Introducing the EDC
EDC User's Manual

Connecting AC Power

EDC User's Manual
Procedure:
Chapter: 1. Introduction (read all sections of this chapter)
The Introduction chapter of the EDC User's Manual will help you become
familiar with the keypad, the LCD display screen, and general operation
of the EDC Controller.
Chapter: 2. Installation
Section: AC Power Connections
Follow the instructions in the above section of the EDC User's Manual,
taking these steps:
Connect power to the Controller. Perform the Power-up Test.
Remove power from the Controller before proceeding.
Do not apply power to the actuator at this time.
3
