M.2 (S80) 3TI7
Customer:
Customer
Part
Number:
Innodisk
Part
Number:
Innodisk
Model Name:
Date:
Innodisk
Customer
Approver
Approver

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the InnoAGE M.2 (S80) 3TI7 and is the answer not in the manual?

Questions and answers

Related Manuals for Innodisk InnoAGE M.2 (S80) 3TI7

Summary of Contents for Innodisk InnoAGE M.2 (S80) 3TI7

  • Page 1 M.2 (S80) 3TI7 Customer: Customer Part Number: Innodisk Part Number: Innodisk Model Name: Date: Innodisk Customer Approver Approver...

  • Page 2: Table Of Contents

    InnoAGE M.2 (S80) 3TI7 Table of contents LIST OF FIGURES ............................... 6 1. PRODUCT OVERVIEW ............................7 1.1 I AGE M.2 (S80) 3TI7 ............. 7 NTRODUCTION OF NNODISK 1.2 P ....................... 7 RODUCT IEW AND ODELS 1.3 SATA I ........................... 8 NTERFACE 2.
  • Page 3 InnoAGE M.2 (S80) 3TI7 3.13 Q ............................. 24 UICK RASE 3.14 W ..........................24 RITE ROTECT 3.15 S AGE SSD ......................24 ANITIZING 4.1 I AGE M.2 (S80) 3TI7 P ................26 IRECTIONS 4.2 E AGE M.2 (S80) 3TI7 ............26 LECTRICAL ONNECTIONS FOR 4.3 D...
  • Page 4 InnoAGE M.2 (S80) 3TI7 EVISION ISTORY Revision Description Date V1.0 First Release Apr., 2020 V1.1 Correct part number July., 2020 V1.2 Correct the typo of pin header 2 July., 2020 Support Private Cloud V1.2 TPS, July., 2020...
  • Page 5 InnoAGE M.2 (S80) 3TI7 List of Tables 1: D ............................. 9 ABLE EVICE PARAMETERS 2: P .............................. 10 ABLE ERFORMANCE 3: I AGE M.2 (S80) 3TI7 P ............. 11 ABLE NNODISK OWER EQUIREMENT 4: P ..........................11 ABLE OWER ONSUMPTION 5: T AGE M.2 (S80) 3TI7 ..............

  • Page 6: List Of Figures

    InnoAGE M.2 (S80) 3TI7 List of Figures 1: I AGE M.2 (S80) 3TI7 ....................7 IGURE NNODISK 2: I AGE M.2 (S80) 3TI7 B ............18 IGURE NNODISK LOCK IAGRAM 3: E ................19 IGURE DGE TO ZURE LOUD YSTEM RCHITECTURE 4: E ................

  • Page 7: Product Overview

    TRIM enables SSD’s controller to skip invalid data instead of moving. It can free up significant amount of resources, extends the lifespan of SSD by reducing erase, and write cycles on the SSD. Innodisk’s handling of garbage collection along with TRIM command improves write performance on SSDs.

  • Page 8: Sata Interface

    SATA II. SATA III interface can work with Serial Attached SCSI (SAS) host system, which is used in server computer. Innodisk InnoAGE M.2 (S80) 3TI7 is compliant with Serial ATA Gen 1, Gen 2 and Gen 3 specification (Gen 3 supports 1.5Gbps /3.0Gbps/6.0Gbps data rate).

  • Page 9: Product Specifications

    InnoAGE M.2 (S80) 3TI7 2. Product Specifications 2.1 Capacity and Device Parameters InnoAGE M.2 (S80) 3TI7 device parameters are shown in Table 1. Table 1: Device parameters OS back-up User Capacity capacity (GB) Capacity(GB) DTM28-64GDK1* DF10G 96259888 45.9 64GB DTM28-64GDK1*...

  • Page 10: Performance

    InnoAGE M.2 (S80) 3TI7 2.2 Performance Burst Transfer Rate: 6.0Gbps Table 2: Performance Capacity 32GB 64GB 128GB 256GB 512GB Sequential* 185 MB/s 370MB/s 550 MB/s 550 MB/s 540 MB/s Read (max.) Sequential* 30 MB/s 60 MB/s 125 MB/s 255 MB/s 315 MB/s Write (max.) 4KB Random*...

