Kingsman MCVP42N Installation Instructions Manual

Zero clearance vented gas fireplace
Hide thumbs Also See for MCVP42N:
Table of Contents

Advertisement

Quick Links

Installation Instructions
Model Numbers:
MCVP42N, MCVP42NE, MCVP42LP, MCVP42LPE
ANSI Z21.50-2014 • CSA 2.22-2014
ZERO CLEARANCE VENTED GAS FIREPLACE
Model Numbers:
MCVP42NH, MCVP42NHE, MCVP42LPH, MCVP42LPHE
ANSI Z21.88-2014 • CSA 2.33-2014
ZERO CLEARANCE VENTED GAS FIREPLACE HEATER
Certified to:
Certified to:
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
For Propane Horizontal installations the
venting must be an additional one foot
above the minimum vertical rise off the flue
This appliance may be installed in an
aftermarket, permanently located,
manufactured home (USA only) or mobile
home, where not prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
before going horizontal.
ATRIUM
A Division of R-Co. Inc.
2340 Logan Ave.
Winnipeg, Manitoba Canada
R2R 2V3 Ph.: (204) 632-1962
Printed in Canada January 22, 2015
Part# 42MCVP-MAN14

Advertisement

Table of Contents
loading

Related Manuals for Kingsman MCVP42N

Summary of Contents for Kingsman MCVP42N

  • Page 1 Installation Instructions Model Numbers: MCVP42N, MCVP42NE, MCVP42LP, MCVP42LPE Certified to: ANSI Z21.50-2014 • CSA 2.22-2014 ATRIUM ZERO CLEARANCE VENTED GAS FIREPLACE Model Numbers: MCVP42NH, MCVP42NHE, MCVP42LPH, MCVP42LPHE Certified to: ANSI Z21.88-2014 • CSA 2.33-2014 ZERO CLEARANCE VENTED GAS FIREPLACE HEATER...

  • Page 2: Table Of Contents

    Table of Contents INFORMATION Table of Contents…………………………………………………………………………………………………………... Glass Safety / Termination Cap Safety- All Units……………………………………………………………………………... Warnings, Installations, and Operations……………………………………………………………………………………….. Pre-installation Questions and Answers……………………………………………………………………………………….. Operating Instructions……………………………………………………………………………………………………………. Recommendations for Finishing of Clean View Installations…………………………………………………………..Mobile Home/Manufactured Housing Installation…………………………………………………………………………….. MCVP42 INSTALLATION Framing- Nailing Tab Guide……………………………………………………………………………………………………... Framing Your Gas Fireplace……………………………………………………………………………………………………..
  • Page 3 IPI SECTION IPI Electronic Ignition System……………………………………………………………………………………………... Remote Control Operation………………………………………………………………………………………………………. IPI Electronic Ignition Parts List – Standard System…………………………………………………………………………. Configuration 1: Basic Manual Hi / Lo and manual Off………………………………………………………………………. Configuration 2: Remote On / Off and manual Hi / Lo……………………………………………………………………….. Operating the Receiver Without Batteries For GT / EGT / GTM / EGTM Remote Controls……………………………… Configuration 3: Remote ON/OFF, Variable HI/LO, and Fan………………………………………………………………...

  • Page 4: Glass Safety / Termination Cap Safety- All Units

    -Glass Safety- All Units IT IS THE RESPONSIBILITY OF THE HOME OWNER TO ENSURE THAT NO ONE TOUCHES A HOT APPLIANCE. If the barrier becomes damaged, the barrier shall be replaced with the manufacturer’s barrier for this appliance. Any safety screen, guard, or barrier removed for servicing the appliance, must be replaced prior to operating the appliance.

