- Page 1 80cm (31.5") LCD TV WITH DVB-T INSTRUCTION MANUAL TFTV835HD...
-
Page 3: Table Of Contents
CONTENTS Safety Precautions Power Supply..............................1 Installation................................. 2 Use and Maintenance............................3 Important Safety Instructions ..........................4-5 User Guidance Information Names of each part(Front View) / Accessories ....................6 Names of each part(Back View) ........................7 Remote control ..............................8-9 Basic Operation Basic Operation .............................. -
Page 4: Safety Precautions
Safety Precautions Power Supply... -
Page 5: Installation
Safety Precautions Installation... -
Page 6: Use And Maintenance
Safety Precautions Use and Maintenance... -
Page 7: Important Safety Instructions
Safety Precautions Important Safety Instructions... - Page 8 Safety Precautions Important Safety Instructions...
-
Page 9: User Guidance Information
User Guidance Information Names of each part IR (Remote Sensor): Infrared sensor for remote control TV/AV button - Input Source Select Button MENU button - OSD Menu Display Button CH+/- button - Channel/Program up/down VOL+/- button - Volume up/down POWER button POWER Indicator Instruction Manual Instruction Manual... -
Page 10: Names Of Each Part(Back View)
User Guidance Information Names of each part Black View SWITCH: Switch on/off the power supply. AC POWER IN: Connect it to AC100-240V 50/60Hz power supply with the mains cable. USB: Software update and Multimedia Operation. HDMI1/2/3: Connect it to the HDMI of DVD or other equipment. VGA: For PC display.Connect it to the D-Sub 15 pins analog output connector of the PC. - Page 11 User Guidance Information Remote Control POWER: Turn the TV on/standby. POWER MUTE MUTE: Press to mute the sound, press again or press VOL+ to unmute. REC LIST CH/LIST SUBTITLE REPEAT REC LIST : Record List. CH/LIST : Display the programs list. SUBTITLE : Turn on/off the subtitle display in DTV mode.
-
Page 12: Remote Control
User Guidance Information Remote Control POWER MUTE REC LIST CH/LIST SUBTITLE REPEAT TV/AV DISPLAY MENU EXIT CH / : Scan through channels. VOL / : Adjust the volume. PICTURE: Select the picture mode. EPG: Press to enter the EPG menu directly. SOUND: Select the sound mode. -
Page 13: Basic Operation
Basic Operation Basic Operation Basic Operation Power on/off 1. Connect to the power. Input Source 2. -To turn on the TV Press POWER button on the TV or remote control. -To turn off the TV YPBPR Press POWER button on the TV or remote control. HDMI1 Input Source select HDMI2... -
Page 14: Osd Menu
OSD Menu OSD Menu 1. CHANNEL menu Software Update(USB) Description Auto Scan Press OK button to enter the hint menu, and select Australia the Country and Tune Type mode for the TV, then press OK button to start auto tuning. DTV Manual Tuning Press OK button to enter the DTV Manual Tuning menu, select a DTV channel, and press OK button to start searching. - Page 15 OSD Menu OSD Menu Programme Edit Press OK button to enter the Program Edit menu as the following picture. Rename Delete: Select a channel and press RED button, “Delete” will appear on the right of the program edit menu next to the channel you have chosen, then press RED button again, the program will be deleted.
-
Page 16: Picture Menu
OSD Menu OSD Menu 2. PICTURE menu Description Picture Mode: Choose from Standard, Dynamic, User and Mild. Note: Contrast, Brightness, Color and sharpness are only available and can be adjusted in the User mode option in the Picture Mode Settings. Contrast: Controls the difference between the brightest and darkest regions of the picture. -
Page 17: Sound Menu
OSD Menu OSD Menu 3. SOUND menu SPDIF MODE Description Sound Mode: Allows you to select among: Standard, Music, Movie, Sports and User. Treble(Could be adjusted when the sound mode is User): Controls the relative intensity of higher pitched sounds. Bass (Can be adjusted when the sound mode is set to User): Controls the relative intensity of lower pitched sounds. -
Page 18: Time Menu
OSD Menu OSD Menu 4. TIME menu Description Clock: Use the buttons to select the position, and use the buttons to set the time. Note: User can not change time manually during DTV mode, for time is from signal source directly. -
Page 19: Option Menu
OSD Menu OSD Menu 5. OPTION menu OSD Duration Country Australia Description OSD Language: Allows you to select menu language. Audio Language 1st/2nd (can be selected in DTV mode): Allows you to select first and second audio language. Subtitle Language 1st/2nd (can be selected in DTV mode): Allows you to select first and second subtitle language. -
Page 20: Lock Menu
OSD Menu OSD Menu 6. LOCK menu No Lock Description Lock System: Turn on/off the Lock System function. Note: You should enter the code to operate the menu.(original code is 0000) Set Password: Set pin code. If the Pin code has been changed you must enter the present code. -
Page 21: Multimedia Operation
Multimedia Operation Multimedia Operation Basic Operation 1). Press the TV/AV button on the remote control to display the input source menu, select USB source by the buttons, and press OK button to enter the Multimedia menu seen below. Input Source YPBPR HDMI1 HDMI2... - Page 22 Multimedia Operation Multimedia Operation 1. Photo Play the photo ZOOM IN ZOOM OUT Press button to select the option on the table, and press OK button to change. Repeat: Select the repeat mode from Repeat All, Repeat 1, Repeat None. Music: Play/pause the music program (you can only play or pause the music you have programed).
- Page 23 Multimedia Operation Multimedia Operation 3. Movie Play the movie GOTO Time Press button to select the option on the table, and press OK button to change. Repeat: Select the repeat mode from Repeat All, Repeat 1, Repeat None. Set A-B: Select and play the preferable paragraph of the program by seting A and B at the beginning and end, and there will be a sign on the left screen, press OK button again to cancel.
-
Page 24: Recording Operation
Recording Operation Recording Operation PVR settings Press the MENU button, and select CHANNEL menu. Recording Timer 1). Recorded List Display the recorded list Recorded list: Display the Recorder List menu, and changed the mode of program. INFO: Display the information of the program you recorded. RED button: Delete the program you select. - Page 25 Recording Operation Recording Operation 3). Schedule List Display the recorder shedule Note: a. Could’t add shedules which have existent on the list; b. Could’t add shedules when the list is full, you have to delete some schedules; c. You could delete a schedules by RED button on the remote control. 4).
- Page 26 Recording Operation Recording Operation 5) Record Start When you finish the settings above, you could start recording by select Record Start in the menu and press OK button in DTV mode. (You can also start recording by press the button on the remote control) Record buttons Recording: Press to enter the recording mode.
-
Page 27: Specifications
In line with manufacturers and would not mean that the panel is faulty. Dead pixels panels with 6 pixels or more within 12 month period, Palsonic Corporation Pty Ltd. complies with industry standard and reserves the right to repairthe unitand non-refundable. We hope you will understand that the product that corresponds to this standard is regarded as acceptable.