  • Page 11: Electrical Specifications

    InnoAGE M.2 (S80) 3TI7 2.3 Electrical Specifications 2.3.1 Power Requirement Table 3: Innodisk InnoAGE M.2 (S80) 3TI7 Power Requirement Item Symbol Rating Unit Input voltage +3.3 DC +- 5% 2.3.2 Power Consumption Table 4: Power Consumption Mode Power Consumption (mA)

  • Page 12: Mean Time Between Failures (Mtbf)

    InnoAGE M.2 (S80) 3TI7 2.4.4 Mean Time between Failures (MTBF) Table 7 summarizes the MTBF prediction results for various INNOAGE M.2 (S80) 3TI7 configurations. The analysis was performed using a RAM Commander ™ failure rate prediction. ‧ Failure Rate: The total number of failures within an item population, divided by the total number of life units expended by that population, during a particular measurement interval under stated condition.

  • Page 13: Transfer Mode

    Serial ATA I 1.5Gbps 2.9 Pin Assignment 2.9.1 M.2 SATA pin assignment Innodisk InnoAGE M.2 (S80) 3TI7 uses a standard SATA pin-out. See Table 9 for InnoAGE M.2 (S80) 3TI7 pin assignment. Table 9: Innodisk InnoAGE M.2 (S80) 3TI7 Pin Assignment...

  • Page 14: Inno Age Tm M.2 Pin Header Definition

    GPIO pins to connect with system for customized application. Pin header 2 is design for connecting with daughter board from SPI to Ethernet. See table 10 and 11. Table 10: Innodisk InnoAGE M.2 (S80) 3TI7 Pin Header 1 Assignment...

  • Page 15: Table 11: Innodisk Inno Age Tm M.2 (S80) 3Ti7 Pin Header 2 Assignment

    System GND * Default setting function range: -0.28<V <0.4; 2.4<V <3.63 (V) range: -0.28<V <0.28; 2.0<V <3.63 (V) Table 11: Innodisk InnoAGE M.2 (S80) 3TI7 Pin Header 2 Assignment MISO H2/Pin 1 H2/Pin 3 H2/Pin 5 H2/Pin 7 H2/Pin 9...

  • Page 16: Innoagetm M.2 (S80)

    InnoAGE M.2 (S80) 3TI7 System power 3.3V System GND No internal connection * Default setting function range: -0.28<V <0.4; 2.4<V <3.63 (V) range: -0.28<V <0.28; 2.0<V <3.63 (V) 2.10 Mechanical Dimensions 2.10.1 InnoAGETM M.2 (S80) 2.10.2 Ethernet Daughter Board Horizontal Type Vertical Type V1.2 TPS, July., 2020...

  • Page 17: Assembly Weight

    An Innodisk InnoAGE M.2 (S80) 3TI7 within flash ICs, 64GB’s weight is 8 grams approximately. 2.12 Seek Time Innodisk InnoAGE M.2 (S80) 3TI7 is not a magnetic rotating design. There is no seek or rotational latency required. 2.13 Hot Plug The SSD support hot plug function and can be removed or plugged-in during operation.

  • Page 18: Theory Of Operation

    M.2 (S80) 3TI7 3. Theory of Operation 3.1 Overview Figure 2 shows the operation of Innodisk InnoAGE M.2 (S80) 3TI7 from the system level, including the major hardware blocks. Figure 2: Innodisk InnoAGE M.2 (S80) 3TI7 Block Diagram Innodisk InnoAGE M.2 (S80) 3TI7 integrates a SATA III controller and NAND flash memories.