  • Page 5: Warnings, Installations And Operations

    Warnings, Installations and Operations Installation Regulations This gas appliance must be installed by a qualified installer in accordance with local building codes, or in the absence of local codes, with the current CAN/CSA-B149.1 or .2 Installation Code (in Canada) or the current National Fuel Gas Code Z223.1- NFPA 54 when installed in the United States. This appliance, when installed, must be electrically connected and grounded in accordance with local codes, or in the absence of local codes, with the current CSA C22.1 Canadian Electrical Code or with the National Electrical Code;...
  • Page 6  Gas fired appliances may be used only for supplemental heat and/or decorative purposes and under no circumstances shall they provide a primary heat source.  This appliance must not be connected to a chimney flue serving a separate solid-fuel burning appliance. NOTE: It is recommended that a Carbon Monoxide (CO) Detector be installed in or near bedrooms and on all levels of your home.

  • Page 7: Pre-Installation Questions And Answers

    Pre-installation Questions and Answers About curing of the paint Your stove or fireplace has been painted with the highest quality silicone stove paint. This paint dries quickly in 15-20 minutes when first applied at the factory. However, due to the high temperature silicone components, the paint will cure when heat is applied to the appliance as it is first used.

  • Page 8: Recommendations For Finishing Of Clean View Installations

    Recommendations for Finishing of Clean View Installations When finishing the wall around the fireplace, it is critical that the wall covering be fastened properly. It is acceptable to pre-drill holes and use self-tapping screws which may be used to fasten a backer for tile, marble, etc. Screws being installed through non-combustible board should be self-tapping type with a maximum length of 2 inches.

  • Page 9: Mobile Home/Manufactured Housing Installation

    Mobile Home/Manufactured Housing Installation This Direct Vent System Appliance must be installed in accordance with the manufacturer’s installation instructions and the Manufactured Home Construction and Safety Standard Title 24 CFR, Part 3280, or the current Standard for Fire Safety Criteria for Manufactured Home Installations, Sites, and Communities ANSI/NFPA 501A, and with CAN/CSA Z240 MH Mobile Home Standard in Canada.

  • Page 10: Framing- Nailing Tab Guide

    MCVP42 Framing- Nailing Tab Guide [Qty] 4 Nailing Tabs are located on flue side of fireplace. These Nailing Tabs can be used in two ways: 1/2” Drywall Flush with Face of Fireplace – Framing Flush with Face of Fireplace -Fireplace to be covered Fireplace and Combustible Wall to be covered with Non-Combustibles (e.g.

  • Page 11: Framing Your Gas Fireplace

    MCVP42 Framing Your Gas Fireplace This section is intended for qualified installers only. Before beginning, make note of where the gas and electrical accesses are located on the unit. This will streamline the construction process. Furthermore, familiarize yourself with the venting and clearance requirements (see Venting section) for this appliance.

  • Page 12: Locating Your Appliance / Fireplace Dimensions

    MCVP42 Locating Your Appliance See Mantel Leg Clearances Instruction for the proper placement of fireplace. PENINSULA ISLAND ALL UNITS MAY BE VENTED VERTICALLY MCVP42 Fireplace Dimensions...

  • Page 13: Framing Dimensions

    MCVP42 Framing Dimensions These structures are not load bearing. Optional- floor cutout for gas line if Framed fireplace opening. coming up through floor. TOP VIEW Vent Framing (Vertical or Horizontal) Vertical Venting MUST maintain 1” clearance to combustibles. 9” Round Hole through Masonry. 12”...

  • Page 14: Facing Requirements

    MCVP42 Facing Requirements Required Non-Combustible Areas NOTE: MATERIALS COVERING THE FACE OF THE FIREPLACE MUST BE NON-COMBUSTIBLE Note: Do not drive excessively long screws into the face of the unit as internal parts may be damaged. Combustibles (i.e. Drywall) may be installed flush with top of Fireplace. Side facing to be installed to standoffs only.

  • Page 15: Basic Finishing Mcvp42

    Basic Finishing MCVP42 Step One: Frame Fireplace with nailing tabs oriented as Step Two: Use Drywall to finish face of wall. shown. NOTE: Drywall will be flush with fireplace face. Drywall Fireplace Frame Nailing Tab Step 3: A brick, tile, or other non-combustible border may be applied over fireplace face to conceal border.

