Sharp QT-CD111 Service Manual page 24

QT-CD111/111C
NO. PART CODE
INTEGRATED CIRCUITS
IC1 VHILA1186N/-1
IC2 VHILA1805//-1
IC101 VHIBA3311L/-1
IC202 VHILA4597//-1
IC203 VHIKIA7808P-1
IC701 RH-IX0105AWZZ
IC801 VHILA9241M/-1
IC802 VHILC78623D-1
IC804 VHIBA5914FP-1
TRANSISTORS
Q351 VSS8050D///-1
Q740 VS2SC1815GR-1
Q804 VSS8050D///-1
Q805 VSS9012H///-1
DIODES
D1 VHD1N4148//-1
D101~103 VHD1N4148//-1
D201 VHD1N4148//-1
D308,309 VHD1N4148//-1
D651~654 VHD1N4004//-1
!
D740,741 VHD1N4148//-1
D802 VHD1N4148//-1
ZD801 VHEMTZJ5R6B-1
FILTERS
CF1 RFILF0001SJZZ
CF2 RFILA0001SJZZ
F1 RFILR0001SJZZ
TRANSFORMERS
T1 RCILI0001SJZZ
T2 RCILI0002SJZZ
T3 RCILI0003SJZZ
T601 RTRNP0001SJZZ
!
COILS
L1 RCILR0001SJZZ
L2 RCILB0001SJZZ
L3 RCILA0001SJZZ
L4 RCILB0002SJZZ
L301 RCILB0003SJZZ
L801 VP-DHR82K0000
L802 VP-DHR68K0000
VARIABLE RESISTORS
VR1 RVR-M0001SJZZ
VR201 RVR-B0001SJZZ
VARIABLE CAPACITORS
VC1~4 RVC-R0001SJZZ
VIBRATORS
X701 RCRM-0001SJZZ
XL801 RCRM-0002SJZZ
CAPACITORS
C2 VCKYPA1HB102K
C4 VCCCPA1HH220J
C5 VCCCPA1HH330J
C6 VCCRPA1HH150J
C8 VCCCPA1HH4R0C J
C9 VCKYPA1HB472K
C10 VCKYPA1HF223Z
C11 VCKYPA1HB221K
C14,15 VCKYPA1HF223Z
PRICE
DESCRIPTION
RANK
J AE FM Front End,LA1186N
J AM FM/AF IF MPX.,LA1805
J AK REC./P.B.Equalizer Amp.,
BA3311L
J AH Power Amp.,LA4597
J AH Voltage Regulator,KIA7808P
J BA System Microcomputer,
IX0105AW
J AS Servo Amp.,LA9241M
J AY Servo/Signal Control,LC78623D
J AN Focus/Tracking/Spin/Slide
Driver,BA5914FP
J AC Silicon,NPN,8050 D
J AB Silicon,NPN,2SC1815 GR
J AC Silicon,NPN,8050 D
J AC Silicon,PNP,9012 H
J AA Silicon,1N4148
J AA Silicon,1N4148
J AA Silicon,1N4148
J AA Silicon,1N4148
J AB Silicon,1N4004
J AA Silicon,1N4148
J AA Silicon,1N4148
J AD Zener,5.6V,MTZJ5.6B
J AD FM IF
J AD AM IF
J AD FM Band Pass Filter
J AD FM IF
J AD FM Detection
J AD AM IF
J AP Power
J AB FM RF
J AE OSC,FM
J AD AM Bar Antenna
J AC OSC,AM
J AD OSC,Bias
AC 0.82 µH,Choke
J
0.68 µH
J
J AC 6.8 kohms (B),Semi-VR [VCO]
J AE 20 kohms (B),Semi-VR [Volume]
J AK Variable Capacitor with Trimmer
(TC1~4)
J AD Ceramic,4 MHz
J AE Ceramic,16.93 MHz
AA 0.001 µF,50V
J
J AA 22 pF (CH),50V
J AA 33 pF (CH),50V
J AA 15 pF (RH),50V
AA 4 pF (CH),50V
AB 0.0047 µF,50V
J
AB 0.022 µF,50V
J
J AA 220 pF,50V
AB 0.022 µF,50V
J
NO. PARTS CODE
C16 VCKYPA1HB472K
C17 VCKYPA1HF223Z
C20,21 VCKYPA1HF223Z
C22 VCKYPA1HB392K
C23 VCKYPA1HF103Z
C24 VCKYPA1HB471K
C25 RC-GZA335AF1H
C26 RC-GZA226AF1C
C27 RC-GZA335AF1H
C28 VCQSMV1HS152J J
C29 RC-GZA106AF1C
C31,32 VCTYPA1CU223M J
C33~35 RC-GZA105AF1H
C36 VCKYPA1HF223Z
C37 RC-GZA227AF1A
C38,39 VCKYPA1HF223Z
C105,106 VCKYPA1HB182K
C107,108 VCKYPA1HB821K
C109,110 VCKYPA1HB271K
C111,112 VCKYPA1HB331K
C113,114 RC-GZA476AF1C
C115,116 VCQYKA1HM183K J
C117,118 RC-GZA106AF1C
C119 RC-GZA225AF1H
C120 RC-GZA476AF1C
C121,122 VCKYPA1HF103Z
C123 RC-GZA107AF1A
C213~216 VCQYKA1HM393K J
C217,218 VCKYPA1HB392K
C219,220 VCQYKA1HM473K J
C221,222 VCKYPA1HB102K
