1.2 I Technical specifi cati ons and parts list

1.2.1 Technical specifi cati ons
Energy source
Working pressure
Feed hose and Lead hose assembly
length
Largeur de la bouche d'aspirati on (cm)
Minimum power required by the
booster pump
1.2.2 Cleaner marking
1.2.3 Hoses marking
Sucti on port
: Lead hose (marked "Polaris Lead Hose")
: Feed hose (marked "Polaris")
: Swivel N°1
: Swivel N°2
: Universal wall fi tti ng assembly UWF
: Relief valve
P280 P380
Booster pump coupled to the fi ltrati on system
2.2 bar 1.8 bar
7 cm
1 HP (if the distance from the equipment room is < 15 metres)
1.5 HP or more (if the distance from the equipment room is > 15
: Lead hose fl oats, spaced 60 to 90 cm apart
: Feed hose fl oats, spaced 45 to 90 cm apart
: In-line fi lter assembly
: Back-up valve
: Connecti on kit (P3900 Sport) or att ach clamp (P280/P380)
P3900 Sport
Maximum 2.2 to 2.6 bar
9.60 m
6 cm
metres)
: Filter bag
: Head fl oat
: Cleaner body
: Sweep hose
: Sweep hose cleaning brush
: Sucti on hose
: Filter bag clamping clip (P280/P380)
: Setti ng the thrust jet
: Adjusti ng screw of the sweep hose