  • Page 16: Mantel Clearances

    MCVP42 Mantel Clearances Before installing any mantels it is important to determine the combustibility of its material(s). There are two types of mantels to consider: Combustible and Non-Combustible. A Combustible Mantel is one that consists of material(s) that may discolor, combust, or lose its integrity in the presence of heat.

  • Page 17: Clearance To Combustibles

    MCVP42 Clearance to Combustibles Clearance to Combustibles MCVP42 24” Front and Sides 0” Back (from Stand-offs) 0” Floor* *Note: If appliance is installed directly on carpeting or other combustible material other than wood flooring, a metal or wood panel extending the full width and depth of the appliance must be used. Carpet may extend 1 inch above the floor of the appliance.

  • Page 18: Safety Screen Installation

    MCVP42 Child Safety Screen Installation Contents of Kit: [3] Child Safety Screens- Ready to Install Assembly Instructions: Attach screen to fireplace as per instructions below. NOTE: Screens are symmetrical from top to bottom. ⚠ WARNING: Wait until unit is COMPLETELY cool before touching glass or attempting to install or remove Child Safety Screens.

  • Page 19: Mp42Pl Porcelain Liner Installation

    MP42PL Porcelain Liner Installation ⚠ WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. Instructions: (NOTE: Porcelain Liners should be installed BEFORE Log Grates or Glass Tray.) Step One: Remove Main Burner (refer to Burner Removal section).

  • Page 20: Mp42Rl Brick Liner Installation

    MP42RL Brick Liner Installation NOTE: Brick Liners are not intended for use with MP42GT. ⚠ WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. MP42RL Consists of: Remove 2 Screws [1] –...

  • Page 21: Baffle Removal (Heater Rated Units) / Deflector Removal (Decorative Units)

    ZCV42MCVP Baffle Removal (Heater Rated Units) To Remove Baffle: Remove [5] DT Screws holding Baffle in place. NOTE: Remove end screw last. See below. To Replace Baffle: Hook Mount Tab onto ledge at top of firebox. Replace end screw first. Replace [4] remaining screws.

  • Page 22: Mp42-Gt Installation / Removal

    MP42-GT Installation / Removal 42MCVP Contents of Kit: 1 Glass Tray ⚠ NOTE Instructions: To Install: Place Glass Tray into  Pilot Area Must Not Be Covered, as firebox as shown. delayed ignition can occur. To Remove: Lift Glass Tray from one edge and carefully remove.

  • Page 23: M42-Lg Installation / Removal

    M42-LG Installation / Removal 42MCVP Contents of Kit: 1. [2] Log Grates 2. [2] Large Bags 3/4” Lava Rock 3. [3] 350 Embers 4. [1] Vermiculite 5. [1] Insulation Wool 6. [1] Grate Plate 7. [6] DT Screws Instructions: To Install: 1.

  • Page 24: Mq42Log1 8 Piece Driftwood Log Set - For Use With Gt Glass Tray

    MQ42LOG1 8 Piece Driftwood Log Set - For use with GT Glass Tray ⚠ WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury.

  • Page 25: Mq42Log1 8 Piece Driftwood Log Set - For Use With M42Lg Log Grate

    MQ42LOG1 8 Piece Driftwood Log Set - For use with M42LG Log Grate ⚠ WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury.

  • Page 26: Mq42Log2 7 Piece Oak Log Set - For Use With Gt Glass Tray

    MQ42LOG2 7 Piece Oak Log Set - For use with GT Glass Tray ⚠ WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury.

  • Page 27: Mq42Log2 7 Piece Oak Log Set - For Use With M42Lg Log Grate

    MQ42LOG2 7 Piece Oak Log Set - For use with M42LG Log Grate ⚠ WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury.

  • Page 28: M42Log3 6 Piece Driftwood Log Set - For Use With Gt Glass Tray

    M42LOG3 6 Piece Driftwood Log Set - For use with GT Glass Tray ⚠ WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury.

