Summary of Contents for Gorgy Timing LEDI 6

  • Page 1 LEDI 6 LEDI 6/S STANDARD, FLUSH-MOUNTED or WATERTIGHT CASE USER MANUAL...
  • Page 2 LEDI 6 – LEDI 6/S Fig.1 MOUNTING PRINCIPLE 2 x diam.4 STANDARD CASE Fig.2 Fig.3 PROG 230V 230 V Impuls. N° serie : Made in France PROG Fig.4 Input Input Use the lever to make the connections input 2 /8...
  • Page 3 LEDI 6 – LEDI 6/S LEDI Cotes FLUSH-MOUNTED case "6" "6/S" (mm) A 151 B 335 C 188 D 378 Fig.5 Wall LEDI recess Support 75mini MOUNTING PRINCIPLE WATERTIGHT Case Outer dimensions of clock Fig.6 Hang the case 1 - Thread...
  • Page 4 - Hook the case over the bracket. Flush-mounted case (fig. 5) - Prepare the wall support. LEDI 6: 335 x 151 x 75 mm. LEDI6/S: 415 x 198 x 75 mm - Position the support clip in the wall recess.
  • Page 5 LEDI 6 – LEDI 6/S 3.2 - STANDARD and WATERTIGHT cases 3.2.1 - Impulse or AFNOR code receiver In the case of a polarised impulse or AFNOR NFS 87-500 code receiver clock, connect the impulse or code input to terminal B1 and connect this to the bottom. The clock will then be automatically converted from autonomous to receiver version 3.2.2 - Radio-synchronised version...
  • Page 6 LEDI 6 – LEDI 6/S 6 - OPTIONS 6.1 - HOURLY PIP OUTPUTS With this option, any of the following may be obtained on terminal B4: - 4 pips, each lasting 200 ms, delivered on the hour: 1st pip: 59 min 57 sec...
  • Page 7 "D" is received. N.B.: - In the case of the LEDI 6 (indicating only hour and minute information), the date information is replaced by zeros and the day of the week in alphanumeric characters by three spaces. However, if this clock is an AFNOR NFS 87-500 receiver or is radio-synchronised, the date information is generated.
  • Page 8 LEDI 6 – LEDI 6/S WARNING ISOLATE BEFORE REMOVE COVER 8 /8...
