SERVICE MANUAL
SPECIFICATIONS
Frequency range
FM: 87.5–108 MHz
AM: 526.5–1606.5kHz (Italian)
530–1605 kHz (EXCEPT Italian)
Speaker
5
Approx. 6.6 cm (2
/
inches) dia. 8 ohms
8
Power output
120 mW (at 10% harmonic distortion)
Power requirements
120 V AC, 60 Hz
For power backup: 9 V DC, one 6F22 battery
Battery life
Approx. 35 hours using the Sony S-006 P (U)
battery
Dimensions
Approx. 120 124 132 mm (w/h/d)
× 5 × 5
(4
3
/
1
/
inches) incl. projecting parts
4
4
and controls
Mass
Approx. 660 g (1 Ib 7.2 oz) not incl. battery
Design and specifications are subject to change
without notice.
MICROFILM
ICF-C160
Australian Model
FEATURES
• Dual alarm
• Date display
• Full power backup function to keep the clock, the
alarm (radio and buzzer) and the radio operation
during a power interruption with a 6F22 battery
(not supplied) installed.
FM/AM CLOCK RADIO
US Model
Canadian Model
AEP Model
E Model

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ICF-C160 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sony ICF-C160

Summary of Contents for Sony ICF-C160

  • Page 1 120 mW (at 10% harmonic distortion) Power requirements 120 V AC, 60 Hz For power backup: 9 V DC, one 6F22 battery Battery life Approx. 35 hours using the Sony S-006 P (U) battery Dimensions Approx. 120 124 132 mm (w/h/d) × 5 × 5 inches) incl.

  • Page 2: Section 1 Servicing Note

    SONY PARTS WHOSE PART NUMBERS APPEAR AS DE FONCTIONNEMENT. NE REMPLACER CES COM- SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB- POSANTS QUE PAR DES PIÈCES SONY DONT LES LISHED BY SONY. NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY.

  • Page 3: Section 2 General

    This section is extracted from SECTION 2 instruction manual. GENERAL – 3 –...

  • Page 4: Section 3 Disassembly

    SECTION 3 DISASSEMBLY Note: Follow the disassembly procedure in the numerical order given. FRONT PANEL ASS’Y 3 cabinet (upper) 5 front panel ass’y 4 three claws 1 four screws (P3 × 35) 4 three claws 2 screw (P3 × 10) MAIN BOARD, CHASSIS 5 speaker cord 8 radio board...

  • Page 5: Section 4 Dial Pointer Setting

    SECTION 4 SECTION 5 DIAL POINTER SETTING ELECTRICAL ADJUSTMENTS Note: Follow the assembly procedure in the numerical order given. [FM] • Adjusting Location: RADIO board (Component Side) Setting: L1: AM TRACKING CT3: FM TRACKING BAND switch: FM ADJUSTMENT ADJUSTMENT FM RF SSG level meter CT1: AM TRACKING T1: AM IF...
  • Page 8 • IC Block Diagram IC1 CXA1019S 29 28 27 26 18 17 16 AM IF DET AGC TUNING METER AF POWER AMP AM FE FM IF DISCRIMINATOR FM FE – 12 –...

  • Page 9: Section 7 Exploded Views

    SECTION 7 EXPLODED VIEWS NOTE: • -XX and -X mean standardized parts, so they • Items marked “*” are not stocked since they The components identified by mark ! or dotted line with mark ! are may have some difference from the original are seldom required for routine service.

  • Page 10: Cabinet (Lower) Section

    (2) CABINET (LOWER) SECTION US, CND AEP, IT, SP not supplied The components identified by mark Les composants identifiés par une ! or dotted line with mark ! are marque ! sont critiquens pour la critical for safety. sécurité. Replace only with part number Ne les remplacer que par une pièce portant le neméro spécifié.

  • Page 11: Section 8 Electrical Parts List

    SECTION 8 RADIO ELECTRICAL PARTS LIST NOTE: • Items marked “*” are not stocked since they • Due to standardization, replacements in the The components identified by mark ! or dotted line with mark ! are parts list may be different from the parts speci- are seldom required for routine service.

  • Page 12: Manual, Instruction

    ICF-C160 RADIO Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < DISPLAY LED > < FLAT CABLE > LED101 1-810-027-11 DIODE OHC-605CA (US, CND, E) W701 1-777-242-11 CORD, CONNECTION LED101 1-810-027-21 DIODE OHC-605CE (AEP, IT, SP, AUS)
