Assembly Instructions; Maintenance - VIBIA I.Cono Assembly Instructions

1
B
A
2
C
3

Maintenance

-Use a slightly-wet cotton cloth for cleaning.
-In case of malfunction or damage, please contact the retailer who sold the lamp.

ASSEMBLY INSTRUCTIONS

C
D
DETAIL X
E
1. Install the reflector (A) using the two screws (B) that were removed from
the body (C).
2. Install the shade (D) on the body (C) as shown by the arrow, so that the
rib on the body slides completely into the slot on the shade (see X detail).
3. Tighten the inner peg (E) using the supplied Allen key. In this way the
shade will be fixed in place.
Rib
Slot
