- Page 1 GLAM LASER PROFESSIONAL LASER USER MANUAL Thank you for using our products. For the sake of safety and better operation of this product, please read this manual carefully before using and operating it.
-
Page 2: General Safety Instructions
Before any first use, unpack the set and make sure there was no damage during transport. Check for missing any part supplied with the laser: 1 x GLAM LASER 1 x POWER CABLE 1 x USER MANUAL GENERAL SAFETY INSTRUCTIONS This fixture must be earthed to in order to comply with the safety regulations and to avoid any electrical shock. -
Page 3: Installation Of The Unit
SAFETY INTRUCTIONS FOR LASERS According to EN/IEC 60825-1 regulations, this laser is classified under 3B class. Direct eye exposure can be dangerous DANGER: LASER RADIATION! UNIT UNDER 3 B CLASS AVOID DIRECT EYE EXPOSURE. LASER RADAITION CAN CAUSE EYE DAMAGE AND/OR SKIN DAMAGE AVOID EXPOSTION TO LASER RADIATION ALL PROTECTIVE MEASURES MUST BE APPLIED FOR MAKING THE USE OF LASERS SAFE This product is a so-called show laser emitting radiation with a wavelength spectrum and producing lasers for shows. -
Page 4: Specifications
SPECIFICATIONS Voltage : 230V/50Hz Fuse : 2A/250V Rated Power : 50W Scanner : High speed optical scanner, big angle scanning Laser : Green 532 nm / 100 mW Red 650 nm / 200 mW Purple : 405 nm /200 mw Working modes : DMX 512 (12 CH), Sound activation, Auto-beam, Auto-animation, Master/Slave, PC control Graphics &... -
Page 5: Function Settings
DMX Control Parameters Chart Channel Function Value Description 0～49 Sound Active mode 50～99 Auto-Beam mode Mode 100～149 Auto-Animation mode 150～199 Manual mode to Auto run 200～255 Manual mode to Sound Active run AL-100: closed~no blanking~moving blanking~flash blanking~blanking Dimmer AL-600RGY: closed~red~green~yellow~ 0～255 fixed color~random single color~random three-color~moving three-color~fixed color... -
Page 6: Operation
DMX ADDRESS CALCULATION In DMX mode, the DIP switch from # 1 to # 9 should be set to record a DMX address. The address ranges from 1-511. Each dipswitch represents a binary value. Please refer to table below. Dipswitch VALUE Dipswitch VALUE... -
Page 7: Troubleshooting
UNIVERSAL DMX MODE This mode allows you to use the DMX 512 console to operate your devices. Install the unit in a suitable and stable position. Use an XLR cable to connect devices together. Taken at the rear of the unit Assign a DMX address for each device using the DIP switch.
