- Page 1 User Manual Book Built-in Dispenser Vicino Series BP 3435...
-
Page 2: Introduction
Thank you for your trust in choosing MODENA products for your household needs. With your satisfaction as our priority, we constantly aim to deliver stylishly designed products equipped with state-of-the-art technology to assist you in your daily activities. This is your guidebook containing everything you need to know about our product. Please reach out to us if you... -
Page 3: Table Of Contents
CONTENTS PAGE • Introduction • Part 1: Safety Warnings • Part 2: Name of Parts • Part 3: Installation • Part 4: How to Use • Part 5: Maintenance • Part 6: Problem & Solution • Part 7: Precaution • Part 8: Specification... -
Page 4: Part 1: Safety Warnings
• Part 8: Specification Safety Warnings Part 1 : • Read all instructions before using the water dispenser. • Never clean parts with flammable fluids. • Do not store or use any other flammable vapors and liquids in the vicinity of this or any other water dispenser. •... -
Page 5: Part 3: Installation
Part 3: Installation Installation Notes 3.A. Before installation, the user should decide the water source to use the right inlet according to the source. Dispenser should be installed in a flat, easily accessible, and secure place (not tilted). Do not install the dispenser and power outlet in a damp or wet area. Make sure the power outlet is grounded properly. - Page 6 3.B.2. Connecting the PE hose to the water dispenser. Prepare the PE hose, cut it flat at both ends. Separate the fastener from the blue quick connector. Insert the PE hose into the fastener ring up until the very end part. To see if it’s secured, pull it using the same strength.
- Page 7 Dispenser is equipped with PE hose that requires a hole to insert the hose through the back side of the cabinet. If the dispensed is installed on a cabinet, it has to be secured. Dispenser equipments must be set on the back of the cabinet, detach the water tray and mark the position with the bolt on the bottom of the Dispenser, as shown in the picture: The bottled water and dispenser connections.
-
Page 8: Part 4: How To Use
Part 4: How to Use CONTROL PANEL Remark: Water capacity button Cold water tap button Hot water setting button Light button Hot water tap button Cooling system button Display screen Getting Started Setting the amount of water Touch button once for to set the water capacity of 150ml, twice for 250ml, and thrice to set continuous water flow. Hot water temperature setting Touch button once to set the hot water temperature, there are 3 options: 55°C, 85°C and 100°C. -
Page 9: Part 5: Maintenance
Part 6: Problem & Solution If abormalities happen when in use, please stop using the appliance and unplug the power cord, and check the following table to make sure of the appliance’s condition. If necessary, please contact Modena Call Center. Problem... -
Page 10: Part 7: Precaution
Part 7: Precaution • If the appliance is not going to be used for a long period of time, unplug it and drain all water in its interior • Wash and disinfect the system every 3-6 months with a suitable cleaner and according to its instructions for use •... - Page 11 12/20...
