Summary of Contents for Coway AP-1520C
- Page 1 Coway Air Purifi er AP-1520C • This product is for domestic use only. Product voltage does not work overseas. • For your safety and proper use of the product, please read this User’s Manual before use. • Warranty card is included in this User’s Manual.
- Page 2 FEATURES Real-time air quality display It displays the digitization of ultrafi ne particulate matter (PM2.5) and gas pollution level, and indicates the indoor air condition in 4 levels of color. Auto mode The auto feature adjusts the product’s air speed automatically via real-time air quality monitoring to operate the product effi ciently.
-
Page 3: Table Of Contents
DEAR CUSTOMERS Coway air purifier. Thank you for using the Please read this user manual carefully for correct use and maintenance of the product. You can refer to the user manual to troubleshoot for product issues while using it. Please keep this user manual in a safe place as it includes the product warranty. -
Page 4: Safety Information
SAFETY INFORMATION Danger : Failing to follow the precautions below may result in serious injury or even death. • Do not use damaged power plugs or loose sockets. • The power plug must be plugged into 220 V – 240 V~ 50 Hz, 60 Hz. •... - Page 5 • Do not install in places with a lot of humidity or dust or places where water (rainwater) splashes. • Do not use or store combustible gases or flammable materials near this product. • Do not insert a sharp object such as drill into the pollution sensor. •...
-
Page 6: Warning
SAFETY INFORMATION Warning : Failing to follow the precautions below may result in considerable physical injury or property damage. • Do not insert fingers or foreign objects (pin, stick, coin, etc.) into the air outlet. • Do not allow children to hang or climb on the product. •... -
Page 7: Caution
Caution : Failing to follow the precautions below may result in slight physical injury or property damage. • Do not install on a slope. • Do not excessively impact or use excessive force on this product. • Use at least 20 cm away from walls or other objects on each side, and use at 30 cm to 60 cm above the product. -
Page 8: Part Names
PART NAMES Front/Rear Indicators Pollution sensor Front cover Air Inlet Power cord Air outlet Control panel... -
Page 9: Air Purification Process
AIR PURIFICATION PROCESS ■ Pre-filter The pre-filter made of microfiber uses a mesh trap to catch large particles such as pet fur and human hair. ■ Fine dust removal filter Effectively captures and reduces small particles such as fine dust and ultrafine dust. ■ HEPA filter The high-performance synthetic HEPA filter is excellent at removing cigarette smoke and fine dust. - Page 10 BEFORE USE Please check before use! The product is for 220 V – 240 V~ 50 Hz, 60 Hz only. Make sure to connect the power plug to a 220 V- 240 V~ 50 Hz, 60 Hz outlet. How to install filter - Be sure to remove the packaging vinyl before installing the filter.
- Page 11 INDICATORS AND BUTTONS Indicators Mode indicator Speed indicator Plasma / Ion indicator Light sensor Mode indicator By using the Mode button, it is possible to select the operation mode in 4 steps (Auto → Silent → Eco → Turbo). Speed indicator By using the Speed button, it is possible to select the air speed in 3 steps (Level 1 →...
- Page 12 INDICATORS AND BUTTONS Pollution level indication guide Clean Clean pollution (Blue) (Blue) (Green) Pollution level indicator Fine dust digitization Gas pollution level indicator Plasma activation indicator High Medium Medium Clean Clean pollution pollution pollution pollution pollution (Blue) (Blue) (Green) (Red) (Green) (Yellow) (Yellow)
- Page 13 Buttons Power button Mode button Speed button Plasma / Ion button Light button / Child lock button Power button Mode button Use the button to turn the product Use it to select the operation mode on and off . by pushing the mode button. (Auto Silent Turbo)
- Page 14 HOW TO USE - Plug the power cord into an outlet before operating the product. - When the product is turned on, it is set to the previously operated mode. Tips ■ How to select the mode Press the Mode button and choose the ▶...
- Page 15 ADJUST PARTICLE SENSOR When the product is shipped out, the pollution sensor is set to standard sensitivity. If the pollution level stays at the highest level after 2 hours of operation or stays at the lowest level for more than 1 hour when the air does not seem clean, users can adjust the sensitivity of the pollution sensor as follows.
-
Page 16: How To Clean
HOW TO CLEAN - Always unplug the power plug before cleaning. - Do not use organic solvents (thinner, etc.), bleach, or detergents containing chlorine or abrasives to clean the product. Tips - Do not immerse the product in water or spray water on it. ■... - Page 17 - Always unplug the power cord before cleaning the filter. - The pre-filter can be restored by removing dust or washing with water. - Failure to clean the pre-filter for a long time may result in poor product performance. Tips - The HEPA filter cannot be reused after washing.
- Page 18 HOW TO CLEAN ■ RBD Plasma, photocatalyst filters 1. Pull the upper part of the front cover to open. 2. Take out the RBD Plasma, photocatalyst filters, and then press both projections of the filter to separate the filter into ▶...
- Page 19 ■ How to Replace - Be sure to check the front side when installing the filter. - Use genuine Coway filter to maintain optimal performance of the product. - Always unplug the power cord before replacing the filter. ■ Filter Cleaning and Replacement Cycle...
- Page 20 TROUBLESHOOTING Even when the product is not broken, the air purifier may malfunction due to misuse by the user or other minor causes. Check the following in such a circumstance to resolve the issue easily without assistance from the service center. If the problem persists after checking the items below, please contact the service center.
- Page 21 SPECIFICATION Product name Air purifier Model Name AP-1520C Rated Voltage 220 V – 240 V~ 50 Hz , 60 Hz Phase Power Consumption 90 W Product Insulation Class Class 2 equipment Dust Collection Method Mechanical dust collection (HEPA filter) Safety Equipment...
- Page 22 INCLUDING ITS REPRESENTATIVES, TO MAKE ANY only to Product used for an application specified REPRESENTATION OR TO OFFER ANY WARRANTY, by COWAY for the Product and applied in strict CONDITION OR GUARANTY IN RESPECT OF THE accordance with COWAY published specifications PRODUCT OTHER THAN THIS WARRANTY.
- Page 23 COWAY no later than accident, alteration, improper installation or thirty (30) days after a defect is discovered or other acts that are not the fault of Coway or should by reasonable diligence have been the manufacturer of the product or that are discovered.
- Page 24 9235685 www.coway.com...
