PR-UN1670
(CNE-8206MB-RS)

Operation Manual

All Rights Reserved. Copyright Rosen Entertainment Systems
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PR-UN1670 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rosen PR-UN1670

Summary of Contents for Rosen PR-UN1670

  • Page 1: Operation Manual

    PR-UN1670 (CNE-8206MB-RS) Operation Manual All Rights Reserved. Copyright Rosen Entertainment Systems...

  • Page 2: Table Of Contents

    CONTENTS OPERATION MANUAL........................1 TOTAL SYSTEM..........................3 1.1..........................3 NALOG UDIO 1.2....................3 CTUAL ONNECTION IAGRAM OPERATIONS..........................5 .........................5 2.1. ANEL BUTTONS ........................6 2.2. EMOTE ONTROL BASIC OPERATIONS........................8 3.1......................8 TART UP AND HUT DOWN 3.2........................9 ITLE AND OTTOM 3.3.

  • Page 3: Total System

    1 Total System 1.1.Analog Audio 1.2.Actual Connection Diagram...
  • Page 4 Speaker connection from 16pin harness White : Front left speaker+ Gray : Front right speaker + White/Black : Front left speaker – Gray/Black : Front right speaker – Green : Rear left speaker+ Purple : Rear right speaker + Green/Black : Rear left speaker – Purple/Black : Rear right speaker –...

  • Page 5: Operations

    2 Operations 2.1.Panel buttons Functions of Buttons 1. [NAVI] Button • Press this button to enter navi app. • Press this button to back to the last page. 2. [HOME] Button • Press this button to main menu. • Press this button to back to the last source. 3.

  • Page 6: Remote Control

    7. Internal microphone for Bluetooth mode 8. Receiver for IR-remote control 9. Disc indicator • Disc inside: show white. • No disc inside: show the illumination color which was set in settings. 10. DVD/CD slot • Insert a disc with the label on the top side into the DVD/CD slot until it will be inserted automatically.
  • Page 7 • Press this button to eject the disc. [POWER/SRC] Button • Press this button to change source. • Press this button more than 1 second to power on when the unit is power off. • Press this button more than 1 second to power off when the unit is power on. [0 - 9] Buttons •...

  • Page 8: Basic Operations

    Buttons • Press to manually select the next higher or lower station in Tuner and Satellite Radio modes. • Press to perform fast-forward or fast-backward searching. Press again to change the speed to 2x, 4x, 8x or 16x. • Press for movement of background source in Navigation mode. [ZOOM] Button •...

  • Page 9: Title And Bottom

    In case of restarting the ACC after 1), wait for more than 10 seconds before turning “ACC” switch on again. 3.2.Title and Bottom 1. Select the tab and enter the page 2. Back to menu or back to the current audio source. 3.

  • Page 10: Audio Mute-On / Audio Mute-Off

    • To change audio source by remote controller or SWC: 1. Press the “SRC” button, it will show next source toast. 2. Each time you continuously press the “SRC” button, active icon moves to the next. 3. If you don’t press the “SRC” button about 2 seconds, the source will be entered. *Note: If there is unavailable source, the icon will be disabled and the icon cannot be selected.

  • Page 11: Usb Mode

    Press “MUTE” button of titlebar again 4 USB Mode 1. Connect a U-disk to the USB cable. 2. The system will automatically detect the connected U-disk. 3. Press the Audio [ ] button to display Audio files list. 4. Press the Video [ ] button to display Video files list.
  • Page 12 Previous Track /Fast Backward button. Play/Pause button. Next Track/Fast Forward button. Repeat button. Shuffle button. Direct Searching button. Track list button. Album Art. Current ID3 info area. 10. Elapsed playing time indicator/Seek bar. USB Video Operations 1. Previous Video button 2.

  • Page 13: Hd Radiotm Operations

    3. Next Video button 4. Elapsed playing time indicator/Seek bar 5. Go to list menu mode 6. Hide Operation bar 7. Operation bar. USB Picture Operations 1. Previous picture button. 2. Play/Pause picture button. 3. Next picture button. 4. Go to list menu mode 5.
  • Page 14 1. Return to Main Menu 2. Time display 3. Frequency display, touch to automatically seek next station in the direction of higher frequencies 4. Station name 5. Loc/DX. It is used to set the station is local or dx. 6. Touch to change the next available sub channel 7.

  • Page 15: Sxm Operations

    6 SXM Operations This function is available when a Satellite Radio Receiver is connected through the dedicated connection.. Note: Satellite radio is a subscription service. Press the [SXM] button on Main Menu display. The system changes to the SXM. The SXM mode screen is displayed 1.

