Summary of Contents for DCS BG36-BQARN
- Page 1 THE PROFESSIONAL 36/48” BG GRILL Use and Care Guide Models: ■ BG36-BQARN ■ BG36-BQARL ■ BG48-BQARL ■ BG48-BQARN ■ BG48-BQRL ■ BG48-BQRN...
- Page 2 A Message T o Ou r Custome rs Thank you for selecting this DCS Professional “BG” Series Grills. Because of these appliances unique features we have developed this Use and Care Guide. It contains valuable information on how to properly operate and maintain your new appliance for years of safe and enjoyable cooking.
-
Page 3: Table Of Contents
T able Of Contents SAFETY PRACTICES & PRECAUTIONS ................3-5 GRILL MODELS ............................6 GAS REQUIREMENTS ........................7-8 LOCATING GRILL / BUILT-IN CLEARANCES .............9-10 BUILT-IN CONSTRUCTION DETAILS ..................11 LEAK TESTING .............................12 INSTALLER FINAL CHECKLIST ....................13 BURNER ADJUSTMENTS ......................14 USING THE GRILL ........................15-16 LIGHTING INSTRUCTIONS ....................16-17 USING THE SMOKER SYSTEM ....................18... -
Page 4: Safety Practices & Precautions
Safety Practices & Precautions IMPORTANT SAFETY NOTICE: Certain Liquid Propane dealers may fill liquid propane cylinders for use in the grill beyond cylinder filling capacity. This “Overfilling” may create a dangerous condition. “Overfilled” tanks can build up excess pressure. As a safety device, the tanks pressure relief valve will vent propane gas vapor to relieve this excess pressure. - Page 5 Safety Practices & Precautions For personal safety, wear proper apparel. Loose fitting garments or sleeves should never be worn while using this appliance. Some synthetic fabrics are highly flammable and should not be worn while cook- ing. Only certain types of glass, heat-proof glass ceramic, earthenware, or other glazed utensils are suit- able for grill use.
- Page 6 Safety Practices & Precautions ions • Do not operate the grill under unprotected combustible construction. Use only in well ventilated areas. Do not use in buildings, garages, sheds, breezeway or other such enclosed areas. This unit is for outdoor use only. •...
-
Page 7: Grill Models
Grill Models tions BG48-BQAR BG48-BQR BG36-BQAR... -
Page 8: Gas Requirements
Gas Requi rements Verify the type of gas supply to be used, either FIG.01 Natural Gas natural or LP, and make sure the marking on the appliance rating plate agrees with that of the supply. The rating plate is located on the inside back wall of the Grill. - Page 9 Gas Requi rements the grill inlet pipe to avoid shifting any internal gas lines of the grill. Ensure that the regulator arrow points in the direction of gas flow towards the unit, away from the supply. Do not forget to place the installer supplied gas valve in an accessible location.
-
Page 10: Locating Grill/Built-In Clea Rances
Do not build the Grill under overhead unprotected combustible construction. If the Grill is to be placed into a combustible enclosure, an approved insulated jacket is necessary and is available from your dealer. Use only the DCS insulated jacket which has specifically been designed and tested for this purpose. - Page 11 Built–In Grill Clea rances GENERAL The Grill is designed for easy placement into masonry enclosures. For non-combustible applications the grill drops into the opening shown in (Fig. 04) and hangs from its side flanges. A deck is not required to support it from the bottom.When using the insulated jacket in a combustible enclosure application, see the bottom of Fig.
