Summary of Contents for AOpen 34HC5CUR
- Page 11 USB Cable (Optional) USB Type C Cable (Optional)
- Page 12 100mmx100mm...
- Page 15 • Height Adjustment After pressing the top of the monitor then you can adjust the height of the monitor. 130mm...
- Page 17 Type 1:Amber Type 2:LED flashes...
- Page 19 15-pin color display signal cable Threading Explanations Threading Explanations +5 V Green Logic ground Blue Monitor ground Monitor ground DDC-continuous data DDC return Line sync signal Red-ground Field sync signal Green-ground DDC-continuous clock Blue-ground 24-pin USB Type C cable PIN No. Signal Assignment PIN No.
- Page 20 Mode Resolution Remark 640x480 60Hz 640x480 72Hz 640x480 75Hz 640x480 66.66Hz VESA 720x400 70Hz 800x600 56Hz 800x600 60Hz SVGA 800x600 72Hz 800x600 75Hz 832x624 74.55Hz 1024x768 60Hz 1024x768 70Hz 1024x768 75Hz 1152x870 75Hz 1152x864 75Hz VESA 1280x960 60Hz 1280x1024 60Hz SXGA 1280x1024 75Hz...
- Page 21 1. Turn off your computer and unplug the power cord. 2. 2-1 C onnect Video Cable a. Make s ure both the monitor and computer are powered-OF F . b. Connect the VGA cable to the computer. (Optional) 2-2 Connect HDMI Cable (Only HDMI-input model) (Optional) a.
- Page 22 Note:The location and names of the function buttons and power button on the monitor may vary according to monitor model,and some button may not available for some models. Type1 HotKey 1,2 buttons. Press to activate user defined hotkey function. Type2 Power Type3-1 Type3-2...
- Page 23 Using the Shortcut Menu The button and the actual functions depend on detail model.Some functions might be grayed if the model can not support . Note:Please select the button function operation according to the actual button type. The button of Type 1 The button of Type 2...
- Page 24 The button of Type 3-1 The button of Type 1 The button of Type 2 The button of Type 3-1 The button of Type 3-2 Open the Function page to select the menu function,and then use the Button Menu/Navi/Ok to adjust the settings you need.When finished, Pull left the Button Menu/Navi/Ok to return to the previous level or exit the menu.
- Page 25 Adjusting the Setings Use buttons to open the OSD and navigate to the Settings you need. The button of Type 1 Use Buttons 1/2 to select the Settings you need from the OSD. The button of Type 2 Use Buttons 1/2 to select the Settings you need from the OSD. The button of Type 3-1 Using the Navi/Ok button, to select the Settings you need from the OSD.
- Page 27 7. H. Position: Adjust the horizontal position from 0 to 100. 8. V. Position: Adjust the vertical position from 0 to 100. 9. Focus: Adjust the focus from 0 to 100. 10. Clock: Adjust the clock from 0 to 100.
- Page 28 sRGB mode is for getting better color matching representation with the peripheral device, such as DSCs or printers.
- Page 30 /Freesync Premium/Freesync Premium Pro/Adaptive-Sync If FreeSync /Freesync Premium//Freesync Premium Pro/Adaptive-Sync is ”OFF”, then the user can set Over Drive to...
- Page 31 cards only. Freesync Premium: Select On or Off.Freesync Premium is available for AMD supported graphic cards only. Freesync Premium Pro: Select On or Off.Freesync Premium pro is available for AMD supported graphic cards only. Adaptive-Sync: Select On or Off. Adaptive-Sync is available for AMD supported graphic cards only.
- Page 32 Note: 1. For Side 9 key/Navi key，Must press Navi Key in the middle to unlock OSD. 2. For side/Buttom 5 key，except power key can be unlocked.
- Page 33 3. DP Format: You can select which DP format you are using. The default is set at DP1.4 or DP1.2. (*only for DP function) 6. PIP/PBP:The options for PIP/PBP Mode are Off, PIP Large, PIP Small, and PBP. You can also adjust the PIP Position, PBP Size, Sub Source, Source Swap, and Audio Source.
- Page 36 LED flashes...
-
Page 37: Declaration Of Conformity
(“x” = 0~9, a ~ z, A ~ Z, or blank) We, AOPEN Smartview Incorporated., hereby declare under our sole responsibility that the product described above is in conformity with the relevant Union harmonization legislations as below Directive and... - Page 38 34HC5CUR 34HC5CUR...
