6. RECARO seat KBA label

label with the seat model details and the KBA model code (KBA label) is located underneath the seat
The
cushion on the cross member, on the right in the direction of travel. To check the label the seat cushion must
be removed.
1
Seat cushion removal
1. Unlock the seat cushion length adjustment and then pull the seat cushion forward as far as it will go.
2. Swing the seat cushion length adjustment handle to the right (in direction of travel) and pull the seat
cushion forward again. You can now pull the seat cushion upward to remove it.
3. The seat cushion must only be removed by lifting it up from the front as the cables at the rear or the air
lines might otherwise be damaged.
Important note:
Check to ensure that the cables and the hoses on the seat cushion have not been damaged
during removal.
1
RECARO Automotive Seating
1 Cushion length adjustment handle
1 KBA label
