Sharp QT-CD111 Service Manual page 15

SW601 M601
TAPE MAIN TAPE MOTOR
(241-7) (241-6)
YL
BR
(211)
BATTERYS
DC12V["D"SIZE(UM/SUM-1,
R20 or HP2)battery 8]
PICK UP UNIT
5 4 3 2 1
8 7 6 5 4 3 2 1
FM ROD ANTENNA(213)
7 8
SP502
R-CH
CNS201
WH
1
BK
2
RD
3
ERASE HEAD
CNS101
BK BK
4
WH
3
RD
2
BK
1
TERMINAL PWB-A3
(236)
D654
CD MOTOR PWB-B
-
+
SPENDLE MOTOR
M701
SLED MOTOR
9
Figure 15 WIRING OF P.W.BOARD (2/2)
– 15 –
SPEKERS
SP501
L-CH
TAPE
RECORD/PLAYBACK
(241-5) HEAD(241-4)
BK
TRANSFORMER
C653
D653
D652
C652
C654 2
1
D651 CNS602
C651
6
5
PICKUP IN
4
3
2
1
-
M702 +
10 11
QT-CD111/111C
COLOR TABLE
BR BROWN
RD(R) RED
OR ORANGE
YL YELLOW
GR GREEN
BL BLUE
VL
VIOLET
GY GRAY
WH(W) WHITE
BK BLACK
PK PINK
T601
POWER
RD
RD
SO651
AC SOCKET
AC 120V
60Hz
OR
OR
12
