- Page 1 AOPEN DT22M-O DT22M-O Commercial Touch Monitor User Manual Version: 1.0 Released date: 2019/08...
- Page 2 To minimize pollution and ensure utmost protection of the global environment, please recycle the product. For more information about the collection and recycling of Waste Electrical and Electronic Equipment (WEEE), you are invited to visit our homepage at www.aopen.com under “Green Products” 廃棄上の指示 より良い地球保護のために、電子機器を廃棄処分にする時は、ゴミ箱に捨てないで下さい。汚...
- Page 3 Electriques et Electroniques (DEEE ou WEEE), vous êtes invité à visiter notre site à www.aopen.com sous “ Green Products”. ATTENTION II y a danger d'explosion s'il y a remplacement incorrect de la batterie. Remplacer uniquement avec une batterie du même type ou d'un type équivalent recommandé...
- Page 4 Per maggiori informazioni riguardanti la raccolta ed il riciclaggio delle apparecchiature elettriche ed elettroniche residue (WEEE), siete invitati a visitare la nostra homepage www.aopen.com alla voce “Green Products”.
- Page 5 Para más información acerca de dónde depositar y cómo reciclar Equipos Electrónicos y Desperdicios Electrónicos (WEEE), por favor, visite la página web www.aopen.com y entre en la sección Productos Ecológicos (“Green Products”). Kassering (Swedish) För att bättre värna om vår jord bör denna elektroniska utrustning ej kasseras tillsammans med...
- Page 6 AOPEN DT22M-O Copyright Copyright of this publication belongs to AOpen Inc. AOpen reserves the right to change the content of this publication without obligation to notify any party of such changes or revisions. No part of this publication may be reproduced, transcribed, transmitted,...
- Page 7 AOPEN DT22M-O Safety Instructions 1. Please read these safety instructions carefully. 2. Please keep this User’s Manual for later reference. 3. Please disconnect this equipment from connecter before cleaning. Don’t use liquid or prayed detergent for cleaning. Use moisture sheet or cloth for cleanning.
- Page 8 AOPEN DT22M-O FCC notice This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This...
-
Page 9: Table Of Contents
AOPEN DT22M-O Table of Contents Packing List ..................11 1-1. Standard Accessories ..............11 System View ..................12 2-1. Front View ..................12 2-2. Rear View ..................12 2-3. I/O ports ..................13 2-4. Dimension ..................14 System Assembly ................15 3-1. - Page 10 We regret not informing about any changes in usage standards and other related information. AOpen Company reserves the right of altering or modifying the content of this manual. In case of any mistakes or incorrect descriptions, which include those on the products, AOpen makes no guarantee or commitments.
-
Page 11: Packing List
AOPEN DT22M-O 1. Packing List 1-1. Standard Accessories System USB cable Power adapter (65W, 19V/3.42A) VGA cable Power cord HDMI cable Notice: The pictures may look slightly different from the product you purchased, due to our constant product improvement effort. -
Page 12: System View
AOPEN DT22M-O 2. System View 2-1. Front View 2-2. Rear View... -
Page 13: I/O Ports
AOPEN DT22M-O 2-3. I/O ports Caution: When you install devices or cables, please removed DC jack at first to prevent inadvertently switched to cause system boot/ damage to system/electric shock. -
Page 14: Dimension
AOPEN DT22M-O 2-4. Dimension... -
Page 15: System Assembly
AOPEN DT22M-O 3. System Assembly 3-1. VESA-bracket support The system support standard 100x100mm VESA mount, so other VESA mount bracket followed this standard spec can be assembled. Please use the system attached VESA screw - M4, otherwise will be broken system’s VESA screw hole. -
Page 16: Side Mount Bracket Support
AOPEN DT22M-O 3-2. Side Mount bracket support Can option Side mount bracket, suggest assembly way as following... - Page 17 AOPEN DT22M-O...
-
Page 18: Specification
Front zero bezel sealed IPR design for IP65 and IK07 Rear VESA-mounting and Side-mounting design for various Kiosk applications RODUCT PECIFICATION Product Specification AOPEN openframe Touch Display Form AOPEN Digital Tile DT22M-O Factor Mechanical Design IPR sealed Metal and Glass for IP and IK grade... - Page 19 AOPEN DT22M-O Backlight LED backlight 21.5inch, Projected Capacitive Touch Panel Touch Panel 1.8mm Chemically Strengthened Glass Mosh 5 Surface Hardness Virtual Key Not support Touch controller PenMount PM1715 Touch IK07 Optional Anti-UV Design (ASTM G154 500HR Standard Certified) IPC Grade Touch...
- Page 20 AOPEN DT22M-O Carton Packing Dimension* 606x468x164mm HDMI Cable, USB Cable, VGA Cable, 65W Adapter, AC Accessory in BOX* Cable Optional peripheral Side Mount Bracket x12, 24*Padded M4 screws HDMI & VGA Resolution 1920x1080@60Hz...
-
Page 21: Osd
AOPEN DT22M-O 5. OSD Key Pad Keys Define: Total 6 keys -- A. SOURCE: Switch Input Source Display Channel ( HDMI or VGA) -- B. MENU: Activate OSD Menu -- C. SELECT: Select the OSD Menu screen section -- D. Down / Left (◄): Decrease setting or scroll down the menu bar -- E. -
Page 22: Appendix A: Troubleshooting
AOPEN DT22M-O Appendix A: TroubleShooting ● Non-functional Display 1. Make sure power is connected. 2. Please press the system power switch (ensure small power light at right rear of screen is on). 3. Please ensure HDMI cable or VGA cable is connected. -
Page 23: Appendix B: Touch Panel Maintainence And Cleaning
AOPEN DT22M-O Appendix B: Touch Panel Maintainence and Cleaning The maintenance and cleaning of the touch panel is quite simple. We recommend that you wipe it down with a clean, dry, and soft cloth regularly and use alcohol or isopropyl alcohol for decontamination and sanitization only when necessary. -
Page 24: Appendix C: Updating Touch Panel Firmware
AOPEN DT22M-O Appendix C: Updating Touch Panel Firmware If you currently have no problems with the touch panel, you do not have to upgrade firmware version.。 If need to update firmware, please follow the steps below: 1. Open “PenMount PCIMSet” and select “Field Update.” Select “Load Firmware”... - Page 25 AOPEN DT22M-O 3. If “PASS” is shown, update was successful. 4. If “FAIL” is shown, please contact us.
-
Page 26: Appendix D: Restricted Substances Survey
AOPEN DT22M-O Appendix D: Restricted Substances Survey...
