Burner Head
for PRESTIGE 60 through 250
Kit Part Numbers:
PSRKIT11 - Prestige 60 Natural or Propane Gas
PSRKIT11 - Prestige 110 Propane Gas
PSRKIT10 - Prestige 110 Natural Gas
PSRKIT31 - Prestige 175/250 Natural Gas /Propane Gas
Parts List
1. Burner Head
2. Burner Head Gasket
3. Stainless Steel Phillips Screws. (For attaching the
new burner head to the burner mounting plate.)
Recommended tools:
A. Pipe Wrench.
B. Phillips Screw Driver.
C. 10 mm Socket and/or 10 mm Open Ended
Wrench and/or Adjustable Wrench.
D. Flat Blade Putty Knife.
WARNING
Indicates a potentially hazardous situation
which, if ignored, can result in serious
injury or substantial property damage.
WARNING
For your safety, turn off electrical power
supply at service panel and allow unit to cool
before proceeding. Failure to do so can cause
severe personal injury or death.
Replacement Kit
NOTICE
Indicates special instructions on installa-
tion, operation or maintenance, which are
important to equipment but not related to
personal injury hazards.
WARNING
Failure to follow instructions below can result
in severe personal injury or damage if ignored.
•
Instructions are for a qualified installer/ ser-
vice technician.
•
Read all instructions before proceeding.
•
Follow instructions in proper order.
Advertisement
Related Manuals for TriangleTube PSRKIT11
Summary of Contents for TriangleTube PSRKIT11
- Page 1 Burner Head Replacement Kit for PRESTIGE 60 through 250 Kit Part Numbers: PSRKIT11 - Prestige 60 Natural or Propane Gas PSRKIT11 - Prestige 110 Propane Gas PSRKIT10 - Prestige 110 Natural Gas PSRKIT31 - Prestige 175/250 Natural Gas /Propane Gas Parts List 1.
- Page 2 Burner Head Replacement Kit for PRESTIGE 60 through 250 Instructions: NOTICE 1. Turn power to the unit “OFF” and allow unit If the gasket “sticks” to the burner mounting to cool. plate use a flat blade putty knife to remove 2.
- Page 3 Burner Head Replacement Kit for PRESTIGE 60 through 250 WARNING WARNING Do not over tighten. Pinching or tearing of the Failure to perform a complete combustion burner plate gasket may occur causing the test at high input rate may result in incom- possible escape of combustion gases from the plete combustion and the production of car- combustion chamber resulting in death, seri-...
- Page 4 Burner Head Replacement Kit for PRESTIGE 60 through 250 Table 1: Recommended Combustion Levels Handling of Previously Fired Combustion Chamber Insulation 3. Assure adequate ventilation. WARNING 4. Wash with soap and water after contact. The combustion chamber insulation contains 5. Wash potentially contaminated clothes sepa- ceramic fibers, which are classified as a pos- rately from other laundry and rinse washing sible human carcinogen.
