Table of Contents
1. SPECIFICATION & PARTS IDENTIFICATION .............................................................................2
2. OPERATION & FUNCTION OF PARTS....................................................................................2, 3
3. LOCATION REQUIREMENTS...................................................................................................3, 4
4. INSTALLATION PROCEDURES ..................................................................................................4
5. STORAGE.................................................................................................................................4
6. CLEANING ..............................................................................................................................5
7. TROUBLESHOOTING GUIDE............................................................................................5, 6, 7
8. WIRING DIAGRAM...............................................................................................................7
9. EXPLODED VIEW & SERVICE PARTS LIST
A. B9A........................................................................................................................................8, 9
B. B9B....................................................................................................................................10, 11
Please read the following safety precaution before servicing the watercooler.
1) Check if an electric leakage occurs in the appliance.
2) To prevent electric shock, unplug prior to servicing.
3) In case of testing with power on, wear rubber gloves to prevent electric shock.
4) When using an instrument or replacing a part for repairing, check it is applied to rated voltage
current and capacity.
5) Prevent water from flowing into electric elements in mechanical parts.
6) When carrying or tilting the appliance, remove all the objects on it.
7) If the cooling cycle is out of order, contact nearest authorized service center for maintenance,
repair and adjustment.
TABLE OF CONTENTS
FOR YOUR SAFETY
- 1 -
Advertisement
Table of Contents
Related Manuals for Clover b9a
Summary of Contents for Clover b9a
-
Page 1: Table Of Contents
6. CLEANING ....................……………………….5 7. TROUBLESHOOTING GUIDE................………..…5, 6, 7 8. WIRING DIAGRAM…………………………............………..……..7 9. EXPLODED VIEW & SERVICE PARTS LIST A. B9A............................8, 9 B. B9B............................10, 11 FOR YOUR SAFETY Please read the following safety precaution before servicing the watercooler. 1) Check if an electric leakage occurs in the appliance. -
Page 2: Specification & Parts Identification
1. SPECIFICATION & PARTS IDENTIFICATION MODEL B9A(HOT & COLD) B9B(COOK & COLD) DIMENSION 290W×398D×460H(mm) WEIGHT 13.5kg 12.5kg CONSUMPTION 105W TEMP CONTROL AUTO COLD TANK Stainless Steel CAPACITY 2.7 ℓ/h (10℃) CONSUMPTION 465W PROTECTOR Heat Limiter TEMP. CONTROL Hot Control TANK... -
Page 3: Cooling Operation
A. Cooling Operation The vapor refrigerants that compressed to high temperature & high pressure conditions in the compressor, turn into liquid refrigerant of high temperature and high pressure passing through the condenser, and then turn into the liquid refrigerants of low temperature and low pressure conditions by passing through the capillary tubes. The liquid refrigerant of low temperature &... -
Page 4: Installation Procedures
D. Coolers are for indoor use only. Keep away from direct sunlight and excessive moisture. E. Avoid harmful gas or excessive heat. 4. INSTALLATION PROCEDURES A. Install drip tray below faucet. B. Thoroughly clean the cooling tank and baffle. Baffle must be in exact place for proper cooling operation. CAUTION: IF THE COLD WATER BAFFLE IS REMOVED, COLD WATER WILL NOT BE FORMED NOR DISCHARGED. -
Page 5: Troubleshooting Guide
C. Remove faucets from the product. Both faucets are disassembled by turning them counter clockwise. D. Wear disposable gloves (clean and safe material for drinking water). E. Wash the faucets, drip tray with mild soap and water. Then, rinse them with clean water immediately. F. - Page 6 It is normal for the cooler to run The ambient temperature is high. continuously at high ambient temperatures. If refrigerant leak is suspected, return C. The cooler There has been a substantial loss in the cooler to authorized service center or compressor runs sealed system's charge of refrigerant.
-
Page 7: Wiring Diagram
assembly. The dual float valve’s packing is defective. Replace the dual float valves packing. Properly connect and replace the cold The cold water piping is defective. water piping. NON SPILL SYSTEM User has taken a large draw or series of Wait until the cold water tank is filled with draws and reservoir has not yet refilled. - Page 8 - 8 -...
- Page 9 - 9 -...
- Page 10 - 10 -...
- Page 11 - 11 -...
