  • Page 1 1

...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SPECIFICATION & PARTS IDENTIFICATION ................2 OPERATION & FUNCTION PARTS..................3, 4 A. Cooling Operation B. Function of Parts LOCATION REQUIREMENTS.......................4 INSTALLATION PROCEDURES ....................5 STORAGE.......................……………………..5 CLEANING ....................……………………….6 7. TROUBLESHOOTING GUIDE................………..…..7, WIRING DIAGRAM…………………………............………..……..9 9. EXPLODED VIEW & SERVICE PARTS LIST C12E..........................10, FOR YOUR SAFETY Please read the following safety precaution before servicing the watercooler.

  • Page 3: Identification

    4) When using an instrument or replacing a part for repairing, check it is applied to rated voltage current and capacity. 5) Prevent water from flowing into electric elements in mechanical parts. 6) When carrying or tilting the appliance, remove all the objects on it. 7) If the cooling cycle is out of order, contact nearest authorized service center for maintenance, repair and adjustment.

  • Page 4: Parts

    2. OPERATION & FUNCTION OF PARTS 4

...

  • Page 5: Cooling Operation

    A. Cooling Operation The vapor refrigerants that compressed to high temperature & high pressure conditions in the compressor, turn into liquid refrigerant of high temperature and high pressure passing through the condenser, and then turn into the liquid refrigerants of low temperature and low pressure conditions by passing through the capillary tubes.

  • Page 6: Procedures

    4. INSTALLATION PROCEDURES A. Connect the 1/4”OD tubing between water inlet of chiller and the supply water hose with pressure rating suitable for use with the application. The tubing must be acceptable for use with potable water. B. Using the 1/4”OD tubing included with the (gooseneck) faucet, connect on water outlet of chiller. -Flush water in lines before installing gooseneck faucet.

  • Page 7: Cleaning

    TROUBLE POSSIBLE CAUSE REMEDY REFRIGERATION SYSTEM No electric power to outlet. Turn on electric power outlet. The thermostat is misadjusted or Adjust or replace the thermostat, as defective. necessary. The wires leading to the thermostat are Check the internal wiring. defective or are not connected.
  • Page 8 thermostat may be defective. Replace the thermostat. short running cycle. It The thermostat is improperly set for the is cooling, but does not prevailing environmental conditions and Adjust the thermostat. run long enough to cooler usage. The compressor motor is defective, Replace the compressor.
  • Page 9 9

...
  • Page 10 10

...
