Tyco Fire Product CENTRAL 3 Instruction Manual

Sprinkler
Head Cabinet
Central Sprinkler Company
451 North Cannon Avenue, Lansdale, Pennsylvania 19446
Product
Description
Central Sprinkler Head Cabinets
are constructed of a metal enclosure
with a hinged cover designed to
provide on-site storage of an
emergency supply of sprinkler heads
and a sprinkler head wrench.
NFPA 13 requires a representative
number of each type of sprinkler
head used in a sprinkler system to be
stored in a cabinet on-site to allow for
immediate removal and replacement
of sprinklers which may have
operated or become damaged.
Central Sprinkler Head Cabinets
are manufactured of heavy gauge
steel with knock-outs to
accommodate either 1 ⁄ " or
2
threaded sprinkler heads and are
painted an attractive red enamel.
They are available in three (3), six (6)
or twelve (12) head capacity.
Model: Sprinkler Head Cabinet
Style: 3, 6 or 12 head
Standard Finish: Red enamel
Mfgr. Source: Non-domestic
Capacity:
Dimensions:
3 head - 5" high x 7
6 head - 5" high x 14" long x 3
12 head - 5" high x 14
Weight: 3 head - 1.5 lbs.
6 head - 2.3 lbs.
12 head - 4 lbs.
3 ⁄ " N.P.T.
4
Hd. Cab.
Technical
Data
3 sprinkler heads
6 sprinkler heads
12 sprinkler heads
1 ⁄ " long x 2 1 ⁄ " deep
2 2
1
⁄ " deep
4
3 ⁄ " long x 5" deep
4
Hd. Cab.
11-94
3, 6 & 12
Head
Sprinkler
Head
Cabinet
No. 28-6.0