  • Page 29: M42Log4 8 Piece Oak Log Set - For Use With M42Lg Log Grate

    M42LOG4 8 Piece Oak Log Set - For use with M42LG Log Grate ⚠ WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury.

  • Page 30: Uhs Box / Component Locations

    MCVP42 51UHS Box Included with base model. The 51-UHS Box is designed for millivolt and IPI units for in-unit installation of the Remote Receiver, Fan Control Module, and the IPI Module. 51-UHS Box can be inserted & removed from beneath fireplace through access panel opening (Remove glass door first). NOTE: When using a remote control, the 51-UHS Box must be used.

  • Page 31: Ulk3 Universal Light Kit

    ULK3 Universal Light Kit ( Optional Accent Lighting Kit) MCVP42 & MCVST42 Please follow the current ANSI/NFPA 70 National Electrical Code in the USA and CAN/CSA C22.1 Canadian National Electrical Code in Canada. Contents of Kit: Inside Firebox  [2] 12V Halogen Lamps ...

  • Page 32: Split Receptacle- Switch Control Outside Of Fireplace

    Split Receptacle- Switch Control Outside of Fireplace If you wish to have a control switch outside of the fireplace for one side of the receptacle and you require a constant source of AC power inside the unit for another accessory such as lights or an IPI valve system, follow one of the procedures below.

  • Page 33: Rbcb1 -Cannonballs- Installation Instructions

    RBCB1 -Cannonballs- Installation Instructions *Must be used with MST42GT/ MP42GT Glass Tray Assorted size and colors. Place randomly as desired inside fireplace. Can be used with MQ Glass, MQ Ember, and / or Lava Rock. Do not place Cannonballs directly on burner ports. If sooting occurs change position of or remove affected objects.

  • Page 34: Mq Dealer Accessories For Mcvst42 / Mcvp42 (Glass)

    MQ Dealer Accessories for MCVST42 / MCVP42 The following Accessories are available through MQ Dealers only.  GLASS (MQG5W, MQG5C, MQG5A, MQG5B, MQG5ZG) ACCESSORY ITEM DESCRIPTION If you wish to use this media evenly spread the glass embers onto the false bottom and burner.

  • Page 35: Mq Stone Decorative Stone Set

    NOTE  Pilot Area Must Not Be Covered, as delayed ignition can occur. MQ STONE DECORATIVE STONE SET- Must be used with Glass Tray MST42GT/ MP42GT MQ Stone can be placed on or around Burner. Lava Rock (Supplied with Base MQ EMBER (shown) can be placed on Burner.

  • Page 36: Door Installation

    ZCV39 / ZCV42 / MCVST42 / MCVP42 Door Installation To install Door: 1. Remove Access Cover below Glass Door. 30° 15° 2. Engage door in lower latches at an angle of between 15 and 30 degrees. 3. Swing door up and pull top latches over door lip at each corner. ⚠...

  • Page 37: Door And Glass Information

     Do not strike or abuse the glass. Glass Replacement MCVP42N, MCVP42NE, MCVP42LP, MCVP42LPE must use tempered glass. Must be 5mm thick. Only Robax ceramic or coated Neoceram glass may be used for replacement for Models MCVP42NH, MCVP42NHE, MCVP42LPH, and MCVP42LPHE. Glass must be minimum 5mm thick.

  • Page 38: Gas Line Installation

    1/2 PSIG (3.5 KPa). NOTE: The gas line connection may be made of 1/2” rigid pipe or an Approved Kingsman Flex Connector, such as FP15GC.

  • Page 39: Millivolt System, Lighting, And Burner Control

    Millivolt System, Lighting, and Burner Control FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. BEFORE LIGHTING  This appliance has a pilot which must be lighted by hand. When Immediately call your gas supplier from a neighbour’s phone.

