COMMERCIAL
SINGLE PACKAGE ROOFTOP
STANDARD AND HIGH EFFICIENCY
HEAT PUMP UNITS
Standard-efficiency (548F), and high-efficiency (542J and
549B) heat pump units with:
• Pre-painted galvanized steel cabinet for long life and quality
appearance
• Commercial strength base rails with built-in rigging capability
• Convertible design for vertical or horizontal supply/return
• Non-corrosive,
sloped
ASHRAE 62 (IAQ)
• Two-inch return-air filters
• A wide assortment of factory-installed options available,
including high static drives that provide additional perfor-
mance range
• Optional gear driven EconoMi$er with CO
(2 to 10 vac actuator)
• Optional gear-driven EconoMi$er with 4 to 20 mA actuator for
EMS controls
• State-of-the-art defrost system
• Dependable 4-way valve operation
Heat Options
• Field-installed electric heat available
• Glycol hydronic coils
548F036-072
549B036-072
condensate
drain
pan,
ventilation control
2
542J150,180
Every compact one-piece unit arrives fully assembled,
charged, tested, and ready to run.
QUIET, EFFICIENT OPERATION AND DEPENDABLE PER-
FORMANCE — Compressors have vibration isolators for quiet
operation. Efficient fan and motor design permits operation at
meets
low sound levels.
Unit sizes 090-180 offer lower utility costs through part-load
operation using 2 stages of cooling.
Quiet and efficient operation is provided by belt-driven indoor
fans (standard on all units over 5 tons). The belt-driven indoor
fan is equipped with variable-pitch pulleys which allow adjust-
ment within the rpm ranges of the factory-supplied pulleys.
Increased operating efficiency is achieved through computer-
designed coils featuring staggered internally enhanced copper
tubes. Fins are ripple-edged for strength, lanced, and double
waved for higher heat transfer.
Models 542J, 548F, 549B
Sizes 036-180
DuraPac and DuraPac Plus
3 to 15 Tons

FEATURES/BENEFITS

Form No. PDS 548F.36.4
548F090-120
549B090-120
