GB AWO 10561
A. "Door locked" indication -
When the blue lamp lights up, the
door cannot be opened -
This washing machine is equipped with
automatic safety functions which detect
and diagnose faults at an early stage and
react appropriately:
B. "Clean filter" indication
C. "Water tap closed" indication
Main Care
programmes Labels
/
Cotton (Anti-bacterial)
Synthetics
Daily load
Quick wash (30 min)
Delicate
Wool
Handwash (Lingerie)
Short spin —
Spin —
—
Rinse + Spin +
— —
Drain
: optional / Yes : dosing required
1)
For improved garment care spin speed is restricted to 800 rpm in this programme.
2)
For improved garment care spin speed is restricted to 400 rpm in this programme.
Black process 45.0° 100.0 LPI
PROGRAMME CHART
A
B
I D
th
6 Sense intelligent technology always guarantees perfect results with maximum efficiency whatever the
wash load.
Type of wash/Notes
Normally to heavily soiled bed linen, table linen and underwear, towels, shirts
etc. made of cotton, coloured cotton and linen.
For temperature selection, please respect the manufacturer's recommendation
on the care label. At a temperature of 80°C or more, this programme
eliminates bacteria, ensuring sanitization of your laundry. The bacteria removal
efficiency has been tested following a similar methodology to the NF EN 13697
standard of Nov. 2001.
With heavily soiled laundry the additional "Prewash" option can be selected as well.
Normally to heavily soiled blouses, shirts, overalls etc. made of polyester
(Diolen, Trevira), polyamide (Perlon, Nylon) or blends with cotton.
Slightly to normally soiled textiles made of cotton and/or synthetics.
Shortly worn outer clothing made of cotton, polyester, polyamide and blends
with cotton.
Curtains and delicate clothing, dresses skirts, shirts and blouses.
Only woollens with a felt-free finish, labelled with the woolmark and identified
as machine washable.
If you select "Rinse Hold" do not leave items to soak for too long.
Textiles made of silk, linen, wool and viscose marked as "handwashable".
This cycle is particularly suitable to treat delicate lingerie (use of a laundry net
strongly recommended).
If you select "Rinse Hold" do not leave items to soak for too long. A very gentle spin
is used in this programme.
In this programme spinning is gentle. Same as the spin cycle in the "Wool"
programme.
In this programme spinning is intensive. Same as the spin cycle in the "Cotton"
programme.
Same as the last rinse and the final spin in the "Cotton" programme.
Drain only - no spinning. Alternative method of terminating programme after "Rinse
Hold".
E
C
L K G
Max Detergents and additives
Load
Prewash Main Softener Start
Wash
kg
6.0 Yes
2.5 Yes
—
3.0 Yes
—
3.0 Yes
1.5 Yes
1.0 — Yes
—
1.0 Yes
1.5 — — —
6.0 — — —
— —
6.0
— — —
—
D. "On/Off" button
H
E. "Start/Pause" button
F. Display
G. Temperature selection buttons
H. Spin speed selection button
I. "Reset" button
J. "Start delay" button
K. "Favourites" button
L. Programme selection button
Programme Sequence Indicators (on display)
F J
prewash main rinse
wash
Special options
7 kg Easy Prewash Intensive Rinse
delay Ironing Rinse Hold
—
— —
— —
— — —
— — — —
— — — —
— — — — —
— — — — —
—
—
— — — — — —
Whirlpool is a registered trademark of Whirlpool USA
5019 301 05804
+/-
rinse spin
stop
Max Tempe-
Spin rature
Speed
rpm °C
1200 20 to 95
1)
20 to 60
800
1200 30 to 60
1200 20 to 30
1)
20 to 40
800
1)
20 to 40
800
2)
20 to 40
400
1)
—
800
1200 —
—
1200
— —
