Description of
the tumble dryer
Front side

Control panel

2 3 4
Control panel
Drum
Filter
Serial number
and model
number
5 6 7
Programme selection knob
Rear side
Rating Plate
Caution, high
temperature
8 9 10
595
Options
buttons and
indicator lights
with OFF
Start/Pause
button
and indicator light
Air inlet
Connection for
ventilation hose
11 12 13
Drying phase
or Delay timer
indicator lights
Maintenance
indicator lights
