IP Multicast Stub Routing in AOS

Example Configuration

In the following example,
system common to other vendors, and the
on page 12, the
Stub Router
currently connected (primary or secondary).
Other vendor as Router 1:
ip multicast-routing
int s0.1 (PVC to the stub router, other configuration details omitted)
ip address 10.0.0.2 255.255.255.0
ip pim sparse-dense-mode
AOS as Stub Router:
ip multicast-routing
ip mcast-stub helper-address 12.1.1.1 (ip address of the media server)
int eth 0/1
ip address 10.1.0.1 255.255.255.0
ip mcast-stub downstream
ip mcast-stub helper-enabled
int eth 0/2
ip address 10.2.0.1 255.255.255.0
ip mcast-stub downstream
ip mcast-stub helper-enabled
int fr1.1 (PVC to the network router, other configuration details omitted)
ip address 10.0.0.1 255.255.255.0
ip mcast-stub upstream
dial-backup number 5551212 ppp 1
int ppp 1 (dbu to network, other configuration details omitted)
ip address negotiated
ip mcast-stub upstream
61200890L1-29.3A
is assumed to be a non-AOS product configured with an operating
Router 1
Stub Router
receives a default route from the peer router through whichever interface is
Copyright © 2005 ADTRAN, Inc.
is an AOS product. Though not shown in Figure 3
Example Configuration
13
