- Page 1 RADIO CASSETTE RECORDER WITH CD RRCD 4101 BEEZZ...
-
Page 2: Care And Safety
CARE AND SAFETY ______________________________ ENGLISH To ensure that this device provides you with long-term satisfaction and enjoyment, please observe the following instructions. This device is designed for the recording and playback of audio signals. Any other use is expressly prohibited. Protect the device, the CDs and cassettes from rain, moisture (dripping or splashing water), sand and heat. - Page 3 OVERVIEW ___________________________________________ Controls e e z z RADIO CASSETTE RECORDER WITH CD RADIO TAPE/ VOL. BAND OPEN/CLOSE FM STEREO 3 4 8 PLAY/ PAUSE F-SKIP OPER. PLAY/PAUSE REPEAT PROG REPEAT PROG. R-SKIP STOP TRACK CLOSE TAPE DIRECTION General information Function switch for selecting the input sources RADIO »...
- Page 4 OVERVIEW ___________________________________________ For switching to mono reception in case of poor FM MONO. .FM ST. stereo reception (on the back of the device). FM MONO FM ST Tape unit Press here to close the cassette compartment. CLOSE 3 4 8 Starts recording.
-
Page 5: Power Supply
POWER SUPPLY ___________________________________ Mains operation Note: Check that the mains voltage on the type plate (on the bottom of the device) corresponds to your local mains supply. If this is not the case, contact your specialist dealer. Plug the mains cable supplied (in the battery compartment) into the »AC «... - Page 6 POWER SUPPLY ______________________________________ Important notes for users in the U.K. Mains plug This apparatus is fitted with an approved moulded 13 Amp plug. To change a fuse in this type of plug proceed as follows: Remove fuse cover and fuse. Fix new fuse which should be a BS1362 5 Amp, A.S.T.A.
-
Page 7: Adjusting The Volume
VOLUME/TONE ____________________________________ Adjusting the volume Adjust the volume using the » VOL« knob. Activating the Ultra Bass System VOL. This function boosts the bass frequencies. Press »ULTRA BASS SYSTEM« to switch the function on and off. Listening with headphones Connect the headphones to the headphones socket » «... -
Page 8: Radio Mode
RADIO MODE _______________________________________ Antennas For FM (VHF) stations extend the telescopic antenna and tilt and turn it to achieve the best reception. Note: If the FM signal is too strong, it is advisable to push in the telescopic antenna. In case of poor reception: If your FM stereo reception is impaired by interference due to insufficient signal strength, this can sometimes be rectified by setting the »... -
Page 9: General Instructions For Laser Devices
CD MODE _________________________________________ General instructions for laser devices You will find a symbol similar to the one shown here on the bottom of the device. CLASS 1 LASER PRODUCT means that the laser is designed in such CLASS 1 a way as to ensure that the maximum permissible emission value cannot be LASER PRODUCT exceeded under any circumstances. - Page 10 CD MODE _____________________________________________ Selecting a different track During playback, keep pressing »F-SKIP« or »R-SKIP« until the number of the track you want to hear appears in the display. – Playback of the selected track starts automatically. Searching for a passage within a track During playback, press »F-SKIP«...
- Page 11 CD MODE _____________________________________________ Playing back the track memory To start the playback of the track memory, press » PLAY/PAUSE«. – Playback begins with the first stored track. • • – The »PROG « and »PLAY/PAUSE « indicators light up. To stop playback of the track memory press » STOP«. Changing from the track memory to normal playback To stop playback of the track memory press »STOP«.
-
Page 12: Tape Mode
TAPE MODE __________________________________________ Preparation FM ST Switch on the radio recorder by moving the »RADIO TAPE/ OFF CD« 3 4 8 function switch to » TAPE«. PLAY/ PAUSE F-SKIP OPER. PLAY/PAUSE Press » « to open the tape compartment. REPEAT PROG REPEAT PROG. - Page 13 TAPE MODE ___________________________________________ Recording from the radio Place a cassette with the protection tabs intact in the tape compartment and use » « or » « to find the correct position on the tape. Set the »RADIO TAPE/OFF CD« switch to » RADIO« and tune in to RADIO the desired radio station.
-
Page 14: Cleaning The Tape Drive
INFORMATION _____________________________________ Cleaning the tape drive To guarantee good recording and playback quality, clean the parts shown (1, 2, 3) after every 50 hours of use, or once a month. Open the tape compartment, moisten a cotton swab with alcohol or a special head-cleaning fluid and clean the idler (3), the capstan (2) and the magnetic heads (1). -
Page 15: Troubleshooting
TROUBLESHOOTING ________________________ If a fault occurs, first refer to this information before you take the device for repair. If you are unable to rectify the fault using the information given here, contact your local dealer or service specialist. Under no circumstances should you attempt to repair the radio recorder yourself, as this would invalidate the guarantee. - Page 16 Grundig AG Beuthener Str. 41 • D-90471 Nürnberg • http://www.grundig.com 72011-401.1500 •...