  • Page 40: Troubleshooting The Gas Control System

    Troubleshooting the Gas Control System WARNING BEFORE DOING ANY GAS CONTROL SERVICE WORK, REMOVE THE GLASS FRONT. Before troubleshooting the gas control system, be sure external gas shut off is in the "On" position. Problem Possible Causes Corrective Action Spark igniter will not light. Defective or misaligned Check for spark at electrode and pilot: if no spark and electrode wire is electrode at pilot.

  • Page 41: Burner System Maintenance

    Burner System Maintenance- MCVST42 / MCVP42 It is recommended to annually inspect and clean the Burner System to prevent malfunction and / or sooting. This operation should be performed by your dealer or a qualified technician. -CAUTION- Before servicing the burner system ensure that the gas supply is turned OFF and disconnect all electrical connections to the appliance.

  • Page 42: Conversion Kit Instructions - Part A

    Gas Conversion Part A MCVP42 Models: MCVP42LP, MCVP42N, MCVP42LPE, MCVP42NE Description Pilot Orifice Burner Orifice Brass Nipple Air Shutter Hi/Lo Regulator Kit Number Brass (1000-255) 42MCVP-CKLP LP Conversion 1001-P167SI 1000-253 Fully Open 1001-P202SI -Millivolt- #30 (977.167) Closed (0.907.202) 1/16” 42MCVP-CKNG...

  • Page 43: Gas Conversion Kit For Top Convertible Pilot Part B

    installationinstructions gas conversion kit for top convertible pilot series 0190XYZ) Instructions for converting SIT 190 series pilot burner injector from NG to LPG and from LPG to NG only. This information should be considered as supplemental to the Appliance Manufacturer's Instructions. Warning! The installation of this conversion kit must only be undertaken by a qualified and certified gas appliance installer.

  • Page 44: Gas Conversion For Modulator - Part C

    Gas Conversion for Modulator – PART C WARNING!- WARNING!-...

  • Page 45: Main Burner Removal / Burner System Removal / Installation

    MCVST42 / MCVP42 Main Burner Removal If Glass Tray or Log Grates are installed, refer to MCVST42GT or MCVST42LG Installation / Removal page in this manual. To remove burner, Lift Pilot Shield off of Pilot. Remove four [4] screws from burner. Slide burner away from pilot and lift to remove.

  • Page 46: Ipi Electronic Ignition System

    IPI Electronic Ignition System Overview The IPI system is an advanced burner controller that Cover provides you with the option of having either a Standing- Pilot, or an intermittent igniting system. This alternating Backup mode is controlled by the CPI/IPI Switch (Continuous Pilot Battery Ignition/Intermittent Pilot Ignition) located on the IPI System Pack...

  • Page 47: Remote Control Operation

    -Remote Control Operation- The Proflame GTM is configured to control the on/off main burner operation, its flame levels, and provides on/off and Smart thermostatic control of the appliance. Transmitter Remote Receiver Transmitter Room Thermostat ( Transmitter Operation) The Transmitter is powered by 3 AAA type batteries. A Mode The Remote Control can operate as a room thermostat.

  • Page 48: Ipi Electronic Ignition Parts List - Standard System

    IPI Electronic Ignition Parts List – Standard System ITEM NO. PART NO. DESCRIPTION 1006-P002si Valve IPI Hi/Lo NG 1006-P003si Valve IPI Hi/Lo LP *1002-P047si Pilot Assembly-LP -24” Wire *1002-P033si Pilot Assembly-NG -24” Wire 1002-P017si Spark Electrode (with wire) *1002-P119si Spark Electrode (with wire- 35” Length) 1002-P903si Electrode Flame Sensor *1002-P910si...

  • Page 49: Configuration 1: Basic Manual Hi / Lo And Manual Off

    Configuration #1: Basic manual HI/LO and manual ON/OFF capabilities.

  • Page 50: Configuration 2: Remote On / Off And Manual Hi / Lo

    Receiver Module .584.523/521/221 1001-P221SI Receiver Module .584.523/521/221 1001-P221SI...