-
Page 12: Built-In Construction Details
Built–In Const ruction Details FIG.04... -
Page 13: Leak Testing
Leak T esting GENERAL: Although all gas connections on the grill are leak tested at the factory prior to shipment, a complete gas tightness check must be performed at the installation site due to possible mishandling in shipment, or excessive pressure unknowingly being applied to the unit. Periodically check the whole system for leaks, or immediately check if the smell of gas is detected. -
Page 14: Installer Final Checklist
Installe r Checklist/Bu rne r Ad justments INSTALLER FINAL CHECKLIST: ❏ Specified clearances main- ❏ Air shutters adjusted. ❏ User informed of gas supply tained to combustibles. shut off valve location. ❏ Adjustable low setting satis- ❏ Nylon straps removed from factory. -
Page 15: Burner Adjustments
Bu rne r Ad justments /Using The Grill WARNING: IMPORTANT! Before lighting . . .Inspect the gas FIG.9 Power Burner Flame Height supply piping or hose prior to turning the gas "on". If there is evidence of cuts, wear, or abrasion, it must be replaced prior to use. -
Page 16: Using The Grill
Using The Grill The replacement pressure regulators and hose assembly must be the type specified by the manufacturer. Do not use the grill if the odor of gas is present. The pressure regulator and hose assembly supplied with the unit must be used. If the unit is LP, screw the regulator into the tank and leak check the hose and regulator connections with a soap and water solution before operating the grill. - Page 17 Using The Grill/Lighting Inst ructions USING THE GRILL LP GAS: Grilling requires high heat for searing and proper browning. Most foods are cooked at the “Medium” heat setting for the entire cooking time. However, when grilling large pieces of meat or poultry, it may be necessary to turn the heat to a lower setting after the initial browning.
-
Page 18: Lighting Instructions
Lighting Inst ructions MATCH LIGHTING (CONTINUED): Once the left or right burner is lit, the adjacent burner(s) can be lit by the cross-lighting method. For center burners to cross light, light the adjacent far left or right burner using the standard or match light procedure. -
Page 19: Using The Smoker System
Using The Smoke r System The smoker system on each grill consists of a stainless steel slide FIG. 15 36 / 48 Grill Smoker System out tray which is positioned above a 5,000 Btu/hr burner. The burner is controlled by a precision brass valve which is capable of being turned down to very low heat levels. -
Page 20: Using The Rotisserie
Using The Rotisse rie The grill rotisserie system is designed to cook items FIG. 17 from the back using infrared heat. The location of the burner allows the placement of the rotis basting pan (included) beneath the food to collect juices and drippings for basting and gravy. - Page 21 Using The Rotisse rie WARNING: Never have the grill burners (bottom burners) on during Rotisserie cooking. It will burn your meat and make it very dry. Use only one thing on at a time, grill or rotisserie. PREPARATION Recommended: Dental floss or butcher string, scissors, broiler pan (bottom only), pliers, instant read thermometer, foil, and hot pads.
- Page 22 Using The Rotisse rie COOKING ON ROTISSERIE 1. Place prepared rod into motor, lay across to other side in groove. (Fig.21) 2. Verify placement as shown in Fig. 22. 3. Ignite Burner, start Rotisserie Motor, and keep on High for cooking all meats on the Rotisserie. 4.
- Page 23 Using The Rotisse rie TO LIGHT: All BQR Series Only: The location of the rotis burner makes it more susceptible to strong wind conditions, more so than the protected grill burners. For this reason you should avoid operating the rotis during windy conditions. As an added safety feature we’ve equipped the burner with an automatic safety valve which will not allow gas to flow to the rotis burner unless the following conditions are present with the knob on: 1.The safety valve button is pressed, and held down.
