the rated 8-ohm output. ** Thermal Headroom on your Crown am- plifier may be labeled Junction Tempera- ture Simulation (JTS). *** See the amplifier’s Reference or Owner’s Manual for more information about JTS and how it works. -
Page 14: Ready/Standby Control
4.3.6 Ready/Standby Control Each channel’s output relay can be independently turned on and off. 4.3.7 Signal Mute The output signal of each channel can be independently muted. This function typically provides 80 dB or more of attenuation. 4.3.8 Polarity Inverter The polarity of the input signal of each channel can be independently inverted. -
Page 15: Signal Processing
Thermal: You can choose to be warned if the thermal level rises above a predetermined level. The Threshold control lets you set the thermal level above which an error message will be reported. The range is from 1 to 100%. Fault: You can choose to be warned when an amplifier “fault”... -
Page 16: Load Supervision
On/Off: Turns the limiter on or off. Average Power Threshold: The threshold is adjustable from 10 to 1000 watts.** Nominal Load Impedance: The nominal load impedance is settable from 1 to 1000 ohms, and should be set to correspond to the nominal impedance rating of the load con- nected to the respective channel. -
Page 17: Iq Audio In Depth
Crown’s IQ System with special guides to aid in the installation and use of the IQ-MC module. For more information about any of these topics, contact Crown Technical Support. 5.1 A Closer Look at IQ Bus Wiring The IQ-MC module must be con-... -
Page 18: Using The Aux Connector
Pins 2 and 5 are used to receive a signal and pins 3 and 4 are used to send a signal. * Because typical mic cables have high ca- pacitance, the maximum possible Crown Bus loop distance will be less. Reference Manual... -
Page 19: Aux Output
5.2.1 AUX Output When the auxiliary feature is turned on by the IQ for Windows software +15 VDC is supplied across pins 3 (ground) and 4 (+). A total of 70 milliamps of current is available. The smart switch mosfet protects against shorts (see Figure 5.1). -
Page 20: Aux Input
Page 20 IQ-MC Modules Figure 5.4 demonstrates how mul- tiple amplifiers can be monitored using the Listen Bus. Crown’s IQ for Windows software allows you to se- lect the amplifier and channel you wish to monitor. Amp 1 Amp 2 Figure 5.4 Multiple-Amp... -
Page 21: Load Supervision
Make sure you use the ap- propriate crimping tool and verify that the connector is properly seated into the tool, or damage will result. Contact Crown Technical Support for additional information about working with RJ-11 and RJ-45 connectors. 5.5 Load Supervision... -
Page 22: Typical Load Characteristics To Know And Understand
This procedure should work well for most applications. However, some applications can be a little more difficult. Some very low-level and/or low duty-cycle signals may not ad- equately “test” the load. Lab and situation testing have shown output levels as small 40 dB below rated amplifier output to be enough for most low-impedance loads. -
Page 23: Specifications
Ca- pable of 80,000 writes minimum. * If address “0” is selected, the MC-IQ will operate in stand-alone mode. In this mode, the Crown bus port is deactivated. Reference Manual IQ-MC Modules IQ Bus Data Communication... -
Page 24: Iq Address Tables
7 IQ Address Tables The following pages in this section contain lookup tables for every valid IQ address. The valid addresses are 1 to 250. Remember that address “0” (zero) will put the IQ-MC into a stand- alone mode where it is invisible to the IQ System and acts like a “dumb”... - Page 25 IQ-MC Modules Figure 7.1 IQ Address Switch (S1) Settings from 0 through 83 Page 25 Reference Manual...
- Page 26 IQ-MC Modules Figure 7.1 IQ Address Switch (S1) Settings from 84 through 167 Page 26 Reference Manual...
- Page 27 IQ-MC Modules Figure 7.1 IQ Address Switch (S1) Settings from 168 through 250 Page 27 Reference Manual...
-
Page 28: Service
Crown factory. For warranty service, we will pay for ground shipping both ways in the United States. -
Page 29: Warranty
ORIGINAL PURCHASER and ANY SUBSEQUENT OWNER of each NEW Crown product, for a period of three (3) years from the date of purchase by the original purchaser (the “warranty period”) that the new Crown product is free of defects in materials and workmanship. - Page 30 No person has the authority to enlarge, amend, or modify this Crown Warranty. This Crown Warranty is not extended by the length of time which you are deprived of the use of the new Crown product. Repairs and replacement parts provided under the terms of this Crown Warranty shall carry only the unexpired portion of this Crown Warranty.
