hepco & becker 5034543 00 05 Quick Start Manual

Front guard for yamaha mt-125

Advertisement

Quick Links

Frontschutzbügel/ Front guard
Yamaha MT-125
2014-2019
Artikel Nr.: / Item-no.:
4543
503
00 05
anthrazit/anthracite
INHALT
CONTENT
1x 700008816 Frontschutzbügel
1x 700008817 Schraubensatz:
2x Spezialschraube M16x40x1,5 Innengewinde M8
2x Zylinderschraube M8x55 (10.9)
2x Linsenkopfschraube M8x30
4x U-Scheibe Ø8,4
2x Abgesetzte Stahldistanz Ø30xØ21x34
2x Stahldistanz Ø13xØ8,5x20
BENÖTIGTE WERKZEUGE
TOOLS REQUIRED
Set
1x 700008816 Front guard
1x 700008817 Screw kit:
Verlängerung/extension
2x Special screw M16x40x1,5 Inner thread M8
2x Allen screw M8x55 (10.9)
2x Filister head screw M8x30
4x Washer Ø8,4
2x Stepped steel spacer Ø30xØ21x34
2x Steel spacer Ø13xØ8,5x20
Ratsche/Ratchet
1
