Textron EZGO TXT SHUTTLE 2+2 Service & Parts Manual page 76

FRONT SUSPENSION AND STEERING
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
32 00464G8
33 01068G01
34 70667G02
35 70667G04
36 00532G7
37 00560G2
38 00734G1
39 70997G01
40 71055G01
Page K-5
1 2 3 4 5
Hex Head Bolt, 7/16" - 14 x 2 3/4" Lg, Grade 5...............................................
Hex Head Bolt, 7/16" - 14 x 3 1/2" Lg, Grade 5...............................................
Spacer, 1.21" ...................................................................................................
Spacer (Short), .69" .........................................................................................
Hex Nut, 7/16" - 14 ..........................................................................................
Flat Washer, 7/16" ...........................................................................................
Lock Nut, 7/16" - 14 .........................................................................................
Cover ...............................................................................................................
Rivet (Aluminum), 3/16" x 1" Lg.......................................................................
689396 Service Parts Manual
DESCRIPTION QTY.
2
1
2
1
1
7
3
1
1
