Tripp Lite SU1000XLCD Quick Manual

SU1000XLCD is not for sale in Colorado, Vermont and Washington state. Customers in these states
should purchase the recommended ENERGY STAR® 2.0 model instead: SU1000RTXLCD2U. Learn
more about ENERGY STAR 2.0 and sales restrictions in these states.
SmartOnline 120V 1kVA 900W Double-
Conversion UPS, Tower, Extended Run, Network
Card Options, LCD, USB, DB9 Serial
MODEL NUMBER: SU1000XLCD
Description
Do you need to protect small- to medium-size servers, networking equipment and telecom systems
against data loss, downtime and equipment damage due to power outages, voltage fluctuations and
transient surges? Tripp Lite's SU1000XLCD SmartOnline® Tower UPS System is the solution! Featuring a
1000VA/900W capacity and true on-line operation with pure sine wave output and zero transfer time to
battery, it provides the highest level of power protection for mission-critical equipment. The
SU1000XLCD's large internal battery set supports connected equipment during blackouts, and runtime is
expandable with optional external battery packs (Tripp Lite model BP24V15RT2U, BP24V28-2U or
BP24V70-3U), sold separately. The SU1000XLCD has 6 5-15R outlets, including 2 single-outlet load
banks that are individually controllable to reboot select equipment on demand or maximize battery runtime
for mission-critical equipment. USB and DB9 communication ports support messaging of detailed UPS
operational parameters and line power status. PowerAlert UPS management software is available via free
download. It comes backed by $250,000 of Ultimate Lifetime Insurance (U.S., Canada, and Puerto Rico
only).
Features
Ideal for Protection of Mission-Critical Equipment
True On-Line Operation with Pure Sine Wave Output and Zero Transfer Time
Individually Controllable Outlets
Reliable, Expandable Battery Backup
1 / 6
Highlights
1000VA / 1kVA / 900 watt on-
line double-conversion tower
UPS
100/110/120/127V 50/60Hz
output, high efficiency economy
mode option
Interactive LCD with 10
selectable screens of UPS and
site power data
Expandable runtime, Hot-
swappable batteries
USB, RS232 & EPO ports,
Network Management Card
options
2 independently switched load
banks
NEMA 5-15P input; 6 5-15R
outlets
To use the Auto Probe feature,
this product requires a
WEBCARDLX network interface
(sold separately) running LX
firmware update 15.5.2 or later
Package Includes
SU1000XLCD SmartOnline®
Tower UPS System
USB, DB9 and EPO Cables
Owner's Manual
