  • Page 1 Product instruction manual OmniFlow 330 The OmniFlow has been designed to be user friendly, however we strongly recommend you take a few minutes to read through this manual to ensure correct operation. Keep this manual safe for future reference.

  • Page 2: Table Of Contents

    OmniFlow 330 1 Introduction ....................1 1.1 Preface ....................1 1.2 Specifications ..................1 2 Safety ......................2 2.1 Environment ..................2 2.2 Do’s and Don’ts ..................2 3 Main parts ...................... 4 3.1 Overview ....................4 4 Installation ..................... 5 4.1 Remove the fix bar and plate ..............

  • Page 3: Introduction

    OmniFlow 330 1 Introduction 1.1 Preface This manual only applies to OmniFlow 330 machine. Before using the machine, please read the instruction manual carefully first. Please keep the manual properly so that consulting it at any time in the future. Any question while operating please contact our technicians.

  • Page 4: Safety

    OmniFlow 330 2 Safety 2.1 Environment Temperature：10℃ to 35℃ Humidity： 30% to 70% Altitude：Below elevation 1000m There is no corrosiveness gas, flammable gas, oil mist and so on in room. 2.2 Do’s and Don’ts Do-Read this manual and fully understand before the operation. Do-Check the plug and machine voltage and frequency to your main supply, and that the socket has a correct working earth lead for this single insulated machine...
  • Page 5 OmniFlow 330 Don’t-put other pieces, especially tiny pieces on loading table. Don’t-alter or uninstall the machine, unless by Vivid authorized engineer. Don’t touch any running parts while running. Don’t shut down the machine while running. Don’t put heavy matter on machine or shock it.

  • Page 6: Main Parts

    OmniFlow 330 3 Main parts 3.1 Overview Name Description Key panel Operation Screen Display Outfeed transmission belt（Optional） Sheet transmission. Turn clockwise to increase the speed and Speed adjusting knob turn anticlockwise to decrease the speed. Top cover Protection Turn the knob clockwise to increase the Blowing adjusting knob speed while turn the knob anticlockwise to slow down.

  • Page 7: Installation

    OmniFlow 330 4 Installation 4.1 Remove the fix bar and plate As shown in the following figure, remove the fix bar and plate first. Fix bar Fix plate 4.2 Mount the extension board There are three screws for the feeding extension board. Remember to fasten the screws after hanging the extension table on.

  • Page 8: Deflectors And Side Guides

    OmniFlow 330 4.3 Deflectors and side guides Deflector 3 is used for wider sheets. Deflector 1 Deflector 2 Deflector 3 4.4 Power socket and switch As shown in the following figures, the power switch and socket are on the operating side.

  • Page 9: Outfeed Conveyor（Optional

    OmniFlow 330 4.5 Outfeed conveyor（Optional） 4.5.1 Installation As shown in the following figures, the extension board should be lower than the conveyor so that the coming sheets will not hit the board. Extension board 4.5.2 Mount the conveyor to the machine As shown in the following figures, there are two shafts on the machine for the conveyor.

  • Page 10: Communication Port

    OmniFlow 330 ② ③ 4.6 Communication port As shown in the following figures, the 9pins port is used to communicate with another machines. The aviation plug is the reserved interface. 9pins port Aviation plug...

  • Page 11: Operation

    OmniFlow 330 5 Operation 5.1 Setting 5.1.1 Separator finger adjusting knob As shown in the following figures. Turn the knob anticlockwise can increase the gap while clockwise decrease the gap. When the sheets double fed, we need to decrease the gap. When the sheets get stuck at the entrance, we should increase the gap. Adjusting knob Sheet Finger...

  • Page 12: Place Sheets

    OmniFlow 330 Adjusting knob Trigger flag 5.1.4 Place sheets The deflectors and the side guides are placed based the sheet width. As for wider sheets ,you may need to lift the edge of sheet on operation side a little to make it fed square.

  • Page 13: Speed Adjusting Knob

    OmniFlow 330 5.1.5 Speed adjusting knob Turn the knob anticlockwise the speed will slow down . Before we turn the knob，we need to unlock the key by following the arrow direction first. Adjusting knob 5.2 Key panel Please read the instructions for each key in the following form before you run the machine.

  • Page 14: Standby

    5.3 Standby When power on the machine, it will come up the Vivid welcome interface. Then it will enter standby interface. Ver：1.01 means the current software version of machine is 1.03.As for the “Ready 0/0,the left 0 means quantity of the paper being run and the right 0 means the preset quantity of paper.

  • Page 15: Set Batch

    OmniFlow 330 5.4 Set Batch Press “M” to enter Set Batch interface. We can set the batch quantity. Shown in the following pictures. After confirming, it will enter the standby interface. Then we can set the sheet quantity for each batch. For example, we set 3 batches and 2 sheets for each batch on the machine.

  • Page 16: Dbl Feed Detect（Optional

    OmniFlow 330 standby interface. 5.8 DBL feed detect（Optional） Press “M” to enter the interface. We can select to open or close the double feed detecting function. Notes：The double feed detecting sensors are optional. If there are no double feed detecting sensors on the machine but the double feed detect is on, it will come up the error message.

  • Page 17: Trouble Shooting

    OmniFlow 330 6 Trouble shooting 6.1 C-5 no paper As shown in the following figure, there is a sensor for the detection of sheets. When the sensor detect no sheets on the table, it will come up C-5. 6.2 C-2 infeed jam （1）C-2 comes up without any sheet getting stuck As shown in the following figure, the sensor may be covered by paper dust.

  • Page 18: Top Cover Open

    OmniFlow 330 6.3 C-1 top cover open When the top cover is opened, it will come up C-1. If the flag didn’t press the switch or the switch broken, it will come up the C-1 as well. Flag Top cover switch 6.4 E-1elevator error （1）When feeding table gets stuck at the bottom, we can restart the machine.

  • Page 19: Maintenance

    OmniFlow 330 7 Maintenance Maintenance of machinery is crucial, necessary maintenance can extend the service life of machinery, and can improve the efficiency of machinery. After long run, the mechanical parts may be covered by lots of dust，which will have bad effects on the operation.
