Bryant 604B User's Information Manual

NOTE: Read the entire instruction manual before starting the
installation.
SAFETY CONSIDERATIONS
Installation and servicing of air-conditioning equipment can be
hazardous due to system pressure and electrical components. Only
trained and qualified personnel should install, repair, or service
air-conditioning equipment.
Untrained personnel can perform basic maintenance functions of
cleaning coils and filters. All other operations should be performed
by trained service personnel. When working on air-conditioning
equipment, observe precautions in the literature, tags, and labels
attached to the unit, and other safety precautions that may apply.
Follow all safety codes. Wear safety glasses and work gloves. Use
quenching cloth for unbrazing operations. Have fire extinguisher
available for all brazing operations.
Recognize safety information. This is the safety-alert symbol
When you see this symbol on the product or in instructions or
manuals, be alert to the potential for personal injury.
Understand the signal words — DANGER, WARNING, CAU-
TION, and NOTE. Danger identifies the most serious hazards,
which will result in severe personal injury or death. Warning
indicates a condition that could cause serious personal injury or
death. Caution is used to identify unsafe practices, which would
result in minor personal injury or product and property damage.
NOTE is used to highlight suggestions which will result in
enhanced installation, reliability, or operation.
Note to Installer:This manual should be left with the equipment
user.
WARNING: Do not store or use gasoline or other
flammable vapors and liquids in the vicinity of this or any
other appliance. Failure to follow this warning could
result in fire, serious injury, or death.
WARNING: Do not use this unit if any part has been
under water. Immediately call a qualified service techni-
cian to inspect the unit and to replace any part of the
control system which has been under water. Failure to
follow this warning could result in electrical shock, fire,
serious injury, or death.
WARNING: Before performing recommended mainte-
nance, be sure the main power switch to unit is turned off.
Electric shock could cause serious injury or death.
STARTING OR SHUTTING UNIT OFF
1. To start the unit:
a. Turn on the electrical power supply to unit.
User Information Manual
User Information Manual
604B
604B
SINGLE-PACKAGED ELECTRIC HEAT PUMP
SINGLE-PACKAGED ELECTRIC HEAT PUMP
WITH PURON® (R-410A) REFRIGERANT
WITH PURON® (R-410A) REFRIGERANT
.
—1—
Cancels: New
Fig. 1—Unit 604B
b. Select temperature and set SYSTEM switch or MODE
control to desired mode.
2. To shut unit off:
NOTE: If the unit is being shut down because of a malfunction,
call your dealer as soon as possible.
a. Set system SWITCH or MODE control to OFF.
b. Turn off the electrical power supply to unit.
OPERATING YOUR HEAT PUMP
The operation of your heat pump system is controlled by the
indoor thermostat. You simply adjust the thermostat and it
maintains the indoor temperature at the level you select. Most
thermostats of heat pump systems have 3 controls: a temperature
control selector, a FAN control, and a SYSTEM or MODE control.
Refer to your thermostat owner's manual for more information.
To better protect your investment and to eliminate unnecessary
service calls, familiarize yourself with the following facts:
1. During heating, increasing the thermostat setting more than
2°F may cause the supplemental heaters to be turned on for
a short period of time to satisfy the thermostat. Needless use
of the supplementary heat reduces potential energy savings.
OM02–62
4–03
C99064
