Page 1: Table Of Contents
Operating Manual TUBULAR GEL OPzV 2V CELLS 1. Safety 4.1 Discharging 1.1 Do’s 4.2 Charging 1.2 Do Not’s 4.2.1 Commissioning Charge 2. Delivery and Storage 4.2.2 IU Charging 2.1 Receiving Inspection 4.2.3 IUI Charging 2.2 Storage 4.2.4 Charging with a Solar Charge Controller 2.3 Unpacking and Handling... - Page 2 • Analyzing and reducing hazards involved in performing electrical work • Installing and configuring batteries No responsibility is assumed by Discover for any consequences arising out of the use of this material. Visit discoverbattery.com for the most recent version of published documents.
-
Page 3: Safety
Safety 1.1 Do’s • Do protect terminals from short circuit before, during, and after installation • Do wear electrically insulated gloves • Do use electrically insulated tools • Do wear eye protection • Do wear safety toe boots / shoes •... -
Page 4: Unpacking And Handling
Seismic forces should also be considered. • The installation should provide for adequate structural support and exposure to the minimum possible vibration. • Discover provides a variation of special designed OPzV 24VDC and 48VDC rack solutions. For more information please ®... -
Page 5: Cells In Series Strings
• The current during both discharge and charge will be split according to the capacity or age of the batteries respectively. 3.4 Cells in Series Strings • Discover® Tubular Gel cells may be connected in series to increase system voltage. • In the case of each series connected string, only use batteries of the same voltage, capacity, design and age. -
Page 6: Commissioning Charge
The initial charge is very important for the future battery operation and the battery’s service life. It is performed as a “Commissioning Charge” as listed in paragraph 4.2.1. Keep records in the battery’s logbook. Discover Commissioning Logs are online available at discoverbattery.com/en/resources/... -
Page 7: Charging
35°C 2.30 Vpc During commission, measure the cell voltage of the cells and after commissioning, measure the cell voltage and surface temperature of each cell and log this data. Discover Commissioning Logs are online available at discoverbattery.com/en/ resources/ 4.2.2 IU Charging •... -
Page 8: Charging With A Solar Charge Controller
current has dropped to this value during absorption phase and limit the voltage to 2.65V per Cell. The balance phase should last max 1-4 hours. The battery should be considered fully charged when the individual cell voltages have not risen for a period of 1 hours or the inverter/charger adjust to float voltage. Voltage limit: 2.35 V/Cell at 20°C/(68°F) Bulk/Absorption Constant current limit: 20A per 100Ah C10 rating... -
Page 9: Temperature Limits
Check for any visible defects such as cracked jars, loose terminal posts and oxidized connectors. To avoid leakage currents and the associated risk of fire, keep the battery dry and clean. Clean with clear water. Do not use any solvents or detergents. Avoid electrostatic charges. Discover Maintenance Logs are online available at discoverbattery.com/en/resources/ BI-ANNUAL MAINTENANCE •... -
Page 10: Faults
Should faults be detected in the battery or the charging device, contact your servicing dealer immediately. Keeping records of all measured data will simplify fault detection and corrective action. A service contract with your servicing Discover® dealer will help to detect faults in time. -
Page 11: Definitions & Abbreviations
11. Definitions and Abbreviations • Ampacity: The allowable current-carrying capacity of a conductor measured in amps. Ampacity is the current, in Amperes, that a conductor can carry continuously under the conditions of use without exceeding its temperature rating. • Battery Capacity: The power a battery can deliver from full charge at standard temperature, and at a specified (usually C10) discharge rate.
