RECARO C 6000 MAN TGX Installation Instructions Manual page 30

A
1. Move the steering wheel as far forward as possible.
2. Move the backrest into the vertical position and the seat into the rearmost and highest position.
B
1
3. Loosen and remove the two screws (1) in the vehicle floor at the front (T40 Torx adapter).
4. Now move the seat as far forward as possible.
5. Loosen and remove the four screws (2) in the vehicle floor at the rear
(T40 Torx adapter).
RECARO Automotive Seating
Steering wheel adjustment - front
Standard seat adjustment - rear, top
2
1 Front screws
2 Rear screws
K0240
Page 7 of 23