  • Page 16: Settings Operation

    7 Settings Operation 7.1.Main Settings Press [Settings] button on the Main menu screen. The Setting menu screen will be displayed. Contains Main、Camera、Style、Tabs. 7.2.Set Bottom Tabs A total of seven tabs are on the shortcut. Among them the third to the sixth users can customize. User can press [ or [ ] button to set different tabs.

  • Page 17: Audio Setup Menu

    7.4.Audio Setup Menu This menu contains: EQ、Speaker、Sub-Out、Volume EQ: Set the audio sound effect Speaker: Set the balance and fader Sub-Out: Set the sound level and crossover Volume: Set the volume and preamp for sources 7.5.Right/Left Hand Drive Mode To change the location of home button of Apple CarPlay: Go to “Video Setting”...
  • Page 18 Touch the iPod Audio icon. iPod Audio mode screen will be displayed. *Note1: The USB cable with the label of “iPod/iPhone” only supports iPod Audio mode. *Note2: When the device which does not support CarPlay or is disabled CarPlay on iPhone is connected, this system will work in the iPod Audio mode.

  • Page 19: Pandora Audio

    • Touch the [ ] key to display the current play list, touch again to display the ID3 Information. ALBUM ART WORK ID3 INFORMATION 10. PROCESS BAR • Touch the [ ] on seek bar and drag it to any position where you want to start playback. 9 Pandora Audio Launch Pandora application on your iPhone.
  • Page 20 • When you press “VOICE” button, “Siri” screen is displayed. To go back to native screen: • Press “HOME” button, Main menu screen is displayed. • Press “MAP” button, native navigation screen is displayed. • Press “Rosen” button, native screen is displayed.
  • Page 21 To start Siri (There are 2 ways to use Siri.) Press “VOICE” button of panel. Press “VOICE” button of SWC. Press and hold “SRC” button of SWC or “SRC” button of remote controller more than 600 milliseconds. Siri screen will be displayed. Talk your request.

  • Page 22: Native Navigation

    11Native Navigation To initialize: (First power-up timing only) Basically, just touch “Next” button. If you want, you can customize settings. To Set Destination 1. Touch Navigation MENU “ ” icon. 2. Touch “New Route” button. 3. There are several ways to select your destination. Choose one of them. 4.
  • Page 23 To Start Guidance Simulation 1. Touch Navigation MENU “ ” icon. 2. Touch “Route Summary” button. 3. Touch “ ” icon. 4. Select “Simulation”.

  • Page 24: Bluetooth Operations

    12 Bluetooth Operations 12.1. Bluetooth Paring 1. Turn on the power of the cellular phone you wish to register. 2. Touch the [ ] key to display the Device Select screen. 3. Touch the [ ] key to display the Inquiring Device screen. 12.2.

  • Page 25: Bluetooth Audio Player Operations

    12.4. Bluetooth Audio Player Operations Confirm that Bluetooth device is connected. Press “HOME” button and choose “A2DP” source. Bluetooth Audio mode screen will be displayed. Pausing playback • Touch the [ ] key during playback. Playback pauses. • To resume playback, touch the [ ] key.

  • Page 26: Disc Player Operations

    *Note: If the reverse cable is connected correctly to the car, the head unit will go to camera mode automatically when the car is in reverses. 14 DISC Player Operations Confirm that a disc is inserted. Press “HOME” button and choose “Disc” source. Play Video Previous Track /Fast Backward Button Elapsed playing time indicator/Seek bar...
  • Page 27 Previous Track /Fast Backward button. Play/Pause button. Next Track/Fast Forward button. Repeat button. Shuffle button. Direct Searching button. Track list button. Album Art. Current ID3 info area. 10. Elapsed playing time indicator/Seek bar. 11. Source shortcut buttons. Playing picture files in disc 1.

  • Page 28: Hdmi Operations

    3. Next picture button. 4. Go to list menu mode 5. Hide Operation bar and Shortcut bar 6. Operation bar. 15 HDMI Operations External peripheral devices, including android or iPhone etc. can be connected to the unit through HDMI Line. Then you can see the phone screen on the HDMI app, you can watch movie which in your phone on unit.
  • Page 29 WARNING  For you safety,the driver should not watch any video sources and/or operate the controls while driving.Please note that watching and operating any video sources while driving are prohibited by law in some countries. Also, while driving, keep the volume to a level at which external sounds can be heard. ...