  • Page 51: Operating The Receiver Without Batteries For Gt / Egt / Gtm / Egtm Remote Controls

    Operating the Receiver Without Batteries For GT / EGT / GTM / EGTM Remote Controls -Wiring Harness P/N 1002-P906si required for both IPI & Millivolt systems. -Millivolt Systems will also require Power Adapter P/N 1002-P850si. The Remote Receiver & IPI or Millivolt system can be powered by the AC Adapter. This is advantageous if you do not want to use batteries.

  • Page 52: Configuration 3: Remote On/Off, Variable Hi/Lo, And Fan

    Configuration #3: Remote ON/OFF, variable HI/LO, and fan capabilities. Refer to the fan installation/removal section for fan installation.

  • Page 53: Electronic Ignition Lighting Instructions

    Electronic Ignition Lighting Instructions If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Always light the pilot whether for the first time or if the gas supply has ran out with the glass door opened or removed. FOR YOUR SAFETY READ BEFORE LIGHTING: A.

  • Page 54: Vent Termination

    The gas fireplace is approved to be vented either through the side wall or vertically through the roof. F - Clearance under veranda, porch, deck or balcony 12 inches 1 This appliance is approved with Kingsman flex vent system. (30cm) minimum. 4 US 5 ONLY VENTING COMPONENTS SPECIFICALLY APPROVED G - Clearance from a perpendicular inside wall or outer corner to AND LABELED FOR THIS FIREPLACE MAY BE USED.

  • Page 55: General Vent Installation

    General Vent Installation Information This gas appliance is approved to be vented either through the side wall or vertically through the roof. Only Kingsman Flex (Z-Flex) Venting Kits and components specifically approved and LABELED for this stove may be used. This appliance is also approved for use with 5 x 8 M&G-Duravent Direct Vent system (Model DV-GS Series), BDM Pro Form Direct Vent, Ameri-Vent Direct Vent Pipe System, ICC Excel Direct, Metal Fab Sure-Seal DV and Selkirk Direct Temp.

  • Page 56: Venting Routes And Components

    Feet Meters Feet Meters degree bend. 55” (MCVP42N) The maximum vertical run is 43 ft. / 13.1meters. Special Note: For each 45 degree bend installed in the 67” (MCVP42LP) horizontal run, the length of the horizontal run must be reduced by 18”...

  • Page 57: Z58Ht Horizontal Installations- Wall Thimble Sizing / Termination Sizing

    Z58HT Horizontal Installations- Wall Thimble Sizing / Termination Sizing- NOTE: If you are installing 5/8 Termination in an existing wall, measure diameter of both Wall Thimble and Termination. Wall Thimble mount plate comes in two sizes: Termination Plate comes in two sizes: 13-5/16”...
  • Page 58 New Wall Thimble Old Wall Thimble Old Termination Old Termination 13-3/4" Wall Thimble Wall Thimble 15-3/4" Termination Termination 13-5/16" 13-5/16" 1-3/16" 3/16" Old Wall Thimble New Termination New Wall Thimble 15-3/4" New Termination Wall Thimble Wall Thimble 13-3/4" 14-5/16" 14-3/8" 11/16"...

  • Page 59: Venting Straight Up Through Roof

    Venting Straight Up Through Roof An Attic Insulation Shield must be installed where the vent passes from a lower living space into an attic space where the chimney is not enclosed. It is designed to keep insulation materials away from the chimney. When installing the Attic Insulation Shield where the chimney passes from a living space to an attic space, install the shield from below and nail in place using 1"...
  • Page 60 -Restrictor- Remove for Runs Under 15 Feet Clearances in horizontal venting. Z58VT 43ft Straight-through roof support configuration; b) Flex bend configuration; c) Termination mounting...

  • Page 61: 58Pvh Dimensions

    58PVH-Dimensions 12-1/2" 13" 1-1/2" 1/2" 10-5/8" 13" 10-5/8" 5" 11" 8-1/8" 1-1/4" 16" 13" 8-1/8" 5" 11" 11" 11-1/8" 11-3/8"...

