- Page 1 Crestron C2N-ANLZ Cresnet Analyzer ® Operations Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2006 Crestron Electronics, Inc.
-
Page 3: Table Of Contents
Troubleshooting... 13 Check Network Wiring... 13 Further Inquiries ... 14 Future Updates ... 14 Return and Warranty Policies ... 15 Merchandise Returns / Repair Service ... 15 CRESTRON Limited Warranty... 15 Operations Guide – DOC. 6473 Cresnet Analyzer Contents • i... -
Page 5: Cresnet ® Analyzer: C2N-Anlz
® Cresnet Analyzer: C2N-ANLZ Introduction Features and Functions Applications The C2N-ANLZ is used to diagnose and record Cresnet problems at customer installations. The C2N-ANLZ is capable of performing the following functions: Operations Guide – DOC. 6473 • ® Cresnet Analyzer records Cresnet data at customer installations for analysis by Crestron engineers •... -
Page 6: Specifications
Cresnet Analyzer Specifications Specifications for the C2N-ANLZ are listed in the following table. C2N-ANLZ Specifications ® 2 • Cresnet Analyzer: C2N-ANLZ SPECIFICATION Power Requirements Cresnet Power Usage Battery Backup (included) Memory Card (included) Size Format Data Logging Environmental Temperature Humidity... -
Page 7: Physical Description
Crestron C2N-ANLZ Physical Description This section provides information on the connections, controls, and indicators available on your C2N-ANLZ. C2N-ANLZ Physical View Operations Guide – DOC. 6473 Cresnet Analyzer ® Analyzer: C2N-ANLZ • 3 Cresnet... - Page 8 CONNECTORS, CONTROLS, & INDICATORS PWR Light Emitting Indicates the state of operation of the Diode (LED) C2N-ANLZ. Refer to “Operational Status” on page 10 for more information. NET LED Indicates Cresnet activity on the Cresnet bus. MARKER 1 & 2...
- Page 9 MEMORY Memory card slot for included removable multimedia memory card. The memory card can be inserted or removed when the C2N-ANLZ is not logging data (LOG LED is off). NET PORTS (2) Four-pin terminal block NET ports connect the C2N-ANLZ between the control system and the Cresnet network.
-
Page 10: Industry Compliance
Cresnet Analyzer Industry Compliance As of the date of manufacture, the C2N-ANLZ has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling. NOTE: This device complies with part 15 of the FCC rules. Operation is subject to... -
Page 11: Setup
Use Crestron power supplies for Crestron equipment. • Provide sufficient power to the system. CAUTION: Insufficient power can lead to unpredictable results or damage to the equipment. Please use the Crestron Power Calculator to help calculate how much power is needed for the system (http://www.crestron.com/calculators). •... -
Page 12: Memory Card
When installing the memory card, observe the following: Battery The C2N-ANLZ has a 9 Volt battery that is used as a backup in the absence of Cresnet power. To install a battery, use a #2 Philips screwdriver and perform the following: ®... -
Page 13: Uploading And Upgrading
However, before attempting to upload or upgrade, it is necessary to establish communication. Establishing Communication Use Crestron Toolbox for communicating with the C2N-ANLZ; refer to the Crestron Toolbox help file for details. There is a single method of communication; direct serial communication. -
Page 14: Operation
Cresnet Analyzer Operation The C2N-ANLZ can be operated from the buttons on the device or via console commands from a connected PC. Button Operation Using the buttons on the C2N-ANLZ, you can: Operational Status The PWR LED indicates the operational status of the C2N-ANLZ: Format a Memory Card Formatting a memory card will erase any files that are stored on the card. -
Page 15: Console Operation
Console Operation Use the C2N-ANLZ console commands to perform many of the functions available from the buttons on the C2N-ANLZ as well as retrieve information about the C2N-ANLZ and the log files stored on the memory card. Format a Memory Card Formatting a memory card will erase any files that are stored on the card. -
Page 16: Network Analyzer
C2N-ANLZ. To use the following console commands, communications must be established and a text console window must be opened as described on page 9: Advanced analysis tools are built into the C2N-ANLZ. These tools should only used under supervision of a Crestron engineer when required. For more information, contact Crestron. -
Page 17: Problem Solving
Use the Right Wire In order to ensure optimum performance over the full range of your installation topology, Crestron Certified Wire, and only Crestron Certified Wire, may be used. Failure to do so may incur additional charges if support is required to identify performance deficiencies because of using improper wire. -
Page 18: Further Inquiries
For assistance in your local time zone, refer to the Crestron website (http://www.crestron.com/) for a listing of Crestron worldwide offices. You can also log onto the online help section of the Crestron website to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features. -
Page 19: Return And Warranty Policies
Purchasers should inquire of the dealer regarding the nature and extent of the dealer's warranty, if any. CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 20 Crestron Electronics, Inc. Operations Guide – DOC. 6473 15 Volvo Drive Rockleigh, NJ 07647 (2014834) Tel: 888.CRESTRON 06.06 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
