FF-E200
FRENCH FITNESS E200 COMMERCIAL ELLIPTICAL
ASSEMBLY MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the E200 and is the answer not in the manual?

Questions and answers

Summary of Contents for FRENCH FITNESS E200

  • Page 1 FF-E200 FRENCH FITNESS E200 COMMERCIAL ELLIPTICAL ASSEMBLY MANUAL...
  • Page 2   :     :    : ...
  • Page 3 1. Safety Precautions ................2. Technical standard ................3. Machine diagram ................4. Assembly instructions ................ 5. Instrument operation guide .............. 6. Machine debugging process .............. 7. Routine maintenance ................ 8. Explosion map ................... 9. Parts list ....................
  • Page 4 Safety Tips: This safety manual lists important safety information. Please read it carefully before use. 1. The machine is suitable for commercial fitness clubs, clubhouse fitness, bodybuilding training, sports training, physical education and so on. 2. The elliptical machine should be placed indoors. Do not use it outdoors or in a place with high humidity.
  • Page 5 11. Long hair users should pay attention to the safety of hair during the use of elliptical machines. 12. If you feel any discomfort or abnormal condition during use, stop exercising immediately and consult a doctor. 13. Before each use, please check the transmission parts for fastening. If it is loose, please tighten or replace it in time.
  • Page 6 Input supply voltage:DC15V±10%,3A Time display range:0:00——99.59 Distance display range:0.00——99.99Km Heat display range:0——999(Kcal) Heart rate display range:50——256(times/minute) Resistance display range:0——20 Speed display range:0.0——99.99 Power cord specification:10A AC250V...
  • Page 7 Elliptical screen 13.3 inch Android system ) Swing Arm Rate Arm Pedal 脚踏板 铝导轨护盖 Aluminum rail cover...
  • Page 8 Assembly easily is the principle User Manual All of this section is intended to ensure that the elliptical machine can be assembled correctly and easily. According to the user manual assembly procedure, the assembly work will be very smooth. ●Due to the large size of the elliptical machine, please select the assembly location where the elliptical will be placed and ensure there is enough space around the elliptical machine.
  • Page 9 Assembly completed overall rendering...
  • Page 10 Assembly step one Disassemble the whole machine package, assemble the left and right swing arm and the fixed display combination, as shown in the figure (1) Assembling fixed display combination, communication line link, screw fixing; (2) Assembling the left and right swing arms and fixing Communicatio line link,...
  • Page 11 Assembly step two Assemble the meter head, connect the heart rate line and the communication line, the heart rate line does not distinguish between the left and right, tighten all the screws communicatio n line and the heart rate line respectively connected, After the assembly is completed, tighten all the screws, after the power is turned on,...
  • Page 12 LED display operation instructions The treadmill panel adopts the capacitive touch principle, and the user can use only one touch at a time, and the touch effect is comparable to that of the mobile phone screen. The surface of the panel is made of acrylic, which is wear-resistant and durable, and has a beautiful color and beautiful appearance.
  • Page 13 program process map, etc.; 5. The “green display tube above” is a circular runway with a circle of 400 meters; 6. "Left LED display area window" This area displays the current motion mode indicator; Second, the button function: 1. “PRO” is the program key: in the standby mode, press this button to cycle through “BIM”, “TIME COUNT”, “DISTANCE COUNT”, “CALORIES COUNT”, “Heart Rate”, “MANUAL MODE”, “ALPINE”...
  • Page 14 Maintennance 1, Cleaning everyday Advises you to clean the equipment before and after each training. To remove dust from the equipment, use a soft cloth to infiltrate the following cleaning agent and then wipe all exposed surfaces; Note: Before using any detergent to clean the fitness equipment, read and follow the manufacturer's instructions, especially the dilution instructions.
  • Page 15 (3) Test all the functions of the console, including the heart rate monitoring function. (4) Check whether the equipment is stationary on the floor. All the feet of the equipment should be firmly in contact with the floor, the equipment should not be shaking or shaking when used.
  • Page 17 Serial Part Name Number number TZ04-T039-0500A 1Z04-7039-0500 TZ03-7039-0317 TZ04-7039-0000 TZ-7039 1Z06-7039-0612 TZ067039-0639 TZ067039-0613A TZ067039-0617 TZ067039-0618 Ø12x40 M10x9t-S1 M-2532-15 M1020L-M2 Ø30x105x20t-C2 TZ03-7039-0327 M5x3L-A1 Ø15x9x14 M8x20L-M2 Ø20x100t-CL M020L-V1...
