604D- - - - A AND 607C- - - - A
LEGACYt AND PREFERREDt 13 AND 14 SEER
SINGLE- - PACKAGED HEAT PUMP SYSTEM
WITH PURON (R- - 410A) REFRIGERANT SINGLE AND THREE PHASE
2 - - 5 NOMINAL TONS (SIZES 24- - 60)
Owner's Information Manual
Fig. 1 - - Unit 604D- - - - A
For your convenience, please record the model and serial numbers of your new equipment in the spaces
provided. This information, along with the installation data and dealer contact information, will be helpful
should your system require maintenance or service.
UNIT INFORMATION
Model # _____________________________________
Serial # ______________________________________
ACCESSORIES (List type and model #)
_____________________________________________
_____________________________________________
_____________________________________________
A09034
NOTE TO EQUIPMENT OWNER:
NOTE TO INSTALLER:
This manual must be left with the equipment owner.
Fig. 2 - - Unit 607C- - - - A
INSTALLATION INFORMATION
Date Installed ________________________________
DEALERSHIP CONTACT INFORMATION
Company Name_______________________________
Address______________________________________
_____________________________________________
Phone Number _______________________________
Technician Name _____________________________
_____________________________________________
1
A09033
Advertisement
Related Manuals for Bryant 604D--A
Summary of Contents for Bryant 604D--A
- Page 1 604D- - - - A AND 607C- - - - A LEGACYt AND PREFERREDt 13 AND 14 SEER SINGLE- - PACKAGED HEAT PUMP SYSTEM WITH PURON (R- - 410A) REFRIGERANT SINGLE AND THREE PHASE 2 - - 5 NOMINAL TONS (SIZES 24- - 60) Owner’s Information Manual A09034 A09033...
- Page 2 SAFETY CONSIDERATIONS CAUTION Improper installation adjustment, alteration, service, maintenance, or use can cause explosion, fire, electrical shock, or other CUT HAZARD conditions which may cause death, personal injury, or property damage. Consult a qualified installer, service agency, or your Failure to follow this caution may result in personal injury. distributor or branch for information or assistance.
- Page 3 sorbed from the outside air. So, to maintain energy- -efficient opera- instance of filter grilles, the filters can simply be removed from the tion, your unit has an automatic defrost mode. grille and replaced. The other typical application is an accessory filter rack installed in- The defrost mode starts at a preset time interval of 60 minutes, al- side the unit itself.
- Page 4 Catalog No:OM604D---607C ---02 Edition Date: 08/09 Copyright 2009 Bryant Heating & Cooling Systems, 7310 W. Morris St. Indianapolis, IN 46231 Replaces: OM604D--- 607C--- 01 Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
