RECOMMENDED TUBE DIAMETERS
UNIT
SIZE
018
024, 030
036-048
060
* For tube set over 50 ft, consult Long-Line Application Guideline.
UNIT
SIZE
018
024
030
036
042
048
060
* TXV must be installed when indoor coil is not equipped with a TXV. TXV listed is for any approved
coil combination. All TXVs are bi-flow, hard shutoff.
®
CERTIFICATION APPLIES ONLY WHEN THE
COMPLETE SYSTEM IS LISTED WITH ARI.
As an ENERGY STAR
Partner. Bryant has
determined that this
product meets the
ENERGY STAR guidelines
for energy efficiency.
TUBE LENGTH LIQUID TUBE
(Ft)* DIAMETER (In.)
0 to 50 3/8

METERING DEVICE

OUTDOOR
SERIES PISTON
B
B
B
B
B
A
A
SM
CERTIFICATION OF MANUFACTURING SITE.
—3—
VAPOR TUBE
DIAMETER (In.)
5/8
3/4
7/8
1-1/8
INDOOR
TXV*
42 KHATX0901HSO
49 KHATX1001HSO
52 KHATX1101HSO
59 KHATX1201HSO
63 KHATX1201HSO
70 KHATX1301HSO
73 KHATX1401HSO