  • Page 19: Figure 3: Edge To Azurec

    InnoAGE M.2 (S80) 3TI7 Sphere is Microsoft-designed MCU intended for use in IOT devices. Functioning as a system itself, the Azure Sphere runs the Azure Sphere OS, which allows the device to operate independently of the host device’s OS. To ensure that device remains fully protected against external threats such as unauthorized access attempts, Microsoft has created a powerful security suite to ensure device integrity ad to protect the hardware form malicious actors.
  • Page 20 Notice: In Private cloud, InnoAGE doesn’t support Azure sphere OS update and InnoAGE App OTA now. 3.4 Error Detection and Correction Innodisk InnoAGE M.2 (S80) 3TI7 is designed with hardware LDPC ECC engine with hard-decision and soft-decision decoding. Low-density parity-check (LDPC) codes have excellent error correcting performance close to the Shannon limit when decoded with the belief-propagation (BP) algorithm using soft-decision information.
  • Page 21 Innodisk InnoAGE M.2 (S80) 3TI7 uses a static wear-leveling algorithm to ensure that consecutive writes of a specific sector are not written physically to the same page/block in the flash. This spreads flash media usage evenly across all pages, thereby extending flash lifetime.

  • Page 22: Die Raid

    Die RAID is a controller function which leveraged user capacity to back up the data in NAND flash. Die RAID supported can ensure the user data in the NAND Flash more consistent in certain scenario. Innodisk InnoAGE M.2 (S80) 3TI7 series is default enable the Die RAID function for the industrial application.

  • Page 23: Authorized Key Management

    InnoAGE M.2 (S80) 3TI7 the customer to use/test encryption functions. 3.12.3 Authorized Key Management (Optional) In order to complete the physical security layer of protection, encryption needs to be bundled with an ATA user password provided by an ATA Security command. Unlike the AES key, the authorized key must be set by the user via the BIOS configuration.

  • Page 24: Quick Erase

    InnoAGE M.2 (S80) 3TI7 Figure 5: InnoAGE SSD partitioned for future recovery purposes Figure 6: PC reset pin connection to InnoAGE SSD Block Diagram 3.13 Quick Erase Quick Erase function is designed for emergency data erase in few seconds by providing ATA command.

  • Page 25: Figure 7: Ata C

    InnoAGE M.2 (S80) 3TI7 Figure 7: ATA Cryptographic Erase command 3.16 Intuitive Management Platform* InnoAGE SSD can be presented through a simple browser-based user interface; the information is easily accessible for all users, regardless of factors such as device and location. By establishing thresholds for pertinent parameters, for example temperature or the number of SSD write cycles, the management system also offers predictability, which in turn makes it easier to plan future work on the system’s deices.

  • Page 26: Innoage M.2 (S80) 3Ti7 Pin Directions

    Please refer to the pin description for further details. 4.3 Device Drive No additional device drives are required. The Innodisk InnoAGE M.2 (S80) 3TI7 can be configured as a boot device. V1.2...

  • Page 27: Smart Feature Set

    InnoAGE M.2 (S80) 3TI7 5. SMART Feature Set Innodisk 3TI7 series support the SMART command set and defines some vendor-specific data to report SMART attributes of SSD. Table 12: SMART command Value Command Value Command Read Data Read Log Read Attribute Threshold...
  • Page 28 InnoAGE M.2 (S80) 3TI7 ID 0 ID 1 ID 2 ID 3 ID 4 ID 5 Flash ID Later bad block info (Read/Write/Erase) Total LBA written(LBA=32MB) Total LBA read(LBA=32MB) V1.2 TPS, July., 2020...

  • Page 29: Part Number Rule

    InnoAGE M.2 (S80) 3TI7 6. Part Number Rule 11 12 19 20 21 22 23 CODE D T M 2 8 - 4 G D K 1 E 1 0 G - X X X Flash Operation Internal OS back up Customized Description Disk 2.5”...

  • Page 30: Appendix

    InnoAGE M.2 (S80) 3TI7 7. Appendix REACH V1.2 TPS, July., 2020...
  • Page 31 InnoAGE M.2 (S80) 3TI7 RoHS V1.2 TPS, July., 2020...
  • Page 32 InnoAGE M.2 (S80) 3TI7 V1.2 TPS, July., 2020...
  • Page 33 InnoAGE M.2 (S80) 3TI7 V1.2 TPS, July., 2020...
  • Page 34 InnoAGE M.2 (S80) 3TI7 V1.2 TPS, July., 2020...
