7. Pitch Fine Adjustment
Via the Pitch Fader -13- you can steplessly adjust the record's pitch. Via the Pitch Range Buttton -10- you can choose between a pitch range of +/-
8% and +/-16%. The respective LED will be lit.
NOTE! In order to select a pitch range of 50%, press both pitch range select switches simultaneously; both LEDs will be lit.
If you want to play a record at its original pitch, bring the pitch fader to the "+/-0%" position. By using the Reset Lock Switch -11- you can deacti-
vate the pitch fine adjustment, the LED will go on. By pressing again the fine adjustment will be re-activated: the turntable returns to the speed set
via the pitch fader and the LED will go out. The Quartz Lock LED -12- will be lit when in original pitch and when pitch fine adjustment is deactivated;
when the pitch differs, it will go out.
8. Brake Speed Adjustment
Via the dial -7- you can steplessly adjust the motor's brake time in a range of min. (dial to the left) – 6 seconds (dial to the right).
9. Torque Adjustment
Via the dial -8- you can steplessly adjust the motor's torque in a range of 2.8 kgf/cm (dial to the left) – 4.5 kgf/cm (dial to the right).
TECHNICAL SPECIFICATIONS
Type: ....................................................................................................manual quartz driven turntable
Drive: ...................................................................................................quartz driven upper torque direct drive
Motor: ..................................................................................................brushless DC motor
Turntable RPM: ..................................................................................33 1/3, 45 and 78 RPM
Turntable: ...........................................................................................aluminum die casting
Pitch: ...................................................................................................variably adjustable +/-8%, +/-16%, +/-50%
Torque: ................................................................................................adjsutable from min. 2800 – 4500 gf/cm
Start up time: ....................................................................................min~6 sec. (adjustable)
Brake system: ....................................................................................electronic brake
Effective Arm Length: .......................................................................230 mm
Overhang: ............................................................................................15 mm
Tracking Error Angle: ........................................................................<3°
Wow and flutter: ................................................................................0.01% WRMS*
S/N ratio: ............................................................................................more than -55 dB
Admissible cartridge weight range: ..............................................3.5 – 8.5 g (incl. headshell 13 – 18 g)
Anti-skating range: ...........................................................................0 – 3 g
Power input: .......................................................................................13 W
Power supply: ....................................................................................AC 115/230 V, 60/50 Hz (EU/US), AC 100 V, 50/60 Hz (JP)
Dimensions: ........................................................................................458 x 144.6 x 354 mm (w/h/d)
Weight: ................................................................................................11,7 kg
*Impact of stylus, record and tone arm not taken into account.
Note: Subject to alterations. The specified data is of approximate value.