  • Page 62: Installation Overview

    PVH58 INSTALLATION OVERVIEW The PVH58 Horizontal Power Vent is approved for the following models only: MQRB4436, MQRB5143, MQRB6961, ZRB46, ZCV39, ZCV42, MCVP42, MCVST42 Either Hard Pipe or Flex Pipe can be used, along with the appropriate adapter kit. The Following Steps Are Required To Install The PVH58 Horizontal Power Vent: ...

  • Page 63: Pvh58 Venting Clearances

    PVH58 VENTING CLEARANCES Note: Clearances are to the edge of terminal plate, add 5-1/2" to clearances to arrive at center line. Note: Local Codes or Regulations may require different clearances. A. Clearance above a veranda, porch, deck, or balcony or other combustible surface is 27”. Clearance above grade is12in [30cm] min.

  • Page 64: Pvh58 Venting- Hard Pipe Or Flex

    PVH58 VENTING HARD PIPE OR FLEX Approved For 4/6-5/8”, 5/8” Hard Pipe The PVH-58 Power Vent is approved for use with M&G-DuraVent-DirectVent Pro Direct Vent system (Model DV-GS Series), and AmeriVent Direct Vent Pipe System, ICC Excel Direct, Metal Fab Sure-Seal DV and Selkirk Direct Temp. Follow installation instructions provided by the appropriate manufacturer for installation of pipe, and adhere to the clearance to combustibles provided in this manual.
  • Page 65 Approved For 4/7”, 5/7” And 7/10” Kingsman Flex (Z-Flex) Pipe Flex Pipe Venting Kingsman Flex pipe is shipped in unexpanded length. When installing pipe expand the lengths. Pipe can be expanded to twice their lengths e.g. 4ft. to 8ft. Fully expand pipe and cut off excess.

  • Page 66: Pvh58 Venting Configurations

    PVH58 VENTING CONFIGURATIONS Refer to Air Intake Adjustment PVH-58 section of this manual to adjust Air Maximum / Minimum Vent Lengths: Intake Shutter. Maximum Vent Length is 125 ft plus six 90° elbows with Air Intake Shutter fully closed. Termination must not be below unit. This power vent can be installed up to 3ft below the installed fireplace on runs less than 100ft and not more than four 90°...

  • Page 67: Pvh58 Wall Thimble Installation

    PVH58 WALL THIMBLE INSTALLATION An 11 inch square opening is required. Center Wall Thimble over the 11 inch square opening and secure both pieces on either sides of the wall. Ensure that cutout is at the lower right corner, as electrical conduit must pass through this area. Cutout At Lower Telescopic Wall Thimble Right Corner when...

  • Page 68: Pvh58 Wiring Harness Connections

    PVH58 Wiring Harness Connections WARNING WARNING WARNING Electrical Grounding Instructions – A qualified electrician must connect This appliance is equipped with a Label all wires prior to disconnection electrical wiring to junction outlet for three – pronged (grounding) plug for when servicing controls.

  • Page 69: Pvh58 Millivolt System Connections

    PVH58 Millivolt System Connections GREEN/GRND 10ft Double Pole Switch Wiring Harness for Millivolt Systems. BROWN BLACK Connects to Double Pole Switch as Shown. A 20ft extension harness can be ordered. See Wiring Harness Connections WHITE section for installation of extension harness. Route Switch Wiring Harness DOUBLE POLE through second 7/8”...
  • Page 70 Connect to TH and TH / TP Tabs on Valve Connect to Power Vent Cable Connect to Double Pole Switch Cable Plug into120v AC Outlet MILLIVOLT POWER VENT CONTROL MODULE FIREPLACE IS SUPPLIED WITH ONE JUNCTION BOX. ADDITIONAL OUTLETS DOUBLE POLE SWITCH MAY BE REQUIRED.

  • Page 71: Pvcm Schematic - Millivolt

    PVCM Schematic - Millivolt...

