- Page 1 280/ 380/ 3900 SPORT Instructi ons for installati on and use - English Hydraulic cleaner Translati on of the original instructi ons in French More documents on: www.zodiac.com H0647000.A - 2018/07...
- Page 2 WARNINGS GENERAL WARNINGS • Failure to respect the warnings may cause serious damage to the pool equipment or cause serious injury, even death. • Only a person qualifi ed in the technical fi elds concerned (electricity, hydraulics or refrigerati on) is authorised to perform any servicing or repairs to the appliance.
-
Page 3: Table Of Contents
Before handling the appliance, it is vital that you read this installati on and user manual, as • well as the "warnings and warranty" booklet delivered with the appliance. Failure to do so may result in material damage or serious or fatal injury and will void the warranty. Keep and pass on these documents for later consultati on during the appliance's service life. -
Page 4: ❶ Specifi Cati Ons
P380 P3900 Sport Cleaner Feed hose and Lead hose assembly Blue and red restrictor discs (The blue disc is already installed for P280 and P380) Ultra-thin bag Dual-capacity silt bag Standard silt bag Leaf bag Disposable bags (EZ Bag) x 6 Tail Sweep Pro®... -
Page 5: I Technical Specifi Cati Ons And Parts List
: Feed hose fl oats, spaced 45 to 90 cm apart : Swivel N°1 : In-line fi lter assembly : Swivel N°2 : Back-up valve : Universal wall fi tti ng assembly UWF : Connecti on kit (P3900 Sport) or att ach clamp (P280/P380) : Relief valve... -
Page 6: ❷ Installati On
Feed hose Swivel : A deviati on is created on this piping to supply the booster pump. : Polaris® pressure cleaners are connected to the sucti on port transformed into a discharge port : The venturi eff ect generated by the jets transforms the water... -
Page 7: I Installing The Feed Hose On The Sucti On Port
2.2 I Installing the feed hose on the sucti on port • Separate the universal wall fi tti ng (UWF) ( ) from the quick disconnect ( ), see picture • Screw the universal wall fi tti ng (UWF) ( ) with the blue or red fl ow restrictor disc ( ) onto the sucti on port opening ). -
Page 8: I Adjusti Ng The Lead Hose
2.3 I Adjusti ng the lead hose 2.3.1 Measuring and cutti ng the lead hose • Measure the deepest point of the pool (for example : 1.80 meters). • Lay out the leader hose secti on (labelled ) beside the pool. •... -
Page 9: I Connect The Lead Hose To The Cleaner
• Att ach the fi lter bag clamping clip on the hose, see picture • Place the head fl oat in accordance with the following indicati ons, see picture - P280: positi on at a distance of 1.3 to 2.5 cm. - P380: Fully embed the head fl oat. -
Page 10: I Connect The Lead Hose To The Feed Hose
2.5 I Connect the lead hose to the feed hose • Unscrew the swivel. • Assemble the lead hose and the feed hose, screw the swivel to fasten together. 2.6 I Checking that the length of the assembled hoses is suffi cient •... - Page 11 2.6.1 If the hose is too long = Cut the feed hose • Don't cut the lead hose : it must stay the equal to the depth of the pool, see "2.3 I Adjusti ng the lead hose". • Remove the quick disconnect from the sucti on port : simultaneously unscrew and pull. See picture : simultaneously unscrew and pull.
-
Page 12: ❸ Use
• Before starting the cleaner, check the rotational speed of the wheel (rpm). For maximum efficiency, the cleaner must rotate and a speed of: - between 28 and 32 rpm (P280-P380). - between 32 and 34 rpm (P3900 Sport). • Place the cleaner on its side (2 wheels in contact with the ground) and make a marking on the wheel ( •... - Page 13 3.2.1 If the water fl ow rate is insuffi cient • In the event that a valve is installed on the cleaner line, open fully to allow the water to flow freely to the cleaner. • Check whether the hoses, fittings and ball joints have leaks. •...
-
Page 14: I Confi Guring The Sweep Hose
To increase movement 3.4 I Setti ng the thrust jet • The default setti ng diff ers depending on the cleaner: P280 P380 P3900 Sport • The jet is located at the rear of the cleaner and thrusts the cleaner in a given directi on. -
Page 15: ❹ Maintenance
• To reinstall the bag, align the markings between the connector and the cleaner's sucti on hose, then click it in place. • Att ach the fi lter bag clamping clip (P280 - P380) onto the hose or place the Velcro strips (P3900 Sport). P280 - P380 P3900 Sport Tip: A dry bag is easier to clean It is easier to clean the bag when it is dry. -
Page 16: ❺ Troubleshooti Ng
• Check the positi oning of the rear thrust jet, see "3.4 I Setti ng the thrust jet". and/or does not P280-P380: make contact with • Check that the blue fl ow restrictor disc is properly installed in the universal fi tti ng (UWF) to the pool bott om. - Page 17 • When the cleaner is in operation, out of water hold upside down and look inside the suction hose. You should see 3 separate jets (P380) or 2 separate jets (P280) with the same flow rate. Contact your retailer if you cannot visualise the jets.
- Page 18 Votre revendeur Your retailer Modèle appareil Appliance model Numéro de série Serial number Pour plus d’informati ons, enregistrement produit et support client : For more informati on, product registrati on and customer support: www.zodiac.com ZODIAC® is a registered trademark of Zodiac Internati onal, S.A.S.U., used under license.
