ICF-C102/C150
Ver 1.1 2002.10
CLOCK
KEY
NOTE:
•
Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
•
-XX, -X mean standardized parts, so they
may have some difference from the original
one.
•
RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
SECTION 9
ELECTRICAL PARTS LIST
•
Items marked "*" are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
•
SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
•
CAPACITORS:
uF: µF
•
COILS
uH: µH
– 10 –
• Abbreviation
AUS
: Australian
CND
: Canadian
C&SA : Central & South America
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
! sont critiques pour la sécurité.
Ne les remplacer que par une piéce portant le
numéro spécifié.
When indicating parts by reference
number, please include the board
name.
