Summary of Contents for Kenmore 253.77062
- Page 1 Use & Care Guide Manual de Uso y Cuidado Kenmore Elite ® Low Profile Single Room Air Conditioner Tipo De Sala De Ventana De Aire Acondicionado Model/Modelo: 253.77062 P/N 16120300A04913 Sears Brands Management Corporation Hoffman Estates, IL 60179 U.S.A. www.kenmore.com www.sears.com...
-
Page 2: Table Of Contents
For warranty coverage details to obtain free repair or replacement, visit the web page: www.kenmore.com/warranty. All warranty coverage applies for only 90 days from the date of sale if this appliance is ever used for other than private household purposes. -
Page 3: Master Protection Agreements
Master Protection Agreements ® Congratulations on making a smart purchase. Your new Kenmore Elite product is designed and manufactured for years of dependable operation. But like all products, it may require preventive maintenance or repair from time to time. That’s when having a Master Protection Agreement can save you money and aggravation. -
Page 4: Important Safety Instructions
Important Safety Read all instructions before using this air conditioner. Instructions WARNING For Your Safety Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. Read product labels for flammability and other warnings. NOTE The power supply cord with WARNING... -
Page 5: Air Conditioner Features
Air Conditioner Features ELECTRONIC CONTROL Before you begin, thoroughly familiarize yourself with the control panel and remote as shown below and all its functions, then touch the symbol pads for the functions you desire. The unit can be controlled by the panel touch pads or with the remote control. DISPLAYS FILTER RESET INFRARED... - Page 6 Air Conditioner Features (continued) Note: The following instructions describe the Control Panel Touch Pads. To turn unit on or off press the ON/OFF button: The unit is programmed to start in the energy saver mode, with auto fan speed and a temperature setting of 72 °F. These settings are required by ENERGY STAR for maximum energy efficiency.
- Page 7 Air Conditioner Features (continued) To use Energy Saver press the MODE button to select: You will save energy usage in this mode. The compressor and motor will turn off once the room is at the desired temperature. The air will be sampled for 20 seconds every 10 minutes until the room is above the set temperature, at which point the compressor turns back on and the fan runs.
-
Page 8: Additional Things
ADDITIONAL THINGS YOU SHOULD KNOW Now that you understand the basic operation functions, here are more control features with which you should become familiar. The “cool” circuit has an automatic 3 minute time delayed start if the unit is turned off and on quickly. This prevents overheating of the compressor and possible circuit breaker tripping. -
Page 9: Care And Cleaning
Clean your air conditioner occasionally to keep it looking new. Be sure to Care and Cleaning unplug the unit before cleaning to prevent shock or fire hazards. Air Filter Cleaning The air filter should be checked at least once a month to see if cleaning is necessary. -
Page 10: Troubleshooting Guide
Room Air Conditioner Troubleshooting Guide THE AIR CONDITIONER WILL NOT OPERATE Check if Then … … Power supply cord is disconnected Firmly push the cord into a live wall outlet having proper voltage. (Page 4) Power Cord has tripped Press the RESET button on the plug head. (Page 4) House fuse has blown or circuit breaker tripped Replace the fuse with a time delay type or reset the circuit breaker. -
Page 11: Normal Sounds
Room Air Conditioner Troubleshooting Guide (Continued) THE AIR CONDITIONER RUNS TOO MUCH Check if … Then … Energy Saver is chosen. Inside blower continues operating for one minute to use as much cooling that is available in the evaporator. Current Unit replaced an older unit. Newer, higher efficiency Air Conditioner may run longer to cool the room.
