All manuals and user guides at all-guides.com Washing Machine W100FW / W120FW / W120VW Retention of this Instruction Book Keep this book in a handy place for reference. It contains important details on the safe and proper use of your appliance. If you sell the appliance, pass it on...
(see illustration). If the mains lead needs to be replaced at any time, it should be Connecting to a Drainage System replaced by a special lead obtainable from your local authorised Creda Service Centre. Getting to Know your Machine A charge will be made if you have damaged the existing lead or require a longer one.
Cold Water Supply remove. Cold Fill Only Connection A Cold Fill Adaptor is available from your local Creda authorised Service 3. Remove Centre. 1 screw and 1. Connect angled end of supplied hoses to hot and cold inlets clamp.
All manuals and user guides at all-guides.com Connect to a drainage system G Do not remove hooked end support from drainage hose. G Do not position standpipe near an electrical outlet. For drainage into a standard work top sink ensure outlet pipe has a minimum bore of 32 mm.
All manuals and user guides at all-guides.com Getting to know your machine Model Shown W120VW Model W120VW shows the maximum features available on a Creda washing machine Front Back 1. Door Locked Indicator 9. Rating Plate 2. Mains On/Off Button 10.
All manuals and user guides at all-guides.com A typical wash programme Before selecting any programme ensure the mains button is in the ‘off’ position. 1. Sort laundry into same wash requirements. 2. Close door, applying pressure only at 3. Add detergent/ conditioner the 2 o’clock position.
Page 7
All manuals and user guides at all-guides.com Wash dial and symbols Before selecting a programme, ensure the mains button is in the ‘OFF’ position. Turn the dial slowly clockwise. You will hear as the pointer aligns with the start of the selected wash programme, final rinse or spin. Note: Failure to correctly align the pointer to the start of a wash programme will result in detergent not being dispensed from the drawer.
All manuals and user guides at all-guides.com Choosing a wash programme IMPORTANT INFORMATION: The temperature of the incoming water supply or selection of wash features: ie. Energy Save or Deep Rinse will affect the programme times. Before selecting a programme, ensure the mains button is in the ‘OFF’ position. Approx Maximum Prog.Time...
All manuals and user guides at all-guides.com Optional wash features BUTTON SELECTION To select, press the button and the button comes out. To cancel, press again and the button is flush with the console. Remember to cancel buttons after use! ENERGY SAVE Save money and time on lightly soiled loads.
All manuals and user guides at all-guides.com The Dispenser Drawer IMPORTANT INFORMATION: The Main Wash Indicator has been preset to dispense powder detergent only. If you wish to dispense liquid detergent see instructions for ‘Changing the Main Wash Indicator’, next page. Release Main Wash Indicator (set...
Page 11
All manuals and user guides at all-guides.com Dispensing Liquid Detergent CHANGING THE MAIN WASH INDICATOR The Main Wash Indicator has been fitted, ready to dispense ‘Powder’ detergent only. Max.– 150ml. 100ml. 50ml. Pull drawer out until it Fig 1 Fig 2 reaches its stop.
All manuals and user guides at all-guides.com Care and Cleaning WARNING G Do not clean any part of your appliance with abrasive cleaners, scouring agents, CLEANING THE acids, chlorine based bleach or metal polish as they may cause damage. EXTERIOR REMOVING AND CLEANING THE DISPENSER DRAWER AND COMPARTMENTS Note: It is advisable to clean the dispenser drawer regularly.
This is available as an optional extra. As with any major appliance, there are certain aspects which These can be obtained from your local retailer or Creda Limited, require regular attention. Listed below are a number of such key see separate spares and service leaflet.
All manuals and user guides at all-guides.com Something wrong with your appliance Before calling your nearest Service Office, look at this list, to find a possible solution to your problem. It makes a noise or vibrates during spin... My appliance will not fill or take in detergent... # Is the machine plugged in and switched on? Your appliance will make some noise, especially during spin cycles.
We appreciate you choosing this quality appliance from to the fixed labour charge, but again this cost will have a Creda and are sure that it will give you many years of maximum level of which you will be advised by your Regional excellent service.
Page 16
To join: 1850 502 200 Republic of Ireland: For more information on our exciting product range ring Creda Answer Centre 08701 54 64 74 General Domestic Appliances Limited Morley Way, Peterborough, PE2 9JB. Web.http:/www.creda.co.uk In line with our continuing policy of research and development, and in the interests of everyone, we reserve the right to amend model specifications and services without notice.