  • Page 72: Pvh58 Ipi System Connections

    PVH58 IPI SYSTEM CONNECTIONS Mount Power Vent Control Module in Fireplace. NOTE: MODELS WIRING HARNESS EQUIPPPED WITH MILLIVOLT/ STANDING PILOT IGNITION: Downward vertical vent runs are NOT permitted. NOTE: MODELS EQUIPPPED WITH INTERMITTENT PILOT IGNITION: Downward vertical vent runs are permitted, however, Cold Climate Switch (Standing Pilot Mode) must not be used.

  • Page 73: Pvh58 Basic Ipi System Connections

    PVH58 Basic IPI System Connections RECOMMENDED METHOD OF CONNECTION: First ensure the entire IPI system is working properly without connecting any Power Vent components. Then connect the Power Vent Control Module.  PV1A – Valve  PV1B – Orange Wire on 912 Harness ...

  • Page 74: Pvh58 All Ipi System Connections

    PVH58 All IPI System Connections RECOMMENDED METHOD OF CONNECTION: First ensure the entire IPI system is working properly without connecting any Power Vent components. Then connect the Power Vent Control Module.  PV1A – Valve  PV1B – Orange Wire on 912 Harness ...

  • Page 75: Pvcm Schematic - Ipi

    PVCM Schematic - IPI...

  • Page 77: Pvh58 Air Intake Adjustment

    PVH58 Air Intake Adjustment The PVH58 is shipped with the air intake adjustment fully closed. This will produce maximum draw at the fireplace. Longer runs require more draw, while shorter runs require less. If flame pattern is slow and lazy, and sooting is occurring, more draw is required. If flame pattern is running too fast, less draw is required.

  • Page 78: Pvh58 Troubleshooting

    PVH58 Troubleshooting NOTE: Before connecting Power Vent Control Module, ensure that all other systems and accessories (Remote Control, Fan, Lights, etc.) are connected and working properly. !WARNING BEFORE DOING ANY GAS CONTROL SERVICE WORK, REMOVE THE GLASS FRONT. BEFORE TROUBLESHOOTING THE GAS CONTROL SYSTEM, BE SURE EXTERNAL GAS SHUT OFF IS IN THE "ON" POSITION.

  • Page 79: Pvh58 Parts List

    PVH58 Parts List PVH58 HORIZONTAL POWER VENT TERMINATION: Listed for Canada and USA NUMBER DESCRIPTION MCVP42 & MCVST42 VENTING AND VENTING ADAPTERS -For fireplaces to be converted to hard pipe (M&G-Duravent-DirectVent Pro, etc.) at the fireplace: ZD58DFA M&G-Duravent Fireplace Adapter -For Power Vent installations where flex pipe will be used up to the Power Vent unit: Z58PVA Flex Connector Set- ZDV5FC (5”...

  • Page 80: Mcvp42 Parts List

    3927ZDV-P601 Transformer MET60-1 Baffle Conversion Kit MCVP42 OPTIONS – MQ DEALER ONLY - 42MP-BCKNG NG Heater / upgrade Kit for MCVP42N / NE to MCVP42NH /NHE MQ42LOG1 Driftwood Log Set- 8pcs 42MP-BCKLP LP Heater / upgrade Kit for MCVP42LP /...
  • Page 81 Remote Control Millivolt – GTMRCN KINGSMAN FIREPLACE VENTING Thermostat/Modulating - NG Remote Control Millivolt – GTMRCP Z58DFA M&G-Duravent Adapter (5 x 8) Vertical Vent Termination Thermostat/Modulating - LP Z58VT Remote Control Millivolt – GTFRCN Horizontal Vent Termination Thermostat/Modulating/Fan - NG...

  • Page 82: Limited Lifetime Warranty

    During the first year after installation, we will provide a replacement for any component part of your unit found to be defective in materials or workmanship, including labour costs. Repair work requires prior approval by Kingsman, labour costs are based on a predetermined rate schedule and any repair work must be done through an authorized Kingsman dealer.