C223,224 RC-GZA107AF1A
C225 RC-GZA227AF1E
C226 VCKYPA1HF223Z
C227 RC-GZW338AF1E
C229,230 RC-GZA107AF1A
C231,232 VCQYKA1HM104K J
C233,234 RC-GZA477AF1A
C301,302 VCKYPA1HF223Z
C351 VCQYKA1HM222K J
C352 RC-GZA227AF1C
C353 VCQYKA1HM223K J
C354 VCQYKA1HM562K J
C651~654 VCKYPA1HF223Z
C701,702 VCKYPA1HF223Z
C704 RC-GZA107AF1A
C705 VCKYPA1HF223Z
C740 VCKYPA1HF103Z
C741 RC-GZA335AF1H
C801 VCKYPA1HF103Z
C802 RC-GZA476AF1C
C803 RC-GZA104AF1H
C804 VCKYPA1HB102K
C805,806 VCTYPA1CU333M J
C807 RC-GZA104AF1H
C808 VCTYPA1CU683M J
C809 VCTYPA1CU473M J
C810 VCKYPA1HB181K
C811 VCTYPA1CU104M J
C812 VCKYPA1HB331K
C813 VCTYPA1CU104M J
C814 VCTYPA1CU103M J
C815 VCKYPA1HB472K
C816 VCKYPA1HB102K
C817 RC-GZA474AF1H
C818 RC-GZA105AF1H
C819 RC-GZA476AF1C
C820 VCKYPA1HB332K
C821 RC-GZA105AF1H
C822 VCKYPA1HB221K
C830 VCCCPA1HH2R0C J
C831 VCKYPA1HB272K
C832 VCCCPA1HH270J
C833 VCKYPA1HB102K
C834 VCTYPA1CU333M J
C835 RC-GZA104AF1H
C837 RC-GZA106AF1C
C838 VCTYPA1CU103M J
C839 RC-GZA105AF1H
C840 RC-GZA334AF1H
C841,842 VCTYPA1CU473M J
C843 RC-GZA107AF1A
– 1 –
PRICE
DESCRIPTION
RANK
AB 0.0047 µF,50V
J
AB 0.022 µF,50V
J
AB 0.022 µF,50V
J
AA 0.0039 µF,50V
J
AB 0.01 µF,16V
J
J AA 470 pF,50V
AB 3.3 µF,50V,Electrolytic
J
AB 22 µF,16V,Electrolytic
J
AB 3.3 µF,50V,Electrolytic
J
AB 0.0015 µF,50V,Styrol
AB 10 µF,16V,Electrolytic
J
AB 0.022 µF,16V
AB 1 µF,50V,Electrolytic
J
AB 0.022 µF,50V
J
AB 220 µF,10V,Electrolytic
J
AB 0.022 µF,50V
J
J AB 1800 pF,50V
J AA 820 pF,50V
J AA 270 pF,50V
J AA 330 pF,50V
AB 47 µF,16V,Electrolytic
J
AB 0.018 µF,50V,Mylar
AB 10 µF,16V,Electrolytic
J
AB 2.2 µF,50V,Electrolytic
J
AB 47 µF,16V,Electrolytic
J
AB 0.01 µF,16V
J
AB 100 µF,10V,Electrolytic
J
AB 0.039 µF,50V,Mylar
AA 0.0039 µF,50V
J
AB 0.047 µF,50V,Mylar
AA 0.001 µF,50V
J
AB 100 µF,10V,Electrolytic
J
AB 220 µF,25V,Electrolytic
J
AB 0.022 µF,50V
J
AG 3300 µF,25V,Electrolytic
J
AB 100 µF,10V,Electrolytic
J
AB 0.1 µF,50V,Mylar
AC 470 µF,10V,Electrolytic
J
AB 0.022 µF,50V
J
AA 0.0022 µF,50V,Mylar
AB 220 µF,16V,Electrolytic
J
AB 0.022 µF,50V,Mylar
AA 0.0056 µF,50V,Mylar
AB 0.022 µF,50V
J
AB 0.022 µF,50V
J
AB 100 µF,10V,Electrolytic
J
AB 0.022 µF,50V
J
AB 0.01 µF,16V
J
AB 3.3 µF,50V,Electrolytic
J
AB 0.01 µF,16V
J
AB 47 µF,16V,Electrolytic
J
AB 0.1 µF,50V,Electrolytic
J
AA 0.001 µF,50V
J
AB 0.033 µF,16V
AB 0.1 µF,50V,Electrolytic
J
AB 0.068 µF,16V
AB 0.047 µF,16V
J AA 180 pF,50V
AB 0.1 µF,16V
J AA 330 pF,50V
AB 0.1 µF,16V
AE 0.01 µF,16V
AB 0.0047 µF,50V
J
AA 0.001 µF,50V
J
AA 0.47 µF,50V,Electrolytic
J
AB 1 µF,50V,Electrolytic
J
AB 47 µF,16V,Electrolytic
J
AA 0.0033 µF,50V
J
AB 1 µF,50V,Electrolytic
J
J AA 220 pF,50V
AA 2 pF (CH),50V
AA 0.0027 µF,50V
J
J AA 27 pF (CH),50V
AA 0.001 µF,50V
J
AB 0.033 µF,16V
AB 0.1 µF,50V,Electrolytic
J
AB 10 µF,16V,Electrolytic
J
AE 0.01 µF,16V
AB 1 µF,50V,Electrolytic
J
AA 0.33 µF,50V,Electrolytic
J
AB 0.047 µF,16V
AB 100 µF,10V,Electrolytic
J
