805-0022 REV D
Operating Manual
14-12-3000 / 14-24-3000
14-36-3000 / 14-48-3000
2
2
2
2
2
3
3
3
3
3
3
3
4
4
5
5
5
5
5
6
6
6
6
5.4 Installation
4-13511 Crestwood Place,
Richmond, BC, V6V 2E9, Canada
discoverbattery.com
6
7
8
8
8
8
8
8
8
9
10
10
10
10
10
11
11
12
13
14
15
16
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DISCOVER 14-12-3000
Summary of Contents for DISCOVER 14-12-3000
-
Page 1: Table Of Contents
3.1 Integrated Battery Management System (BMS) 8.3 Battery Firmware 3.2 Fuse 9. Troubleshooting 3.3 Protections 10. Recycling and Disposal 4. Handling 11. 14-12-3000 Technical Specifications 5. Installation 12. 14-24-3000 Technical Specifications 5.1 Tools 13. 14-36-3000 Technical Specifications 5.2 Battery Location 14. 14-48-3000 Technical Specifications 5.3 Securing Battery... -
Page 2: Safety
▲ WARNING For wet and electrically uninsulated working conditions, electric shock risk is high, and can cause injury and death. Model Nominal System Voltage Maximum System Voltage 14-12-3000 12 V 14.6 V 14-24-3000 24 V 29.2 V 14-36-3000 36 V 43.8 V... -
Page 3: Chemical Risk
(such as high power anti-parallel diodes or braking resistor systems), are subject to high voltage transients that may result in damage to the internal battery pack protection system which may result in unsafe situations. Please consult Discover Battery technical support before directly connecting any motor loads. 1.9 Transportation If the battery is not installed in equipment, it must be transported in the original package or equivalent. -
Page 4: Current Protections
Maximum Operating Limits 14-12-3000 14-24-3000 14-36-3000 14-48-3000 150 Adc 114 Adc 76 Adc 57 Adc Continuous Charge Current 150 Adc 114 Adc 76 Adc 57 Adc Continuous Discharge Current 150 Adc 150 Adc 150 Adc 114 Adc 20 Minute Discharge Current... -
Page 5: Design Features & Components
• A blown fuse requires replacement by a qualified installer - contact your Discover installer. 3.3 Protections The BMS will open the internal relay to protect against operation outside of maximum specifications. During a protection the key LED will flash at 1 Hz. -
Page 6: Installation
5. Installation ▲ WARNING! Read Safety Section before installing the battery. ▲ CAUTION! Do not install AES LiFePO batteries in series. Select the appropriate AES battery model for the voltage of your system. 5.1 Tools • Insulated tools must be used •... -
Page 7: Parallel Battery Wiring
Washers ARE NOT Washers ARE NOT compressed! compressed! Copper compression lug M8” bolt (supplied with battery) Lock washer (supplied with battery) Terminal hardware Terminal hardware IS bottomed out! Shrink-wrap to IS bottomed out! Flat washer (supplied with battery) color-code the cable Battery cable lug Ensure nothing is between Terminal surface... -
Page 8: Commissioning Parallel Systems
Discover Battery. For Closed Loop and Open Loop configuration details please refer to the appropriate Application Note for your Power Conversion device available from the Discoverbattery.com website, or contact your Discover Battery provider for assistance. 7. Operation ▲ CAUTION! Review operating limits. -
Page 9: Open Loop Charge Curve
Multi voltage chargers are constructed using transformers that may be capable of producing spikes that exceed the maximum ratings of the Discover AES Battery. You must ensure that the charger being supplied: • Meets the recommended charge curve •... -
Page 10: Discharging
▲ NOTE! Recommended charge current is 0.5C Cell Modules Absorption Termination Model Bulk Current in Series Voltage Charge Current 14-12-3000 150 Adc maximum 13.6 V 14-24-3000 114 Adc maximum 27.2 V I2 ≤ 2 A 14-36-3000 12 S 76 Adc maximum 40.8 V... -
Page 11: Battery Firmware
• All battery cables and their connections should be tight, intact, and NOT broken or frayed • Replace any damaged batteries • Replace any damaged cables • Ensure correct torque is used for the terminal bolts 8.3 Battery Firmware Consult the Discoverbattery.com website for the latest battery firmware versions. If a battery firmware update is require, ensure this is done by a qualified and authorized person using the AES Dashboard software tool. -
Page 12: Recycling And Disposal
10. Recycling and Disposal Batteries must not be mixed with domestic or industrial waste. Discover AES batteries are recyclable and must be processed through a recognized recycling agency or dealer. Please contact Discover or your servicing dealer for details. -
Page 13: 12-3000 Technical Specifications
12. 14-12-3000 TECHNICAL SPECIFICATIONS Electrical Specifications Storage Temperature Range -20°C/45°C (-4°F/113°F) Operational Specifications Nominal Voltage 12.8 V Charge Voltage 13.6 V Battery Management System (BMS) Integrated, with Solid State Field Replaceable Relay (SSR) Maximum Voltage 14.6 V Cell Balancing Passive balancing when Minimum Voltage 11.2 V... -
Page 14: 24-3000 Technical Specifications
13. 14-24-3000 TECHNICAL SPECIFICATIONS Electrical Specifications Operational Specifications Nominal Voltage 25.6 V Battery Management System (BMS) Integrated, with Solid State Field Replaceable Relay (SSR) Charge Voltage 27.2 V Cell Balancing Passive balancing when Maximum Voltage 29.2 V Cell Voltage > 3.35 V Minimum Voltage 22.4 V Non-Volatile Memory... -
Page 15: 36-3000 Technical Specifications
14. 14-36-3000 TECHNICAL SPECIFICATIONS Electrical Specifications Discharge Temperature Range -20°C/50°C (-4°F/122°F) Storage Temperature Range -10°C/30°C (14°F/86°F) Nominal Voltage 38.4 V Operational Specifications Charge Voltage 40.8 V Maximum Voltage 43.8 V Battery Management System (BMS) Integrated, with Solid State Field Replaceable Relay (SSR) Minimum Voltage 33.6 V... -
Page 16: 48-3000 Technical Specifications
15. 14-48-3000 TECHNICAL SPECIFICATIONS Electrical Specifications Storage Temperature Range -10°C/30°C (14°F/86°F) Operational Specifications Nominal Voltage 51.2 V Charge Voltage 54.4 V Battery Management System (BMS) Integrated, with Solid State Field Replaceable Relay (SSR) Maximum Voltage 58.4 V Cell Balancing Passive balancing when Minimum Voltage 44.8 V Cell Voltage >...