-
Page 24: Care & Cleaning
Ca re And Cleaning BATTERY REPLACEMENT: FIG. 26 1. Remove grease tray. 2. Open cart door. 3. Pull battery downwards (This may require use of pliers.) NOTE: Re-install upward and push to snap. NOTE: Polarity as shown in Fig. 26 GRILL RACKS: The easiest way to clean the grill is immediately after cooking is completed and after turning off the flame. -
Page 25: Burner Removal & Cleaning
Bu rne r Removal And Cleaning SIDE BURNERS: FIG. 24 The grill power burners (BQRS Models Only) are cast iron and occasionally it will be necessary to remove surface rust to ensure proper performance. Frequency of cleaning will depend on the climate & location, and how often you use the grill. -
Page 26: Troubleshooting
You may save the cost of a service call. Troubleshooting is for general purposes only. If the problem persists and you feel you require service, contact your dealer or the nearest authorized agency to perform service. Only authorized agencies can perform warranty service. Call DCS Customer Service at (888) 281-5698. -
Page 27: Grill Burner Assembly Parts List
Grill Bu rne r Assembly ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. Grate 4F Electr. Polish 18197-02 Control Valve 13017 Radiant Tray 32218-02 Control Knob 14154 Ceramic Rods 9.5 32224 Knob Bezel 14006-PL Radiant Cap 32264 Collector Box 32801 C/Heat Shield w/Assy. -
Page 28: Grill Body Parts List
Cage Nut 15029-02 Logo spring Clip 15073 Valve Panel 48BQR 32212-22-PA Valve Panel 48BQAR 32212-21-PA Valve Panel 36BQAR 32212-20-PA DCS Logo 17382-03 Torx Screw 15002-41 Drip Pan 48 30645-2 Drip Pan 36 30645-1 Drip Pan Handle 48 32050-01 Drip Pan Handle 36... -
Page 29: Rotisserie Assembly Parts List
Rotisse rie Assembly ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. Rotisserie Handle 18040 Screws 15001-23 Meat Holder Assembly 19010-02 Thermocouple 13007-2 Rotisserie Rod 48dbqar 19054-05 Electrode Rotisserie 48-BQR 16440-01 Rotisserie Rod 48dbqr 19054-02 Electrode Rotisserie 36-BQAR 16440-01 16440-01 Rotisserie Rod 36dbqar 19054-04 Electrode Rotisserie 48-BQAR 16440-02... -
Page 30: Smoker Burner Assembly Parts List
Smoke r Bu rne r Assembly ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. Smoker Tray w/assembly 32231 Smoker Burner 30639-1 Screw 15139 Screw 15139 Smoker Plate 32228 Screw 15139 Smoker Pull Handle 18204-01 Smoker /Burner Support 32226 Screw 15139 Control Valve 13017-01 Electrode Smoker 36-BQAR... -
Page 31: 48 Grill Ca Rt Pa Rts List
48 Grill Ca rt Pa rts List ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. Side Shelf Tray 41067 Axle 41062 Side Shelf End Cap 14205 8” Solid Rubber Wheel 18264 Side Shelf Assembly 18212 Hub Cap 41075-01-SP Bolt 15003-06 Torx Screw 15002-45 Left Body Panel... -
Page 32: Grill Cart Parts List
36 Grill Ca rt Pa rts List ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. Side Shelf Tray 41067 Pull Handle 18204-02 Side Shelf End Cap 14205 Right Door Assembly 41113-01 Side Shelf Assembly 18212 Screw 15001-13 Bolt 15003-06 Door Stop Tab 41094 Left Body Panel 41053... -
Page 33: Wiring Diagram
Wi ring DiagramBG36-BQA R Models I/R Burner Electrode Smoker Burner Electrode Burner Electrodes Burner Electrode IgnitionModule 6 Output Ignition Switch Wiring Diagram P/N # 32826... -
Page 34: Wi Ring Diagrambg48-Bqr Models
Wi ring DiagramBG48-BQR Models I/R Burner Electrode Smoker Burner Electrode Burner Electrodes Burner Electrode IgnitionModule 6 Output Side Burner Electrode Ignition Switch Wiring Diagram P/N # 32828... -
Page 35: Wi Ring Diagrambg48-Bqa R Models
Wi ring DiagramBG48-BQA R Models I/R Burner Electrodes Smoker Burner Electrode Burner Electrodes Burner Electrodes IgnitionModule 6 Output Ignition Switch Wiring Diagram P/N # 32827... -
Page 36: Service
Se rvice HOW TO OBTAIN SERVICE: For warranty service, contact DCS Customer Service at (888) 281-5698. Before you call, please have the following information ready: • Model Number • Serial Number • Date of installation • A brief description of the problem Your satisfaction is of the utmost importance to us. -
Page 37: Warranty
DCS to be defective. Replacement will be F.O.B. DCS, and DCS will not be liable for any transportation costs, labor costs, or export duties. This warranty shall not apply, nor can we assume responsibility for damage that might... - Page 38 A Message T o Ou r Custome rs As product improvement is an ongoing process at DCS, we reserve the right to change specifications or design without notice. 5800 Skylab Road, Huntington Beach, CA 92647 Tel: (714) 372-7000 Part No. 17466 rev B...
